Viking CPA-7A Technical Practice

Technical Practice
Add Paging, Loud Ringing and Background
ringing, the CPA-7A generates an adjustable loud warble from a dry contact closure or
a ringing C.O. or analog PABX/KSU station.
The CPA-7A is easy to install and can eliminate the installation of multiple bells, relays
and paging cards.
Features
• 7 watts of paging power (powers up to 8 horns)
• Day/night switchable for paging/loud ring
• Ringing volume adjustment
• Paging volume adjustment
• Interfaces with ringing Centrex or C.O. lines,
paging ports, unused trunk ports, or a ringing
analog station port
• Background music is muted during page
• Provides "Night Bell" warble tone via contact
closure or ringing analog circuit
• Provides page "Alert" tone before paging
Made in the U.S.A.
Telecommunication Peripheral Products
Music to Centrex, PABX's or Key Systems
http://www.VikingElectronics.com
E-mail...Sales@VikingElectronics.com
The CPA-7A is a cost effective, general
purpose, telecom paging system.
The CPA-7A provides 7 watts of power for
many telecom paging applications and can
also provide background music and night bell
capability.
Compatible with ringing Centrex and analog
PABX/KSU station ports as well as unused
trunk inputs, the CPA-7A will also interface
directly with standard paging ports. For loud
adjustable
Applications
• Paging and loud ringing for Centrex systems
• Paging and loud ringing for systems with paging
ports, analog station ports or trunk ports
Sales...(715) 386 - 8861
Specifications
Power: 120V AC/13.8V AC 1.25 A, UL listed adapter provided
Amplifier: 7 watts - to power up to (8) 8 ohm speakers or (16) 45
ohm speakers
Speakers: (1) 25AE paging horn
Dimensions: 133 mm x 89 mm x 44 mm (5.25" x 3.5" x 1.75")
Shipping Weight: 1.36 kg (3 lbs)
Environmental: 0 C to 32 C (32 F to 90 F) with 5% to 95% non-
condensing humidity
Sound Pressure Level: 110 dB @ 1 m
Maximum Cable Length: 91 m (300 ft) 18 AWG
CPA-7A
General Purpose
Telecom Paging System
June 7, 1998
