Queer Eye 6624335COM Manual

Wardrobe nightfall oak
Hide thumbs

Advertisement

Quick Links

Download this manual
6624335COM
Wardrobe Nightfall Oak
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
B346624335COM00SF
Tough

Advertisement

loading
Need help?

Need help?

Do you have a question about the 6624335COM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Queer Eye 6624335COM

Summary of Contents for Queer Eye 6624335COM

  • Page 1 6624335COM Wardrobe Nightfall Oak B346624335COM00SF Date of Purchase ___ / ___ / ___ Lot Number: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Do Not Return This Product! Contact our customer service team for help first.

  • Page 2: Helpful Hints

    Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Monday-Friday 9am - 5pm CST Visit ameriwoodhome.com Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1-2 ESTIMATED ASSEMBLY TIME: 1 HOUR - Open your item in the area you plan to keep it to avoid excessive heavy lifting.

  • Page 3: Before You Start

    Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight.

  • Page 4: Board Identification

    Board Identification Not actual size TOP PANEL Front Frame T6624335020SF T6624335010SF Back Frame Side Upper Rail T6624335030SF T6624335040SF QTY: 2 PCS Mid Shelf Side Lower Rail T6624335060SF T6624335050SF QTY: 2 PCS ameriwoodhome.com...
  • Page 5 Board Identification Not actual size Left Side Frame Right Side Frame T6624335070SF T6624335080SF Bottom panel Back panel T6624335090SF T6624335100SF Adjustable Shelf T6624335110SF ameriwoodhome.com...
  • Page 6 Board Identification Not actual size ameriwoodhome.com...

  • Page 7: Part List

    Hardware Bag Reference Number: 26624335COM0 Part List Actual Size Ø3.5X12mm Ø8X30mm Ø4X38mm x 30 Wood dowel Screw Screw TSF0501 TSF1006 TSF0801 Ø4X14mm Screw TSF1005 ameriwoodhome.com...
  • Page 8 Hardware Bag Reference Number: 26624335COM0 Part List NotActual Size Ø7x34mm Ø15x12mm x 34 x 34 Glue Shelf support Cam bolt Cam lock TSF0015 TSF0554 TSF0354 TSF0307 Hanger rod Hanger rod flange Wall anchor Wall bracket TSF0061 TSF0060 TSF0025 TSF2626 ameriwoodhome.com...
  • Page 9 STEP Ø8X30mm Ø3.5X12mm Ø7x34mm x 16 1.1 Attach (11) to (B), (C) with (2) as below illustrated. 1.2 Attach (5) to (A), (B), (C) as below illustrated. 1.3 Attach (1) to (B), (C) as below illustrated. Wooden Dowel Hole for wooden dowel Use one drop of glue in dowel hole.
  • Page 10 STEP Ø8X30mm Ø7x34mm x 18 2.1 Attach (5) to (F), (G), (H) as below illustrated. 2.2 Attach (1) to (G), (H) as below illustrated. Wooden Dowel Hole for wooden dowel Use one drop of glue in dowel hole. ameriwoodhome.com...
  • Page 11 STEP Wooden Dowel Ø8X30mm x 18 Hole for wooden dowel Use one drop of glue 3.1 Attach (1) to (I), (J), (E), (D) as below illustrated. in dowel hole. Wooden Dowel Hole for wooden dowel Use one drop of glue in dowel hole.
  • Page 12 STEP Wooden Dowel Ø15x12mm Hole for wooden dowel Use one drop of glue 4.1 Attach (E), (D) to (B) with (6) as below illustrated. in dowel hole. ameriwoodhome.com...
  • Page 13 STEP Ø15x12mm 5.1 Attach (C) & (12) to (E), (D) & (B) with (6) as below illustrated. Wooden Dowel Hole for wooden dowel Use one drop of glue in dowel hole. Quick Assembly LOCK Proper orientation of CAM LOCK ameriwoodhome.com...
  • Page 14 STEP Wooden Dowel Ø15x12mm Hole for wooden dowel Use one drop of glue 6.1 Attach (A) to (B), (C) with (6) as below illustrated. in dowel hole. Quick Assembly LOCK Proper orientation of CAM LOCK ameriwoodhome.com...
  • Page 15 STEP Wooden Dowel Ø15x12mm Hole for wooden dowel Use one drop of glue 7.1 Attach (I), (J) to (G) with (6) as below illustrated. in dowel hole. 7.2 Attach (H) to (I), (J) with (6) as below illustrated. Quick Assembly LOCK Proper orientation of CAM LOCK ameriwoodhome.com...
  • Page 16 STEP Wooden Dowel Ø15x12mm Hole for wooden dowel Use one drop of glue 8.1 Attach (F) to (H), (J), (G) with (6) as below illustrated. in dowel hole. Quick Assembly LOCK Proper orientation of CAM LOCK ameriwoodhome.com...
  • Page 17 STEP Wooden Dowel Ø15x12mm Hole for wooden dowel Use one drop of glue 9.1 Attach sample from step (8) to sample from step (6) in dowel hole. with hardware (6) as illustrated. 9.2 Firmly grasp (B) and (C) to stand up unit before moving to next step.
  • Page 18 STEP 10.1 Insert (8) as below illustrated. 10.2 Put (K) on (8) as below illustrated. ameriwoodhome.com...
  • Page 19 STEP Wallboard Pared WARNING This unit must be anchored to a stud or wall,as shown.Failure to do so could cause severe injury. Hole Agujero Trou 11.1 Drill a 3/16" diameter hole (5mm) in the wallboard. 11.2 Tap the wall anchor (9) into the hole until it is flush.

