- Page 1 Model e7500/120V HeatProjector with Stand Part Number: HZHPe7500C120YMS ELECTRIC RADIANT HEATER RADIANT OPTICS MFG., LLC 1217 1st Street Marysville WA 98270 USA 425-806-3990 www.radiantoptics.com...
- Page 2 Table of Contents 1.0 About your HotZONE HeatProjector 2.0 Important Instructions 3.0 Setup and Operation 4.0 Cleaning and Maintenance 5.0 Troubleshooting 6.0 Technical Information...
- Page 3 Warranty Radiant Optics Mfg., LLC warrants, to the original purchaser, our products to be free of defects in material or work- manship for six months from date of purchase. Parts found to be defective will be repaired or replaced at the option of Radiant Optics Mfg., LLC.
- Page 4 2.0 Important Instructions When using or working on electric heaters, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: Read all instructions before installing or using this heater. Remove the unit from the packaging and make sure it is in good condition before using.
- Page 5 3.0 Setup and Operation Setup 1. Remove the heater head and stand from its packaging. 2. Place the stand on a level surface, adjust height, and hand tighten clamps. See instruction pro- vided with stand. 3. The stand comes with a “screw adapter fitting” installed that is unnecessary. Untighten top clamp and remove fitting and discard.
- Page 6 4.0 Cleaning and Maintenance 1. The heater does not contain user serviceable parts. Should the product be damaged or breakdown, contact our customer service. 2. Damaged supply cords must be replaced by the manufacturer. 3. Replacement elements are available and should be installed by qualified personnel. Cleaning Unplug the power cord and make sure the heater is cool before continuing.
- Page 7 5.0 Troubleshooting At power and after two to three minutes of warm-up time, the heater element should glow a warm orange color, similar to the color of coals in a hot fire. If the element does not warm up at all: Check that the power is on at the circuit breaker and/or any installed switch or dimmer.
- Page 8 6.0 Technical Information Description Cover Side Lens Element Bracket Element Model Weight Power Input e7500YMS 15” 15” 9” 4LBS 1500 Watts Voltage Current 120V 12.5 amps Replacement Element Part Number: HPHZe7500C120V www.radiantoptics.com...
