KiloVault Uniti EcoFreedom Lite
USERS GUIDE
This publication could include technical or other inaccuracies or typographical errors. Changes are periodically added to the information herein;
these changes will be incorporated in new editions of the publication. KiloVault® may make improvements and/or changes in the services,
facilities or specifications described in this publication at any time. Please note: If this unit is installed by someone other than the end-user, the installer
must explain the contents of this installation and user's manual to the end-user.
Advertisement
Related Manuals for KiloVault Uniti Series
Summary of Contents for KiloVault Uniti Series
- Page 1 This publication could include technical or other inaccuracies or typographical errors. Changes are periodically added to the information herein; these changes will be incorporated in new editions of the publication. KiloVault® may make improvements and/or changes in the services, facilities or specifications described in this publication at any time. Please note: If this unit is installed by someone other than the end-user, the installer...
- Page 2 Read this entire document, in addition to the equipment Installation Manual, before installing or using the KiloVault Uniti. Failure to do so or to follow any of the instructions or warnings in this document can result in electrical shock, serious injury, or death, or can damage the Uniti, potentially rendering it...
-
Page 3: Installing Base
Installing Base Place the Battery cabinet of the KiloVault Uniti onto the base. Using the ten bolts provided secure the battery cabinet to the base. Prepare the required parts. Install the main body to the base. Tighten the screws. Battery Cabinet Fix the main body and the base by 10 screws. -
Page 4: Installing The Top Cabinet
Installing the top cabinet Install the cable box to the top of the main body. Tighten the screws. - Page 5 STEP 4 Installing the batteries Insert the batteries into Using the provided busbars included in the lower Uniti compartment. each PLC battery box connect the top 2 Batteries per row. 2 batteries in series and the bottom 2 batteries in series. Note: When making the connections, be sure to observe correct hardware stacking and proper polarity, and ensure that nothing obstructs the connection be-...
- Page 6 STEP 5 Connect the cables Connect the black Jumper cable provide Attach the side cover to the main body. with the Uniti. Cables is connected from the Slide the front cover in. top negative post of the top string of batteries to the lower Positive post of the bottom string.
- Page 7 Install the side cover Attach the side cover to the main body. Secure the side cover using the provided screws. . Slide the front cover in.
- Page 8 Busbars and Breaker 120 VAC 15 Amp outlet. 120 VAC outlet Breaker. Battery String Breakers Light Breaker Load Breakers. Inverter Breakers. 120 VAC 15 Amp outlet. Positive Busbar Negative Busbar...
- Page 9 Unit Eco Freedom Lite Basic Inverter Settings. 01 Output Source Priority PV priority mode, switching to the Mains when the PV fails or the battery is lower than the set value of the parameter. 02 Output Frequency 60.0 Hz 03 AC Input Voltage Range Wide mains input voltage range of 230V Machine: 90~280V Mains input voltage range of 230V machine: 90~280V 04 Battery Power to Utility Setpoint...
- Page 10 KiloVault* LLC KiloVault® Uniti Series Pre-wired energy storage system 330 Codman Hill Road Boxborough, MA 01719 +1(888)218–5924 info@kilovault.comwww.kilovault.com...
- Page 11 KiloVault Uniti EcoFreedom Lite USERS GUIDE...
