- Page 1 13 feb. 2023, 15:02 Loke Made in Sweden Scan for online support and documents or visit support.enyroom.se...
- Page 2 Please read through the manual completely before installation and usage. Tack för att ni valt en Euroscreen som en del i er AV-installation. Vi ® hoppas den kan ge er många timmar av underhållning och/eller utbildning, beroende på...
- Page 3 The choice of picture-format in combination with a true matt black border finish creates a powerful framework for the projected image. Overview / Översikt Loke TabTension features all the benefits mentioned above, and an additional selection of tensioned flexible screen surfaces. The tensioning function make it possible to adjust the flatness Fabric width + 110 of the surface and therefore provide a perfectly flat viewing surface for years to come.
- Page 4 Overview / Översikt Brackets - Wall/Ceiling fig 2 34,5 44,5...
- Page 5 Loke Bracket / Loke Konsol EN: USE FASTENERS INTENDED FOR THE ACTUAL SURFACE. Try to level them up as good as possible, using spirit level or laser guide (fig 4). Sideways spacing isn’t crucial as they can slide sideways but recommended maximum distance from the ends should be no more than 30cm (fig 5)! Insert the upper lip of the case first (fig 6), and the bot- tom lip second (fig 7).
- Page 6 Tensioning / Trådspänning (TabTension only) (endast TabTension) EN: To keep the surface flat you may need to fig 8 adjust the tensioning as the surface will change with time and temperature. This is done with the tensioning screw marked in fig 8. It is adjustable with 1/6 turn increments.
- Page 7 How to open case / Öppna kassetten fig 9 EN: The front lid can be removed while the screen remains installed on the wall. To open the case remove the screws shown in fig 9 on both ends. Lift and remove the lid (fig 10).
- Page 8 The Waste Electrical and Electronic Equipment Directive (WEEE Directive) is the European Community directive 2002/96/EC on waste electrical and electronic equipment (WEEE) which, together with the RoHS Directive 2002/95/ ® EC, setting collection, recycling and recovery targets for all types of electrical goods. Applicable Euroscreen products are labeled with the WEEE symbol.
