Haier 29F9B-P Service Manual

Hide thumbs Also See for 29F9B-P:

Advertisement

Quick Links

Download this manual
COLOUR TELEVISION
Serv ice Manual
Features
2
I C bus control
218 programmes stored
Stage curtain for on/off effect
Multi-picture mode,multi-sound mode selection
Auto-correcting black balance
Surround stereo
Super woofer
Haier group
29F9B-P
I.Precaution.................................1
2.
Specifications..............................7
3.
4.
Troubleshooting...........................21
5.
6.
Electrical Parts List.....................27
7.
Block Diagram.............................46
8.
Schematic Diagrams...................47

Advertisement

loading

Related Manuals for Haier 29F9B-P

Summary of Contents for Haier 29F9B-P

  • Page 1: Table Of Contents

    29F9B-P COLOUR TELEVISION Serv ice Manual I.Precaution.........1 Specifications......7 Alignment and Adjustments..9 Troubleshooting......21 Exploded Views and Parts List..26 Electrical Parts List.....27 Block Diagram......46 Schematic Diagrams....47 Features I C bus control 218 programmes stored Stage curtain for on/off effect Multi-picture mode,multi-sound mode selection...
  • Page 2 1. PRECAUTIONS INPORTANT SAFETY NOTICE These parts are identified by many electrical and mechanical parts in this chassis have special safety-related characteristics. ! in the Schematic Diagram and Replacement Parts List. It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent X-RADIATION, Shock, Fire, or other Hazards.
  • Page 3 SERVICEING PRECAUTIONS CAUTION: Before servicing receivers covered by this service manual and its supplements and addenda, read and follow the SAFETY PRECAUTIONS. NOTE: If unforeseen circumstances create conflict between the following servicing precautions and any of the safety precautions, always follow the safety precautions. Remember : Safety First.
  • Page 4 8. Always connect the test receiver ground lead to the receiver chassis ground before connecting the test receiver positive lead. Always remove the test receiver ground lead last. Use with this receiver only the test fixtures specified in this service manual. CAUTION: Do not connect the test fixture ground strap to any heat sink in this receiver.
  • Page 5 General Soldering Guidelines 1. Use a grounded-tip, low-wattage soldering iron and appropriate tip size and shape that will maintain tip temperature within the range of 500 F to 600 2. Use an appropriate gauge of RMA resin-core solder composed of 60 parts tin/40 parts lead. 3.
  • Page 6 Replacement Carefully insert the replacement IC in the circuit board. Carefully bend each IC lead against the circuit foil pad and solder it. Clean the soldered areas with a small wire-bristle brush.(It is not necessary to reapply acrylic coating to the areas). “Small-Signal”...
  • Page 7 Fuse and Conventional Resistor Removal/Replacement 1. Clip each fuse or resistor lead at top of the circuit board hollow stake. 2. Securely crimp the leads of replacement component around notch at stake top. 3. Solder the connections CAUTION: Maintain original spacing between the replaced component and adjacent components and the circuit board to prevent excessive component temperatures.

  • Page 8: Specifications

    3. Connect insulated 20-gauge jumper wire from the lead of the nearest component on one side of the pattern break to the lead of the nearest component on the other side. Carefully crimp and solder the connections. CAUTION: Be sure the insulated jumper wire is dressed so that it does not touch components or sharp edges.
  • Page 9 Products functions TYPE TYPE 29F9B 29F9B FUNCTIONS FUNCTIONS TDA8844/8843 Audio output power(w) 5W+5W+8W √ Tube 29″FS Super woofer Color system NO of built-in speakers PAL、NTSC √ Broadcast system Analog surround stereo B/G、D/K、I √ No.of preset channels Treble/bass lifting and balancing √...

