Oriental motor AZX Series Operating Manual

O P E R A T I N G M A N U A L
Servo Motor
AZX Series
Motor Edition

Introduction .................................................1

Safety precautions ......................................1

Precautions For Use ......................................2
Preparation ...................................................3
Installation ....................................................4
Introduction
„ Before using the product
Only qualified personnel of electrical and mechanical engineering should
work with the product.
Use the product correctly after thoroughly reading the section
precautions. In addition, be sure to observe the contents described in
"
warning, caution, and note in this manual.
The product described in this manual is designed and manufactured to
be incorporated in general industrial equipment. Do not use for any other
purpose. Oriental Motor Co., Ltd. is not responsible for any compensation for
damage caused through failure to observe this warning.
„ Related operating manuals
Download the operating manuals from Oriental Motor Website Download
Page or contact your nearest Oriental Motor sales office.
• AZX Series OPERATING MANUAL Hardware Edition
• AZX Series OPERATING MANUAL Software Edition
Safety precautions
The precautions described below are intended to ensure the safe and
correct use of the product, and to prevent the user and other personnel from
exposure to the risk of injury. Use the product only after carefully reading and
fully understanding these instructions.
Description of signs
Handling the product without observing the instructions
that accompany a "WARNING" symbol may result in
serious injury or death.
Handling the product without observing the instructions
that accompany a "CAUTION" symbol may result in injury
or property damage.
The items under this heading contain important handling
instructions that the user should observe to ensure safe
use of the product.
Explanation of graphic symbols
Indicates "prohibited" actions that must not be performed.
Indicates "compulsory" actions that must be performed.
HM-60466-3
Grounding .....................................................5
Inspection And Maintenance ....................6
General Specifications ................................6
Regulations And Standards ........................6
" Safety
Thank you for purchasing an Oriental Motor product.
This Operating Manual describes product handling procedures and safety
precautions.
y Please read it thoroughly to ensure safe operation.
y Always keep the manual where it is readily available.
Do not use the product in explosive or corrosive environments, in the
presence of flammable gases, in places subjected to splashing water, or
near combustibles. Doing so may result in fire, electric shock, or injury.
Do not transport, install, connect, or inspect the product while the
power is supplied. Doing so may result in electric shock or damage to
equipment.
Do not forcibly bend, pull, or pinch the cable. Doing so may result in
fire or electric shock.
Do not disassemble or modify the motor. Doing so may result in injury
or damage to equipment.
Do not machine or modify the cable. Doing so may result in fire,
electrical shock, or damage to equipment.
Do not apply a strong force to the connector or the terminal. Doing so
may damage to the connector or the terminal, resulting in fire, electric
shock, or damage to equipment.
Assign qualified personnel to the task of installing, wiring, operating/
controlling, inspecting and troubleshooting the product. Handling
by unqualified personnel may result in fire, electric shock, injury, or
damage to equipment.
Take measures to hold the moving part in position if the product is
used in vertical drive such as elevating equipment. Failure to do so may
result in injury or damage to equipment.
Do not use the brake mechanism of the electromagnetic brake motor
for braking or as a safety brake. Doing so may result in injury or
damage to equipment.
Take measures to hold the moving part in position since the motor will
stop and lose its holding force if an alarm is generated in the driver (any
of the driver's protective functions is triggered). Failure to do so may
result in injury or damage to equipment.
Install the motor inside an enclosure. Failure to do so may result in
electric shock or injury.
Be sure to ground the motor as it is Class I equipment. Failure to do so
may result in electric shock.
Do not use the motor beyond its specifications. Doing so may result in
electric shock, injury, or damage to equipment.
Keep your fingers and objects out of the openings in the motor. Failure
to do so may result in fire, electric shock, or injury.
Do not touch the motor during operation or immediately after
stopping. The surface is hot, and this may cause a skin burn(s).
Do not carry the motor by holding the output shaft or the cable. Doing
so may result in injury.
Do not place combustibles around the motor. Doing so may result in
fire or a skin burn(s).
Do not leave anything around the motor that would obstruct
ventilation. Doing so may result in damage to equipment.
Do not touch the rotating part (output shaft) while operating the
motor. Doing so may result in injury.
Do not touch the terminals while conducting the insulation resistance
measurement or the dielectric strength test. Accidental contact may
result in electric shock.
1
