- Page 1 MPPT SOLAR CHARGE CONTROLLER USER MANUAL EX-10ASC...
- Page 2 DISCLAIMER While every precaution has been taken to ensure the accuracy of the contents of this guide, Expion360 assumes no responsibility for errors or omissions. Note as well that specifications and product functionalities may change without notice. IMPORTANT Please be sure to read the manual in its entirety before using the products. Misuse may result in damaging the products, causing harm, or incurring serious injury.
-
Page 3: Safety Information
The charge controller has the following benefits: Quality internal components for a long lifespan. • Wide window of operating temperatures. • Lithium battery compatible and preset for Expion360 batteries. • Maximum conversion efficiency of 98%. • PV power limitation function. -
Page 4: Led Indicators
Orange On, Solid Under-voltage. On, Solid Over-voltage. Fast Flashing (4x per second) Overheating or low temperature. If PV LED is green and the battery LED is orange: System voltage error. Expion360 10A MPPT Solar Charge Controller Manual Rev 1 7/11/2023... -
Page 5: Technical Specifications
Overall dimension 124 mm x 89 mm x 30 mm Mounting hole size 3.5 mm Mounting dimension 88 mm x 76 mm Wire gauge 14 AWG Connector Weight 1.2 lb Expion360 10A MPPT Solar Charge Controller Manual Rev 1 7/11/2023... -
Page 6: Troubleshooting
Connected PV current, voltage, or power exceeding the rated value of the controller. • The charge controller is used outside the working temperature window. • Any attempt to disassemble the product by the user. • Expion360 10A MPPT Solar Charge Controller Manual Rev 1 7/11/2023...