  • Page 10: Alignment And Adjustments

    3.Alignment and Adjustment Functions: Complete frequency range CATV (470MHz) Preset of 218 programs. Curtain-drawing type of display when powered up. Various kinds of picture modes and sound modes Screen display of menu in English Program scan Surrounding stereo C bus control with digital technology Stereo earphone jack Zooming of pictures...
  • Page 11 Control Local control buttons Local menu selecting button TV/AV selecting button Volume tuning button (increase) Volume tuning button (decrease) Program number tuning button (down) Program number tuning button (up) Remote control button Power/standby button Program number button Screen display button Help button Picture mode button Sound mode button...
  • Page 12 Brief operation instructions Insert the power plug into the power line socket and insert the antenna plug into the antenna socket on the rear panel. Press down the power switch of the TV set. The red indicator light goes on. Follow the steps below. A．Program preset 1.
  • Page 13 Disassembly instructions A. Important note This set is disconnected from the power supply through the converter transformer. An isolating transformer is necessary to service operations on the primary side of the converter transformer. Back Cabinet Removal Remove the screw residing on the back cabinet and carefully separate the back cabinet from the front cabinet.
  • Page 14 Pin No. Functions Working voltage (V) Mute Timer Power Halftone OSD B signal output OSD G signal output OSD R signal output BLANK signal output Line synchronous signal input Pattern synchronous signal input OSD-XIN OSD-XOUT Ground OSD crystal oscillation OSD crystal oscillation 2.63 Reset button Power supply...
  • Page 15 Pin No. Functions Working voltage (V) SVHS-Y input 3.99 Working power Internal video input 3.67 Earth Audio output 2.97 SECAM decoding and decoupling 0.42 External video input Dark current test input B output 3.09 G output 3.27 R output 3.16 Beam current limit and field protection 2.19 R input...
  • Page 16 Pin No. Functions Working voltage (V) Field reference current forming 3.87 AGC decoupling 4.25 High amplifier AGC output 6.52 Audio deemphasis 2.91 Sound demodulation and decoupling 2.07 3. N502 SAA4961 Integrated comb filter Pin No. Functions Working voltage (V) Standard color sub-carrier input Earth Earth Earth...
  • Page 17 Pin No. Functions Working voltage (V) Blank ADC input ADC input ADC input Brightness signal input 2.74 Address selection input U signal input 2.31 V signal input 2.30 Blank Clock line 4.23 Blank Blank Data line 4.27 Power supply V signal output 2.69 U signal output 2.63...
  • Page 18 Pin No. Functions Working voltage (V) AV1 audio input (left) 4.01 Blank Main signal audio input (left) 4.01 Reference voltage filter capacitance 7.95 Main signal audio input (right) 4.01 Power supply 8.02 AV1 audio input (right) 4.02 Earth Audio output to Pin 10 4.02 Audio input (from Pin 9) 4.02...
  • Page 19 10. N1602 TDA2616 super integrated power amplifier circuit with mute Pin No. Function Working voltage (V) Super treble input 10.82 Mute control input 21.7 Semi power input 10.84 Amplified output 1 10.85 Earth Amplified output 2 10.83 Power supply 21.73 Positive output terminal 10.84 Negative output terminal...
  • Page 20 Adjustment A. Safety precautions 1. It is safe to adjust after using insulating transformer between the power supply line and chassis input to prevent the risk of electric shock and protect the instrument. 2. Never disconnect leads while the TV receiver is on. 3.
  • Page 21 signals (strength: 60dB) 2) Connect the negative end of the digital display voltmeter to earth and the positive to TP-A of AGC input. 3) Press factory handset button to enter the adjustment status. Press button 6 to adjust AGC-TAK, which is usually set to 0B and the measured voltage value is usually 3.85~4.25V.

  • Page 22: Troubleshooting

    4.Trouble shooting No OSD Check if pin26、pin27 have H.V synchronous signal No H synchronous signal No V synchronous signal Check and replace V908 Check V907 Check and replace N901 Check L904 Check and replace N901...
  • Page 23 Remote control breakdown (but handset is good) Check +5V of sensor normal abnormal Check N804 Check and replace PM01 Check RP02 Check and replace N901...
  • Page 24 Horiznal bright line Check if pin47、pin48 in N201 have saw-tooth wave output Check if 15V 45V are normal ? Check R256、C233 abnormal normaol Check R804 VD407 Check and replace R816 R817 Check replace TDA8844 R413 VD405 R302 R303 DZ304 C310 Check T902...
  • Page 25 No picture Whether there is picture in AV in put mode Check pin6 in TDA8844 Check pin48、pin49 in N201 have IF signal input Check pin13 of N201 Replace N201 HC101、 SF101、 A101 Check N201 Check V203 V205 V206 Check if pin27、31、32 in N201 have signal input Check N201and its external circuit Check if R、G、B signal have output...
  • Page 26 No raster Check +B voltage normal abnormal Check heater voltage and video amf. voltage Check pin 20 voltage in Check every voltage Check R505 Check CRT cathode in CPU voltage abnormal normal Check 300V between Check V403 T444 Replace CRT C1650 Check V402 Check N801 Parts connected...

  • Page 27: Exploded Views And Parts List

    5.Exploded Views and Parts List...

