ANDROID 4.4
& above
COMPATIBLE
MET-LINK
MET-LINK Wind Sensor
ABN 56 007 283 963
Manual
8-10 Keith Campbell Court, PO Box 9039
Version 1.02 – Oct 2017
Scoresby, VIC 3179 AUSTRALIA
Author: Observator Instruments
Tel: +61 3 8706 5000, Fax: +61 3 8706 5049
Email: info.au@observator.com
Web: www.observator.com
Observator Instruments V1.02
Page 1
Copyright 2017
©

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MET-LINK and is the answer not in the manual?

Questions and answers

Related Manuals for Observator MET-LINK

Summary of Contents for Observator MET-LINK

  • Page 1 ANDROID 4.4 & above COMPATIBLE MET-LINK MET-LINK Wind Sensor ABN 56 007 283 963 Manual 8-10 Keith Campbell Court, PO Box 9039 Version 1.02 – Oct 2017 Scoresby, VIC 3179 AUSTRALIA Author: Observator Instruments Tel: +61 3 8706 5000, Fax: +61 3 8706 5049 Email: info.au@observator.com...
  • Page 2 MET-LINK USER MANUAL V1.02 Document History Paper copies are valid only on the day they are printed. Contact Observator Instruments if any doubt about the accuracy of this document. Revision History This document has been revised by: Revision Number Revision Date...

  • Page 3: Table Of Contents

    Record data .......................... 20 Export data ........................... 21 View a record ........................22 Comment a record ....................... 23 Turn off MET-LINK interface ....................24 Quit the application ......................24 Delete a record ........................25 Access additional information ................... 26 Read the Bluetooth battery level..................26 Export in local folder ......................
  • Page 4 MET-LINK USER MANUAL V1.02 Page intentionally left blank Observator Instruments V1.02 Copyright 2017 © Page 4...

  • Page 5: Met-Link Introduction

    MET-LINK USER MANUAL V1.02 1. MET-LINK INTRODUCTION Thanks for purchasing the new MET-LINK wireless for the Gill Maximet line of weather sensors. What is MET-LINK? The MET-LINK handheld solution is comprised of a Gill Maximet sensor, a MET-LINK wireless interface and a MET-LINK Android Application for your Bluetooth-enabled Android device.

  • Page 6: Applications

    10. Pollution & Chemical hazard. The MET-LINK system is a great reference tool for wind checking on the spot. The freedom to port data directly to a phone, tablet or laptop offers the end user, field work efficiencies and an ordered means of managing data.

  • Page 7: Safety

    MET-LINK USER MANUAL V1.02 3. SAFETY For correct functioning of Observator MET-LINK, the sensor must be installed according installation instructions. Always read and follow Maximet instructions. Always make sure to securely attach MET-LINK interface module. After end of life dispose this product according local regulations or return to manufacturer.

  • Page 8: Specification

    MET-LINK USER MANUAL V1.02 4. SPECIFICATION Maximet sensor Dimensions Length 222mm Diameter 142mm MET-LINK wireless module Dimensions Length 191mm Diameter 55mm Observator Instruments V1.02 Copyright 2017 © Page 8...
  • Page 9 MET-LINK USER MANUAL V1.02 Connectivity MET-LINK interface (Bluetooth Module) SPP profile Power Supply Extended rechargeable Lithium Ion battery 13Wh (Battery life ~5 hours of operation) Power supply, charge through 12V power pack, powers on when Sensor is plugged in Maximet GMX-500 ( Gill Sensor) Temperature, Humidity &...
  • Page 10 MET-LINK USER MANUAL V1.02 Wind Speed Range 0.1m/s to 60m/s Accuracy ±3% to 40m/s ±5% to 60m/s Resolution 0.01m/s Starting Speed 0.1m/s Sampling Rate Units (m/s, km/hr, mph, kts. Ft/min) Wind Direction Range 0-359° Accuracy ±3° to 40m/s ±5° to 60m/s Resolution 1°...

  • Page 11: Pinout & Wiring Diagram

    MET-LINK USER MANUAL V1.02 PINOUT & WIRING DIAGRAM The Pinout configuration of the MET-LINK is the following: Pin Number Meaning Signal GND Supply +Ve Supply -Ve RS422/485 TXD+ RS232 TXD, RS422/RS485 TXD- RS422/RS485 RXD+ RS232 RXD, RS422/RS485 RXD- Comms Select-Only SDI-12 Data Observator Instruments V1.02...

  • Page 12: Description

    MET-LINK USER MANUAL V1.02 6. DESCRIPTION When the product is delivered, this is what you will find in the box: Items found in the box Figure 1.1. Maximet sensor Figure 1.2. MET-LINK interface Module Figure 1.3. Charging cable Figure 1.4.

  • Page 13: Accessories

    MET-LINK USER MANUAL V1.02 7. ACCESSORIES Observator Instruments offers wide range accessories for MET-LINK range of product directly available from the website: Accessories Figure 2.1. Spare Maximet sensor Figure 2.2. Spare charging adapter Figure 2.3. Spare Li-ion extended batteries Figure 2.4.

  • Page 14: Installation

    To Install the Android application on your smartphone, use the following link, download and install the “.Apk file” (for smartphone): https://play.google.com/store/apps/details?id=obs.metlink&hl=en Connect MET-LINK sensor to the Maximet module by matching the pin and turning the module screw. Download & Install MET-LINK application: Observator Instruments V1.02...
  • Page 15 MET-LINK USER MANUAL V1.02 Press on the MET-LINK interface module button and notice the blue LED indicator turning on. If you cannot see the blue indicator light, it means the MET-LINK interface module is not powered. Blue LED is on Note: In the event where the indicator is not lighting up, ensure that the MET-LINK interface module has enough battery (refer to the “Charging Battery”...

