COLOUR TELEVISION
SERVICE MANUAL
Features
Stage curtain for open and close effect
218 programs stored
Multi-picture modes and sound modes selection
On/Off timer
Child lock
Soft exchange Count
Appointment
DVD component input
Serial Number: 0010550217
附件一（1/1）
Version:00.00
COLOR TELEVISION
Models
29FV6H
Edition: 2006-08-30
Model: 29FV6H

Advertisement

Table of Contents
loading

Related Manuals for Haier 29FV6H

Summary of Contents for Haier 29FV6H

  • Page 1 29FV6H Features Stage curtain for open and close effect 218 programs stored Multi-picture modes and sound modes selection On/Off timer Child lock Soft exchange Count Appointment DVD component input Serial Number: 0010550217 Version:00.00 Edition: 2006-08-30 COLOR TELEVISION Model: 29FV6H 附件一（1/1）...

  • Page 2: Table Of Contents

    Contents Ⅰ． Technical specifications & Safety precautions …………………... Ⅱ．Servicing precautions ………………………………………………..5 Ⅲ． Functions & Location of controls …………………………………. Ⅳ．Disassembly instructions ………………………………………… A. Important notes …………………………………………………... B. Precautions for handling of picture tube ……………………. Ⅴ． Specific information …………………………………………………. A. Principle integrated circuits ……………………………………. B.

  • Page 3: Ⅰ． Technical Specifications & Safety Precautions

    TECHNICAL SPECIFICATION & SAFETY PRECAUTIONS POWER SUPPLY: AC 150~250V, 50/60 Hz Tuning system: frequency synthesized type auto-search fine tuning system； 38.9MHz； Power consumption: ≤ 140W； Antenna input impedance: 75Ω； Receiving system: a) Color system: PAL BG；AV NTSC3.58/4.43MHz； b) Broadcast TV system: B/G； Language displayed: English；...
  • Page 4 An Isolation Transformer should always be used during the servicing of a receiver whose chassis is not isolated from the AC power line. Use a transformer of adequate power rating as this protects the technician from accidents that might result in personal injury caused by electrical shocks.

  • Page 5: Ⅱ．servicing Precautions

    SERVICING PRECAUTIONS Warning and Cautions 1. When you clean the TV set, please pull 4. To prevent the TV set from firing and out the power plug from AC outlet. Don't electric shock, don't clean the cabinet and the screen with make the TV set rain benzene, petrol and other chemicals.
  • Page 6 any cleanser. If using hard cloth, the tube surface will be damaged. CAUTION: Before servicing receivers covered by this service manual and its supplements and addenda, read and follow the SAFETY PRECAUTIONS. NOTE: If unforeseen circumstances create conflict between the following servicing precautions and any of the safety precautions, always follow the safety precautions.
  • Page 7 8. Always connect the test receiver ground lead to the receiver chassis ground before connecting the test receiver positive lead. Always remove the test receiver ground lead last. 9. Use with this receiver only the test fixtures specified in this service manual. CAUTION: Do not connect the test fixture ground strap to any heat sink in this receiver.
  • Page 8 your clothes’ fabric or lifting of your foot from a carpeted floor might generate static electricity sufficient to damage an ES device.) General Soldering Guidelines 1. Use a grounded-tip, low-wattage soldering iron and appropriate tip size and shape that will maintain tip temperature within the range of 500 F to 600 2.
  • Page 9 (or with solder braid) before removing the IC. Replacement Carefully insert the replacement IC in the circuit board. Carefully bend each IC lead against the circuit foil pad and solder it. Clean the soldered areas with a small wire-bristle brush.(It is not necessary to reapply acrylic coating to the areas).
  • Page 10 2. Securely crimp the leads of replacement component around notch at stake top. 3. Solder the connections CAUTION: Maintain original spacing between the replaced component and adjacent components and the circuit board to prevent excessive component temperatures. Circuit Board Foil Repair Excessive heat applied to the copper foil of any printed circuit board will weaken the adhesive that bonds foil to the circuit board causing the foil to separate from or “lift-off”...