  • Page 28: Electrical Parts List

    Electrical parts list Name Code Location Spcification Unit（percent） 10904802444 29F9B-P(LT) 0094000956 A68CPAA00X01 holding pad 0090201172 MTAC2019AC--Q Screw 0090600015 SJ2824-87 ST4*12F Washer 0090100122 1MM φ8.5 Degaussing coil tie 0090800186 BJZ0002-----Q combined nut 0090600018 Washer 0090200247 TMMOA101 plastic bag 0090501291 240*160 Degaussing coil...
  • Page 29 Wire 0090400767 XP001 JT5251-C0136Q Wire 0090400768 XP002 JT3251-C0135Q Resister 0094101518 RT13-1/6W-1kΩ±5%-07-A-A Resister 0094101704 RT13-1/6W-820Ω±5%-07-A-A Resister 0094101705 RT13-1/6W-1.5KΩ±5%-07-A-A Resister 0094101705 RT13-1/6W-1.5KΩ±5%-07-A-A Resister 0094100935 RT13-1/6W-2.7KΩ-J-07-A-A Resister 0094101949 RT13-1/6W-47Ω±5%-07-A-A Infrared sensor 0094000216 A1000 HS0038 Diode 0094401085 VD1000 HFT505M-1 Capacitor 0094201063 C001 CD110-16V-100µF-M-05-F-A Jumper 0094101120 J001 φ0.6mm/7.5mm------A...
  • Page 30 heatsink assembly 0090800237 BJB0055-----Q Heatsink 0090100136 MTBT0029BC--Q 0094401086 N801 KA3S0880RF Screw 0090600075 SJ2832-87 ST3*10F mica chip 0090200362 (20X26) 0090100114 MTBH2002BA--Q heatsink assembly 0090800238 BJB0056-----Q Heatsink 0090100137 MTBT0026BC--Q Transistor 0094400383 VD403 2SD1886----B-A Screw 0090600076 SJ2831-87 ST3*10F heatsink assembly 0090800239 BJB0057-----Q Heatsink 0090100138 MTBT0028BC--Q 0094400607...
  • Page 31 Resister 0094101226 R402 RT13-1/6W-100Ω±5%------R Resister 0094101226 R960 RT13-1/6W-100Ω±5%------R Resister 0094101226 R218 RT13-1/6W-100Ω±5%------R Resister 0094100017 R251 RT13-1/6W-100Ω±5%------T Resister 0094101226 R247 RT13-1/6W-100Ω±5%------R Resister 0094101226 R259 RT13-1/6W-100Ω±5%------R Resister 0094101226 R705 RT13-1/6W-100Ω±5%------R Resister 0094101226 R706 RT13-1/6W-100Ω±5%------R Resister 0094101226 R714 RT13-1/6W-100Ω±5%------R Resister 0094101226 R720 RT13-1/6W-100Ω±5%------R Resister 0094101226 R729...
  • Page 32 Resister 0094101238 R908 RT13-1/6W-1.5kΩ±5%------R Resister 0094101238 R913 RT13-1/6W-1.5kΩ±5%------R Resister 0094101240 R102 RT13-1/6W-2.2KΩ±5%------R Resister 0094101240 R948 RT13-1/6W-2.2KΩ±5%------R Resister 0094101240 R951 RT13-1/6W-2.2KΩ±5%------R Resister 0094101241 R909 RT13-1/6W-2.7KΩ±5%------R Resister 0094101241 R914 RT13-1/6W-2.7KΩ±5%------R Resister 0094100028 R253 RT13-1/6W-3.3KΩ±5%------T Resister 0094101244 R204 RT13-1/6W-4.7kΩ±5%------R Resister 0094101244 R203 RT13-1/6W-4.7kΩ±5%------R Resister 0094101244 R933...
  • Page 33 Capacitor 0094201079 C916 CC1-06-CH-63V-15pF-J------F Capacitor 0094201079 C917 CC1-06-CH-63V-15pF-J------F Capacitor 0094201083 C235 CC1-06-CH-63V-18pF-J------F Capacitor 0094202166 C915 CC1-06-CH-63V-22pF-J------F Capacitor 0094202166 C914 CC1-06-CH-63V-22pF-J------F Capacitor 0094201088 C207 CC1-08-CH-63V-100pF-J------F Capacitor 0094201088 CV01 CC1-08-CH-63V-100pF-J------F Capacitor 0094201088 CV02 CC1-08-CH-63V-100pF-J------F Capacitor 0094201088 CV03 CC1-08-CH-63V-100pF-J------F Capacitor 0094201088 CV04 CC1-08-CH-63V-100pF-J------F Capacitor 0094201088 C208...
