PCB Piezotronics IMI SENSORS TO604B91 Installation And Operating Manual page 23

4
PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
B
522 CABLE
BLUNT CUT
RED
A
GREEN
WHITE
BLACK
BLUE
BROWN
DRAIN
1 LENGTH WILL VARY IN FEET OR METERS DEPENDING ON THE MODEL
4
3
"LENGTH" 1
SOCKET 1
SOCKET 2
SOCKET 3
SOCKET 4
SOCKET 5
X NC
3
2
SQ CONNECTOR
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES DIMENSIONS IN MILLIMETERS
[ IN BRACKETS ]
DECIMALS XX ±.03 DECIMALS X ± 0.8
XXX ±.010 XX ± 0.25
ANGLES  2 DEGREES ANGLES  2 DEGREES
CABLE TOLERANCES IN ENGLISH CABLE TOLERANCES IN METRIC
1"≤ LENGTH < 1' = +1"/ - 0
2.54cm ≤ LENGTH < 30.5cm = +2.54cm/ - 0
1'≤ LENGTH < 5' = +2"/ - 0
30.5cm ≤ LENGTH < 1.5m = +5.1cm/ - 0
5'≤ LENGTH < 100' = +6"/ - 0
1.5m ≤ LENGTH < 30.5m = +15.2cm/ - 0
30.5m ≤ LENGTH = +30.5cm/ - 0
100'≤ LENGTH = +1'/ - 0
FILLETS AND RADII FILLETS AND RADII
.003 - .005 0.07 - 0.13
2
1
REVISIONS
REV DESCRIPTION
NR RELEASED TO DRAFTING
KEYWAY
SOCKET 1
SOCKET 4
SOCKET 5
DRAWN CHECKED ENGINEER
NJF 02/03/23 JDM 02/03/23 GCD 02/03/23
3425 WALDEN AVE. DEPEW, NY 14043
TITLE
(716) 684-0001 E-MAIL: sales@pcb.com
OUTLINE DRAWING
DWG. NO.
MODEL 522SQBZ CODE
IDENT. NO.
CABLE SERIES
52681
SCALE: 2.25X
1
DIN
53484
B
SOCKET 2
SOCKET 3
A
77124
SHEET 1 OF 1
