USER AND INSTALLATION MANUAL
ENGLISH
CO2 SWITCH.
CO2 FX
PART02472
rev 01-00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CO2 SWITCH and is the answer not in the manual?

Questions and answers

Related Manuals for Magicfx CO2 SWITCH

Summary of Contents for Magicfx CO2 SWITCH

  • Page 1 USER AND INSTALLATION MANUAL ENGLISH CO2 SWITCH. PART02472 CO2 FX rev 01-00...

  • Page 2: Disclaimer

    Failure to read the manual and to follow the printed instructions may lead to personal injury and/or damage to the product. © 2023 MAGICFX ® All rights reserved. Nothing from this publication may be copied, reproduced and/or published by means of printing, photocopying or by any other means, without the prior written approval of MAGIC FX.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Disclaimer Trademarks Liability Introduction Revision table MEET THE MAGICFX CO2 SWITCH! ® Main parts Technical data 1.3 Product identification Accessories Safety General safety rules CO2 Indoor use Rigging Noise Levels Safety symbols Safety precautions Installation and use Mount on a SUPERBLASTER II...

  • Page 4: Introduction

    This document contains the original instructions in English. In case you require other languages please contact MAGIC FX. REVISION TABLE Doc nr Revision Date Description Author Approved PART02472 01-00 04-09-2023 Initial release PvdW MAGICFX ECO2JET — User and Installation Manual ®...

  • Page 5: Meet The Magicfx ® Co2 Switch

    CO2 SWITCH can be controlled with a commander or a switchpack. ® The MAGICFX CO2 SWITCH is equipped with several holes for mounting the unit. The CO2 SWITCH can be mounted to a stage or to a truss with a truss clamp. Safety cables can be attached, ® The MAGICFX CO2 SWITCH is suited for simultaneous activation of multiple units through a power link.

  • Page 6: Technical Data

    TECHNICAL DATA Product Product Name CO2 SWITCH Product Code MFX1124 Product Type CO2 FX Main Length 203 mm 7.3 in Dimensions Width 140 mm 4.5 in Height 155 mm 6.1 in Weight Weight 3.7 kg 8.2 lb Package Length 280 mm 11.4 in...

  • Page 7: Accessories

    High Pressure Hose 3/8 Male - Female, 5 m MFX1122 CO₂ High Pressure Hose 3/8 Male - Female, 20 m MFX3103 Twenty Clamp (20 kg) M10 SPR00119 Safety Steel MFX0313 Schuko to Neutrik® powerCON TRUE1 - cable 1.5 m MFX0313Accessories MAGICFX ECO2JET — User and Installation Manual ®...

  • Page 8: Safety

    Only authorised persons may carry out work with the CO2 SWITCH. • Do not use the CO2 SWITCH if there are people or animals in the direct output. • Make sure that children, unauthorised people and animals do not obtain access to the CO2 SWITCH.

  • Page 9: Indoor Use

    INDOOR USE The CO2 SWITCH is designed for outdoor use and use in well-ventilated indoor spaces. When used indoors, make sure you take the necessary preparations. These preparations could include, but are not limited to: • Consulting your CO2 supplier.

  • Page 10: Safety Symbols

    Missing or obscured safety symbols on the machine can lead to WARNING death, serious injury or property damage. Make sure all safety symbols are correctly in place and visible, see Section 2.5. MAGICFX ECO2JET — User and Installation Manual ®...

  • Page 11: Installation And Use

    INSTALLATION AND USE MOUNT ON A SUPERBLASTER II Loosen the starknob by turning it counter-clockwise. Mount the CO2 SWITCH on the desired position on the SUPERBLASTER II. MAGICFX ECO2JET — User and Installation Manual ®...

  • Page 12: Connect Power

    Tighten the starknob to secure the CO2 SWITCH. CONNECT POWER Connect the PowerCon TRUE1 power cable to the power input of the CO2 SWITCH. Connect the other end to the power controller with a 100-250 Vac (50-60 Hz) power output source.

  • Page 13: Connect Co2

    Make sure that the power is switched off (LED power indicator is off). Connect the CO2 hose to the CO2 connector on the SUPERBLASTER II and the other end to the CO2 SWITCH. Connect a CO₂ bottle to hose connector to a CO2 cylinder.
  • Page 14 Connect the CO2 hose to the CO2 bottle to hose connector on the CO2 cylinder. Connect the other end of the CO2 hose to the CO2 SWITCH. In case of multiple machines: Repeat steps 1 – 5 for each machine.

  • Page 15: Blast With Power

    Carefully read the manual of the SUPERBLASTER II for all safety WARNING steps. Open the CO2 cylinder. When it’s time to shoot, switch the power on. Do not use the machine if the CO2 valve is not opening and CAUTION closing correctly. MAGICFX ECO2JET — User and Installation Manual ®...

  • Page 16: Clean Up

    CLEAN UP Close the CO2 cylinder. Switch the power on to release the remaining pressure. Switch the power off and disconnect the power cable(s). MAGICFX ECO2JET — User and Installation Manual ®...
  • Page 17 Disconnect the CO2 hose from the CO₂ bottle to hose connector on the CO2 cylinder. Remove the CO₂ bottle to hose connector from the cylinder. Dismount the machine. MAGICFX ECO2JET — User and Installation Manual ®...

  • Page 18: Maintenance

    MAINTENANCE To achieve the maximum service life of the CO2 SWITCH you must regularly clean the CO2 SWITCH and test if it is functioning correctly. Contact MAGIC FX if the CO2 SWITCH is not functioning correctly. Do not replace parts yourself; always consult MAGIC FX.

  • Page 19: Ec Declaration Of Conformity

    EC DECLARATION OF CONFORMITY           MAGICFX ECO2JET — User and Installation Manual ®...
  • Page 20 WWW.MAGICFX.EU...