  • Page 11: Ⅲ． Functions & Location Of Controls

    components or sharp edges. III. FUNCTIONS & LOCATION OF CONTROLS Preset of 218 programs. Curtain-drawing type of display when powered up; Various kinds of picture modes and sound modes; Screen display of menu in English ; C bus control with digital technology; Timer on/off;...
  • Page 12 Remote Controller REMOTE CONTROLLER GUIDE Remote controller functions TV/AV exchan ging bu tton Mu te bu tton Numeric butto n On e/two/th ree digi tal bu ttons Pictu re mo de selecti on Volu me u p/d wo n butto n Program play-forward button Surround sound selection button Game background selection button...

  • Page 13: Ⅳ. Disassembly Instructions

    Ⅳ. DISASSEMBLY INSTRUCTIONS A. Important note This set is disconnected from the power supply through the converter transformer. An isolating transformer is necessary to service operations on the primary side of the converter transformer. Back Cabinet Removal Remove the screw residing on the back cabinet and carefully separate the back cabinet from the front cabinet.

  • Page 14: Ⅴ． Specific Information

    A. Principle integrated circuits This new generation large screen color television is based on the latest 2in1 chip HAIER8829A-V1.0 developed by Toshiba and haier, integrate with other advance ICs, high performance and simpler circuit are realized by using I bus to communicate with all the other ICs.
  • Page 15 signal at pin 9 and pin 10 which come from N201(HAIER8829A-V1.0), the desired video signal will be available at pin 3, and then sends to AV switcher N802 (TC90L01N) after emitter follower V207 and V214. The pin 31 of HAIER8829A-V1.0 output SIF signal. It will go back into the pin 33 of HAIER8829A-V1.0 after C225.
  • Page 16 Pin 13 and 14 are the I2C bus ports. Pin 16 and 17 are the audio output ports to the audio processor. Pin 18 is the video output port to the MCU. Pin 22, 23, 24 are the video and audio output ports to the AV out. 6.
  • Page 17 in Table 4. (Use a fluke 87III digital multi-meter or other digital multi-meter.) Table 4 Working Function Voltage (V) GROUND VERTICAL SCAN WAVE OUTPUT 13.66 POWER VCC2 25.5 REFERENCE 3.28 VERTICAL RAMP WAVE INPUT 3.28 POWER VCC1 25.2 PUMP UP OUT 2.38 9.

  • Page 18: Chip Introduction

    The video amplifying circuits supply voltage output from pin 10 of the T401(FBT-B-19) is 180V~200V. After VD406 and C462, 180V is transmitted to the CRT printed circuit board by one shield wire. The vertical scan supply voltage for N301 output from pin 8 of T401(FBT-B-19) is 27V.
  • Page 19 +5 VCC SIGNAL GND HORIZONTAL SYNC SIGNAL INPUT HORIZONTAL PULSE SIGNAL OUTPUT HORIZONTAL AFC VERTICAL SIGNAL PRODUCE LOCATION VERTICAL PULSE SIGNAL OUTPUT HORIZONTAL VCC Cb SIGNAL INPUT Y SIGNAL INPUT Cr SIGNAL INPUT TV GND COLOR SIGNAL INPUT EXTERIOR VEDIO SIGNAL INPUT TV VCC AUTOMATIC BRIGHT CONTROL E-W SIGNAL OUTPUT...
  • Page 20 C SERIAL BUS DATA LINE SDA1 C SERIAL BUS COLOCK LINE SCL1 SDA2 SCL2 VIDEO SYNC SIGNAL INPUT REMOTE CONTROL INPUT SLEEP CONTROL 2. Definition of every pin of the LA7841 Working Function Voltage (V) GROUND VERTICAL SCAN WAVE OUTPUT 13.66 POWER VCC2 25.5...