  • Page 16: Charging The Battery

    MET-LINK USER MANUAL V1.02 Charging the battery 1. Connect the provided charging adapter to the MET-LINK interface module and apply power. 2. At any time, you can monitor the charging status of the module by pressing on the MET- LINK interface button. The LED indicator is flashing green and red to indicate that the battery is charging.

  • Page 17: Android Application Interface

    MET-LINK USER MANUAL V1.02 9. ANDROID APPLICATION INTERFACE Activate the GPS location & Bluetooth 1. Go to your phone options 2. Activate the GPS location of your phone 3. Activate Bluetooth Observator Instruments V1.02 Copyright 2017 © Page 17...

  • Page 18: Pair The Sensor Via Bluetooth

    MET-LINK USER MANUAL V1.02 Pair the sensor via Bluetooth Blue indicator After having activated the Bluetooth of your phone: is flashing 1. Turn MET-LINK interface by pressing on the blue button, make sure that the blue LED indicator turns on.

  • Page 19: Launch The App & Connect To Sensor

    MET-LINK USER MANUAL V1.02 Launch the app & connect to sensor 1. Search for “MET-LINK” App in Google Play store or alternatively scan the QR code below. Download and open the software. 2. Wait for the app to load. 3. Search for device to connect to by pressing on “Find Device”.

  • Page 20: Record Data

    MET-LINK USER MANUAL V1.02 Record data 1. When connecting to the sensor for the first time, wait few seconds in order to load the data and select “Logging” menu. 2. Press on “Start Logging” to start the record. A record message will be displayed while recording. Press “Stop Logging”...

  • Page 21: Export Data

    MET-LINK USER MANUAL V1.02 Export data 1. Go to the Menu Page by clicking on the left-hand side Icon. 2. Select “View records” menu. “View records” menu will display the records available from the most recent to the oldest, click on the icon of the selected record to display options.

  • Page 22: View A Record

    MET-LINK USER MANUAL V1.02 View a record 1. In the menu Page select “View records” menu. “View records” menu will display the records available from the most recent to the oldest, click on any record to display the logged data.

  • Page 23: Comment A Record

    MET-LINK USER MANUAL V1.02 Comment a record 1. Follow steps 1, 2 of the previous section “View a Record”. 2. Type your comments in the “comments box”. 3. Press the green icon to save your comment. Observator Instruments V1.02 Copyright 2017 ©...

  • Page 24: Turn Off Met-Link Interface

    MET-LINK USER MANUAL V1.02 Turn off MET-LINK interface We highly recommend to disconnect the wireless when taking measurements. 1. In the Menu Page select “Devices” menu. 2. Click “Disconnect” button to disconnect the sensor, this will immediately turn off the...

  • Page 25: Delete A Record

    MET-LINK USER MANUAL V1.02 Delete a record 1. In the Menu Page select “View records” menu. “View records” menu will display the records available from the most recent to the oldest , click on the icon of the selected record to display options.

  • Page 26: Access Additional Information

    MET-LINK USER MANUAL V1.02 Access additional information 1. On the Dashboard Page, click on the top-right corner. 2. Select “More” to access to the drop-down menu. Documentation links are available on the “Download” buttons. Read the Bluetooth battery level 1. On the Menu Page select “Live data” menu.

  • Page 27: Export In Local Folder

    MET-LINK USER MANUAL V1.02 Export in local folder 1. Follow steps 1, 2, 3 of the section “Export data”. Press “Save into local folder”. 2. The exported record will automatically saved into your local folder. 3. To open the file,...

  • Page 28: Deployment

    MET-LINK USER MANUAL V1.02 DEPLOYMENT Deploy the sensor Start by considering the environment of operation: always operate wearing appropriate safety equipment in safe operating conditions. Install the module on the tripod and make sure the sensor is securely attached and steady.

  • Page 29: Retrieve The Sensor

    At any time, you can use the Smartphone application to connect to the sensor (refer to chapter “Android Application interface” of this document). In the case you cannot see live data, disconnect and reconnect the sensor to the MET-LINK interface module and start the application again.

  • Page 30: Maintenance & Calibration

    MET-LINK USER MANUAL V1.02 MAINTENANCE & CALIBRATION Battery replacement 1. Please unscrew the cover of the Bluetooth Interface module. Disconnect the li-ion battery pack by pulling each part of the white connector. è Warning: do not pull on the cables otherwise it would damage the unit.
  • Page 31 MET-LINK USER MANUAL V1.02 3. Connect the new battery to the white connector, place the battery in the holder. Finally, screw the cover until fully tight. Observator Instruments V1.02 Copyright 2017 © Page 31...

  • Page 32: Long Term Storage

    MET-LINK USER MANUAL V1.02 Long term storage In order to increase the life-expectancy of MET-LINK products, we highly recommend to switch off the long-term storage internal switch of the Bluetooth Interface Module. Switch off the Long term storage switch Note: The internal switch should be only used to turn off the unit if the device is in storage more than 6 months or when transporting by air.

  • Page 33: Service & Support Coverage

    MET-LINK USER MANUAL V1.02 SERVICE & SUPPORT COVERAGE MET-LINK Valid Warranty Warranty on MET-LINK products is one year. See our Warranty and Terms and condition for details. Telephone Technical Support You can contact us any time about Technical Support. Repair and Service Coverage Please enquire about a maintenance program.

  • Page 34: Warranty Conditions

    MET-LINK USER MANUAL V1.02 Warranty conditions MET-LINK products are warranted against defects in material and workmanship for one year from date of warranty registration. The warranty does not cover the battery. Unauthorized service, tampering or abuse will void this warranty. Damage as a result of improper installation will also void this warranty.