  • Page 34 Capacitor 0094200988 C702 CD110-16V-47µF-M------F Capacitor 0094200747 C826 CD110-16V-100µF-M------F Capacitor 0094200747 C832 CD110-16V-100µF-M------F Capacitor 0094200989 C102 CD110-16V-220µF-M------F Capacitor 0094200640 C719 CD110-25V-10µF-M------F Capacitor 0094200640 C829 CD110-25V-10µF-M------F Capacitor 0094200640 C712 CD110-25V-10µF-M------F Capacitor 0094200640 C831 CD110-25V-10µF-M------F Capacitor 0094200640 C730 CD110-25V-10µF-M------F Capacitor 0094200640 C731 CD110-25V-10µF-M------F Capacitor 0094200581 C216...
  • Page 35 Capacitor 0094200096 C304 CL21X-100V-0.1µF-J------F Capacitor 0094201465 C215 CL21X-63V-0.47µF-J------F Capacitor 0094201465 C222 CL21X-63V-0.47µF-J------F Capacitor 0094201465 C218 CL21X-63V-0.47µF-J------F Capacitor 0094200097 C408 CL23B-400V-472-J------F Inducer 0094500708 L901 LGA0204-0.47µH±10%------R Inducer 0094500018 L206 LGA0204-1µH±10%------T Inducer 0094500018 L207 LGA0204-1µH±10%------T Inducer 0094500018 L208 LGA0204-1µH±10%------T Inducer 0094500709 L101 LGA0204-0.56µH±10%------R Inducer 0094500710 L903...
  • Page 36 Diode 0094401116 DZ802 MTZJ4.7B------R Diode 0094401118 DZ803 MTZJ5.6B------R Diode 0094401118 DZ905 MTZJ5.6B------R Diode 0094401118 DZ807 MTZJ5.6B------R Diode 0094401119 DZ903 MTZJ6.2C------R Diode 0094400620 DZ904 MTZJ7.5C------R Diode 0094401120 DZ801 MTZJ8.2B------R Diode 0094401120 DZ401 MTZJ8.2B------R Diode 0094401120 DZ402 MTZJ8.2B------R Diode 0094401120 DZX01 MTZJ8.2B------R Diode 0094400493 DZ204...
  • Page 37 Jumper 0094101103 J229 φ0.6mm/7.5mm------B Jumper 0094101103 J227 φ0.6mm/7.5mm------B Jumper 0094101103 J224 φ0.6mm/7.5mm------B Jumper 0094101103 J225 φ0.6mm/7.5mm------B Jumper 0094101103 J215 φ0.6mm/7.5mm------B Jumper 0094101103 J216 φ0.6mm/7.5mm------B Jumper 0094101103 J217 φ0.6mm/7.5mm------B Jumper 0094101103 J226 φ0.6mm/7.5mm------B Jumper 0094101103 J270 φ0.6mm/7.5mm------B Jumper 0094101103 J264 φ0.6mm/7.5mm------B Jumper 0094101103 RT25...
  • Page 38 Jumper 0094101104 J201 φ0.6mm/10mm------B Jumper 0094101104 J213 φ0.6mm/10mm------B Jumper 0094101104 J214 φ0.6mm/10mm------B Jumper 0094101104 J218 φ0.6mm/10mm------B Jumper 0094101104 J219 φ0.6mm/10mm------B Jumper 0094101104 J223 φ0.6mm/10mm------B Jumper 0094101104 J601 φ0.6mm/10mm------B Jumper 0094101104 J602 φ0.6mm/10mm------B Jumper 0094101104 J603 φ0.6mm/10mm------B Jumper 0094101104 J604 φ0.6mm/10mm------B Jumper 0094101104 J605...
  • Page 39 Jumper 0094101104 J949 φ0.6mm/10mm------B Jumper 0094101104 J957 φ0.6mm/10mm------B Jumper 0094101104 J958 φ0.6mm/10mm------B Jumper 0094101104 J935 φ0.6mm/10mm------B Jumper 0094101104 J960 φ0.6mm/10mm------B Jumper 0094101104 RT24 φ0.6mm/10mm------B Jumper 0094101104 C813 φ0.6mm/10mm------B Jumper 0094101104 DT02 φ0.6mm/10mm------B Jumper 0094101104 φ0.6mm/10mm------B Jumper 0094101104 J221 φ0.6mm/10mm------B Jumper 0094101104 J222 φ0.6mm/10mm------B...
  • Page 40 Capacitor 0094201447 C111 CT1-06-2F4-63V-0.1µF-Z------F Capacitor 0094200724 C106 CD110-50V-0.33µF-M------F Capacitor 0094201458 C229 CL11-63V-0.047µF-J------F Capacitor 0094201462 C217 CL21X-63V-0.1µF-J------F Capacitor 0094201463 C708 CL21X-63V-0.22µF-J------F Capacitor 0094201463 C705 CL21X-63V-0.22µF-J------F Capacitor 0094201463 C234 CL21X-63V-0.22µF-J------F Transistor 0094400438 V203 2SC1815(Y)------F Resister 0094101385 R409 RF10-1W-1Ω±5%-05-E-A Resister 0094101384 R408 RF11-1/2W-33Ω±5%-17-A-A Resister 0094102103 R601...
