- Page 1 HeatProjector HotZONE HZE Series ELECTRIC RADIANT HEATER RADIANT OPTICS MFG., LLC 1217 1st Street Marysville WA 98270 USA 425-806-3990 www.radiantoptics.com...
-
Page 2: Table Of Contents
Table of Contents 1.0 About your HotZONE HeatProjector 2.0 Important Instructions 3.0 Mounting and Electrical Installation 3.1 Mounting 3.2 Electrical 4.0 Maintenance 5.0 Troubleshooting 6.0 Parts List and Dimensions... -
Page 3: About Your Hotzone Tm Heatprojector
Warranty Radiant Optics Mfg., LLC warrants, to the original purchaser, our products to be free of defects in material or work- manship for six months from date of purchase. Parts found to be defective will be repaired or replaced at the option of Radiant Optics Mfg., LLC. -
Page 4: Important Instructions
2.0 Important Instructions When using or working on electric heaters, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: Read all instructions before installing or using this heater. This heater is hot when in use. -
Page 5: Mounting And Electrical Installation
Options: a. Use 3/4” EMT conduit (1) Radiant Optics recommends using the 3/4” EMT compression fitting provided to mount your heater using 3/4” EMT conduit. (2) Enough high temperature lead wire is provided to mount the heater at the minimum dis- tance to combustibles: 6”... - Page 6 3.1 Mounting (Continued) Optional Mounting kits from Radiant Optics Wall and Ceiling Mounting kits Radiant Optics offers kits to facilitate Wall or Ceiling Mounting. These kits contain: universal mounting subassembly includes plate for attaching to a single or dual gang junction •...
- Page 7 3.1 Mounting (continued) Distance to Combustibles The Radiant Optics HeatProjector projects a beam of energy at a target area. Items placed too close to the heater can overheat and can catch fire. Installers must mount the heater at or above the MINIMUM MOUNTING HEIGHT and ensure the MINIMUM DISTANCE TO COM- BUSTIBLES is maintained above, below and around and the heater.
-
Page 8: Electrical
3.2 Electrical All wiring must be in accordance with the National and Local Electrical Codes. The heater housing must be properly grounded. Refer to the label on the heater for model identification. 1. Install circuit protection for each heater or bank of heaters as required by the NEC and local codes. 2. -
Page 9: Maintenance
4.0 Maintenance HotZone™ heaters have no moving parts and require very little maintenance. We recommend the following be done at least once a year: With an air hose regulated to 30 psi or less, blow off any dust and dirt that has accumulated on •... -
Page 10: Parts List And Dimensions
6.0 Parts List and Dimensions Description e7500 e15000 e25000 Cover Side Lens Element Bracket Element Element Hold-down*** 3/4” EMT Compression Fitting Model Weight Power Input e7500 15” 15” 9” 4LBS 1500 Watts e15000 21” 21” 12” 7LBS 3000 Watts Replacement Elements The estimated life of the element is approximately 2000 hours.