  • Page 21: Service Mode Menu Alignment Structure

    4. Definition of every pin of the TA8256BH STEP FUNCTION STEP FUNCTION IN(W) MUTE T.C IN(R) OUT(L) PRE-GND IN(L) POWER-GND MUTE OUT(W) RIPPLE-FILTER OUT(R) 5. Definition of every pin of the 24LC08 STEP FUNCTION STEP FUNCTION TEST C Service mode menu alignment structure 1.
  • Page 22 Press CH- and CH+ buttons to select items for adjustment. Press VOL- and VOL+ buttons to adjust selected items. Press the button (POWER) to switch off the appliance and go back to the normal state. Maintenance menu Item Specifications Default Value OPTION，...
  • Page 23 CLVD The data when YVU mode & SOUND SYS = M OPT2 IF:38.9 00:AKB off;01:ACB (cut off : align to targets);10:ADB( drive : align to targets);11:AKB ( cut off / drive : align to targets) SECD Secam mode BIT0:S-ID Sens ; BIT1:Bell fo ; BIT2:S-ID Mode ;...

  • Page 24: The Schedule Of The Main Circuit

    D . The schedule of the main circuit：...

  • Page 25: Ⅵ． Electrical Adjustment

    VI. ELECTRICAL ADJUSTMENT A. Safety precautions 1. It is safe to adjust after using insulating transformer between the power supply line and chassis input to prevent the risk of electric shock and protect the instrument. 2. Never disconnect leads while the TV receiver is on. 3.
  • Page 26 5. CUT OFF adjustment 1) Receiver PAL system “MONO SCOPE” signal, warm up the TV set for 15 min. 2) The control terms of adjustment are as follows: color=0; bright=50; contrast gradient=100. 3) Confirm bus data: RCUT=20; BCUT=20; GCUT=20; GDRV-40; BDRV=40. 4) Press RGB VP button on factory remote controller to let the horizontal line just appears.
  • Page 27 1) Receive “STAR STEP” signal. 2) Set color=50; contrast gradient=100; bright=50. 3) Adjust bus “BRTC” data to make “STAIR STEP” fore four paragraphs just not be distincted. 4) Vice bright after adjustment should satisfy to make “STAIR STEP” black clause be in 4±1.5 clause.

  • Page 28: Ⅶ． Information Of Resistors And Capacitors

    VII. INFORMATION RESISTORS CAPACITORS RESISTORS & CAPACITORS-PARTS NO.CODE Notes: 1.part numbers are indicated on most mechanical parts. Please use this part number for parts orders. 2.The unit of resistance is Ω(ohm).K=1000Ω,M=1000KΩ 3.The unit of capacitance is μF(microfarad). P=10 μF. Numbering system of Capacitor Example CL42 ----- 17 ---- 50V ---- 2F4 ---- 104 * ----...

  • Page 29: Terminal View Of Transistors

    RESISTOR PART NAME & DESCRIPTION TYPE ALLOWANCE ±1% Carbon ±5% Solid ±10% Metal ±20% Oxide ±2% Fuse Terminal view of transistors 2SC1815-Y------F 2SC4544----B-A 2SA1015-Y------F 2SB1569A-E----B-A EXPORT 2SC752GTM-Y------F EXPORT 2SP2400A-E----B-A EXPORT 2SC2878-A(TEM)------F EXPORT 2SC3853(2SC3852)----E-A RN1204(DTC144ESATP) EXPORT KSR1010TA 3DD2553----B-A 2SA562TM-Y------F KSR2010TA 3CA688----E-A 2SC3355------F EXPORT 2SC3853(2SC3852)----B-A 2SD18887YD...

  • Page 30: Ⅷ Damageable Parts List

    Ⅷ DAMAGEABLE PARTS LIST Part specialized code Circuit Name of part Type name diagram 0094005099 A68QCP693X001 POWER 0094000230 SWITCH KDC-A04-8A SW601 0090400437 POWER LINE JPRVVZ252DJBQ RS11-1/2W-12MΩ RESISTOR 0094101090 ±20% R532 RF10-1W-1Ω±5% RESISTOR 0094101290 R566 RF10-2W-4.7Ω±5% RESISTOR 0094101340 R327 RF10-2W-2.2Ω±5% RESISTOR 0094102506 R929 2200pF-M-AC400V-1...
  • Page 31 Sincere Forever Haier Group Haier Industrial Park, No.1, Haier Road 266101, Qingdao, China http://www.haier.com 附件一（2/2）...
