1. OVERVIEW
2. BATTERY AND CONTROLLER
Dimensions: Length 469mm. Section 42.0 x 49.5mm.
This section of the down tube and the battery shows how the battery
must rest firmly (yellow) on the inner wall of the tube, while on the other
sides, a minimum distance must be respected which can vary according
to the construction tolerances of the frame, we recommend at least 1mm
minimum space. The controller must be screwed in perfectly.
6 6
