- Page 1 KiloVault Uniti USERS GUIDE REV 1.1 10/26/2023...
- Page 2 This publication could include technical or other inaccuracies or typographical errors. Changes are periodically added to the information herein; these changes will be incorporated in new editions of the publication. KiloVault® may make improvements and/or changes in the services, facilities or specifications described in this publication at any time. Please note: If this unit is installed by someone other than the end-user, the installer must explain the contents of this installation and user’s manual to the end-user.
- Page 3 Uniti EcoFreedom 5 - What you received "DO NOT DISCARD CRATE AND INTERNAL PACKAGING." Battery Cabinet Batteries Inverter Cabinet • Open the box and inspect all contents to ensure all items in the box are undamaged. REV 1.1 10/26/2023...
-
Page 4: Installing Base
Installing Base • Place the battery cabinet of the KiloVault Uniti onto the base. Using the ten bolts provided secure the Battery cabinet to the base. Prepare the required parts. Tighten the screws. Install the man body to the base. -
Page 5: Installing The Top Cabinet
Installing the top cabinet Tighten the screws. Install the cable box to the top of the main body. Battery Compartment REV 1.1 10/26/2023... - Page 6 Installing the Batteries (Uniti Eco Freedom) STEP 4 Each level holds (4) HLX+ Batteries. Each Level are connected in series. Jumper Jumper Jumper • Ensure critical or primary load center is de-energized or disconnected. • Ensure AC source is de-energized or disconnected. •...
- Page 7 Install the side cover Attach the side cover to the main body. Secure the side cover using the provided screws. . Slide the front cover in. REV 1.1 10/26/2023...
- Page 8 Safety Breakers 120 VAC 15 Amp outlet. 120 VAC outlet Breaker. Light Breaker Battery String Breakers Load Breakers. Inverter Breakers. 120 VAC 15 Amp outlet. Negative Busbar Positive Busbar REV 1.1 10/26/2023...
- Page 9 Unit Eco Freedom Basic Inverter Settings. 01 Output Source Priority PV priority mode, switching to the Mains when the PV fails or the battery is lower than the set value of the parameter. 02 Output Frequency 60.0 Hz 03 AC Input Voltage Range Wide mains input voltage range of 230V Machine: 90~280V Mains input voltage range of 230V machine: 90~280V 04 Battery Power to Utility Setpoint...
-
Page 10: Inverter Settings
Inverter Settings 06 Charge source priority 10 Battery Absorption charge time SNU Default 5 Minutes PV and Mains hybrid charging: PV charging is a priority, and when the PV energy is insufficient, the Mains charging supplements. 11 Battery float charge voltage When the PV energy is sufficient, the Mains charging stops. - Page 11 KiloVault* LLC KiloVault® Uniti Series Pre-wired energy storage system 330 Codman Hill Road Boxborough, MA 01719 +1(888)218–5924 info@kilovault.comwww.kilovault.com...
- Page 12 KiloVault Uniti USERS GUIDE...