  • Page 20: Maximum Loads

    Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 0 lbs / 0 kgs (not for loading) Hanger rod max. load: 35 lbs/ 15.9 kgs 35 lbs/ 15.9 kgs Warning: Risk of injury to persons - do not place a television on this furniture.
  • Page 21 Register your product to receive the following: * New trend details - sneak peek on what's new * Surveys - have a voice within our community * Exclusive deals and discount codes * Quick and easy replacement part service To register your product, visit ameriwoodhome.com Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You"...
  • Page 22 Español Cubierta Delantera Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Lunes - Viernes 9am - 5pm CST Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
  • Page 23 Español Identificación de los Paneles Lista de Piezas (Página 7, 8) Este no es el tamaño real (Página 4, 5, 6) Tamaño real Este no es el tamaño real (5) Perno de leva Taco de madera (6) Bloqueo de leva PANEL SUPERIOR Tornillo (7) Pegamento...
  • Page 24 Español Página 19 Atención: Cet appareil doit être ancré à un montant ou à un mur, comme illustré. Le non-respect de cette consigne peut entraîner des blessures graves. 11.1 Percez un trou de 3/16" de diamètre (5 mm) dans le panneau mural. 11.2 Enfoncez l'ancrage mural (9) dans le trou jusqu'à...
  • Page 25 Français Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ. VEUILLEZ LIRE ET GARDER POUR UNE RÉFÉRENCE FUTURE Ne retournez pas ce produit! Contactez notre équipe de service à la clientèle amicale d'abord pour obtenir de l'aide. Appelez-nous: (sans frais) du Lundi au Vendredi de 9h à...
  • Page 26 Français Liste des pièces (Page 7, 8) Identification des matériaux Pas de taille réelle (Page 4, 5, 6) Taille réelle Pas de taille réelle Cheville en bois (5) Boulon à came (6) Serrure à came PANNEAU SUPÉRIEUR (7) Colle CADRE AVANT (8) Support d'étagère CADRE ARRIÈRE (9) Ancrage mural...
  • Page 27 Français Page 19 Attention : Cet appareil doit être ancré à un montant ou à un mur, comme illustré. Le non-respect de cette consigne peut entraîner des blessures graves. 11.1 Percez un trou de 3/16" de diamètre (5 mm) dans le panneau mural. 11.2 Enfoncez l'ancrage mural (9) dans le trou jusqu'à ce qu'il soit aligné. 11.3 Fixez le support mural (10) à l'ancrage mural (9) avec la vis (3). Page 20 CHARGES MAXIMALES Ce meuble a été conçu pour supporter les charges maximales indiquées.  En excédant ces limites de charge, le meuble pourrait devenir instable, s'effondrer, et/ou causer des blessures graves. AVERTISSEMENT : Risque de blessure corporelle - ne pas placer une télévision sur ce meuble. Ce meuble n'est pas approuvé pour une utilisation avec une télévision. Page 21 Enregistrez votre produit pour recevoir les éléments suivantes: Détails sur les nouvelles tendances - un aperçu sur les nouveautés Sondages - avoir une voix au sein de notre communauté Offres exclusives et codes promo Service de pièces de rechange rapide et facile Pour enregistrer votre produit, visitez ameriwoodhome.com 5 Étoiles Visitez le site Web de votre détaillant local, évaluez le produit que vous avez acheté et laissez-nous vos commentaires ! Nous tenons à offrir un grand "Merci" à tous nos clients pour avoir pris le temps d'assembler ce produit "Ameriwood Home", et de nous donner vos commentaires précieux. Merci ameriwoodhome.com...
