PARTS
*not to scale
x 16
3/4" (1.9 cm)
PN 2233
x 2
3" (7 .62 cm)
PN 1267
x 1
3/8" (1 cm)
PN 1238
x 1
PN 7030
x 1
1/2" (1.9 cm)
PN 2293
BikeErg weight: 68 lb (31 kg)
Space required for use (training area): 48 in x 60 in (122 cm x 152 cm)
Questions? Comments? Problems?
Contact Concept2 directly at 800.245.5676 (US and Canada)
Or visit us online: concept2.com
Concept2, Inc. 105 Industrial Park Drive Morrisville, Vermont USA 05661 concept2.com/contact
c2vt.com/bikeergassembly
T27 6-Lobe Driver
6 mm L-key
x 1
x 1
3" (7 .6 cm)
3 1/4" (8.3 cm)
PN 1268
PN 1224
x 1
x 1
PN 7120
PN 1271
x 6
1/2" (1.3 cm)
PN 1299
x 2
1" (2.5 cm)
PN 2276
x 1
Slide Rail/Wrench
PN 7104
ASSEMBLY INSTRUCTIONS
x 1
IMPORTANT: Do not fully tighten
screws until all screws are in place.
Use the 6-lobe driver with L -key
inserted (as shown) and fully tighten
all fasteners using this configuration.