  • Page 41 Inducer 0094500411 L103 LGA0204-10µH±10%-07-A-A Inducer 0094500548 J414 LGA0410-27µH±10%-10-A-A Inducer 0094500274 L401 AA36 Inducer 0094500539 L402 LX170 Filter 0094500413 L801 735504C Transformer 0094500414 T401 BCT-15 Transformer 0094500538 T801 BCK-07-D8C Transformer 0094500472 T444 BSC29-0160 Diode 0094400498 VD301A BAV21-07-J-- Diode 0094400798 VD401 S2L60-15-P-- Diode 0094400629 VD801...
  • Page 42 Jumper 0094101120 J807 φ0.6mm/7.5mm------A Jumper 0094101139 F801 φ0.6mm/10mm------A Resister 0094100017 R1055 RT13-1/6W-100Ω±5%------T Resister 0094100017 R1056 RT13-1/6W-100Ω±5%------T Resister 0094100722 R1034 RT13-1/6W-1.8KΩ±5%------T Resister 0094100026 R1035 RT13-1/6W-2.2KΩ±5%------T Resister 0094100029 R1036 RT13-1/6W-4.7KΩ±5%------T Resister 0094100033 R1057 RT13-1/6W-10KΩ±5%------T Resister 0094100779 R1032 RT13-1/6W-22kΩ±5%------T Resister 0094100800 R1033 RT13-1/6W-47kΩ±5%------T Resister 0094100077 R1052...
  • Page 43 Connect housing 0094300110 CNP2 TJC1-2A Connect housing 0094300029 CNP3 TJC9-4A Fuser holder 0090100037 MTBJ0001BB--Q Fuse 0094000012 T4A/250V Capacitor 0094201717 CD110X-35V-470µF-M-05-E-A Capacitor 0094202153 CD110X-16V-100µF-M-05-E-A Transistor 0094400192 KSC815-YTA------F Transistor 0094400203 KSA539-YTA------F Wire 0090400608 JT21010D0125Q 线束CNP1 Wire 0090400607 线束CNP3 JT4351-C0132Q Resister 0094100025 RT13-1/6W-1.5kΩ±5%------T Resister 0094100029 RT13-1/6W-4.7KΩ±5%------T...
  • Page 44 clamp 0090200244 Main PCB assembly 0094000326 BXY0023-----Q heatsink assembly 0090800240 BJB0058-----Q 0094400271 N001A LA4282 0094400271 N002A LA4282 Heatsink 0090800199 BJB0092-----Q Screw 0090600075 SJ2832-87 ST3*10F Wire 0090400951 JT1201-10170Q Jumper 0094101104 W005A φ0.6mm/10mm------B Jumper 0094101104 W006A φ0.6mm/10mm------B Jumper 0094101104 W007A φ0.6mm/10mm------B Jumper 0094101104 W000A φ0.6mm/10mm------B...
  • Page 45 0091800341 PX42015-----Q Capacitor 0094201441 C007A CL21X-63V-0.1µF-K-05-B-A Capacitor 0094201441 C008A CL21X-63V-0.1µF-K-05-B-A Capacitor 0094201401 C014B CD110-25V-4.7µF-M-05-F-A Capacitor 0094200826 C000A CD110X-35V-1000µF-M-05-E-A Capacitor 0094200826 C001A CD110X-35V-1000µF-M-05-E-A Capacitor 0094200826 C011A CD110X-35V-1000µF-M-05-E-A Capacitor 0094200826 C013A CD110X-35V-1000µF-M-05-E-A Capacitor 0094200826 C023A CD110X-35V-1000µF-M-05-E-A Jumper 0094101205 W004A φ0.6mm/5mm------A Transistor 0094400509 V000A 2SC1815(Y)----D-A Connect housing...

  • Page 46: Block Diagram

    System 1 loading wave input Saw-tooth input System 2 CVBS input V output TV audio input Super woofer amf. Sound Amf. N1603 TDA2616 N1602 TDA2616 Super woofer output 140V N601 TDA9860 POWER Audio input 1 sound output Audio input 2 29F9B-P...

  • Page 47: Schematic Diagrams

    8.Schematic Diagrams...
  • Page 48 Sincere Forever Haier Group Tel:86-532-8938356 Web side:http://www.haier.com...
