- Page 1 30 augusti 2023, 10:16 fm Sesame 2.1 Made in Sweden Scan for online support and documents or visit support.enyroom.se...
- Page 2 Please read through the manual completely before installation and usage. Tack för att ni valt en Euroscreen som en del i er AV-installation. Vi ® hoppas den kan ge er många timmar av underhållning och/eller utbildning, beroende på...
- Page 3 Installation / Installation Fig 1: Ø 6,5 Ø 6,5 - Intended for M6 screws. Ø 10,5 Ø 10,5 - Intended for M10 threaded rods. Ø 6,5 Ø 10,5 Mount the brackets by inserting the nuts into the top track of the case and fitting the Ø...
- Page 4 Two screws / Två skruvar (not included / ingår ej) fig 4 Two threaded rods / Två gängstänger (not included / ingår ej) fig 5 STOP / STOPP Install the case in the ceiling (fig 3 to 5). Finish off by attaching the end cover plates. Please locate the ”stop”...
- Page 5 Features / Funktioner Opening the lid / Öppna locket This has to be carried out by two people! a. Remove the end cover plates. b. Put your hand under the lid, see fig 8. The lid is hinged and will not fall to the ground but should not be released uncontrolled! c.
- Page 6 Set height of inner bracket / Justera höjden med innergaveln fig 13 For fine adjustment of screen level and case closing, the Sesame is equipped with adjustable inner brackets on both sides. There is a total travel distance of 8mm. These are set from factory with roughly 4mm in each direction, but may vary slightly.
- Page 7 Adjusting thread tension / Justera trådspänningen (TabTension only/endast) fig 14 fig 15 a. Unscrew endcap, see fig 14 b. Take out centering distance (small, black plastic tube) c. Adjust thread with tensioning screw (marked in red in fig 15). Anti-clockwise increases tension and vice versa.
- Page 8 The Waste Electrical and Electronic Equipment Directive (WEEE Directive) is the European Community directive 2002/96/EC on waste electrical and electronic equipment (WEEE) which, together with the RoHS Directive 2002/95/ ® EC, setting collection, recycling and recovery targets for all types of electrical goods. Applicable Euroscreen products are labeled with the WEEE symbol.
