Unit Connection Technology WS037C User Manual

Professional wireless weather station
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WS037C Professional Wireless Weather Station
User Manual
1.Introduction
Thank you for your purchase of the Professional Wireless
Weather Station. The following user guide provides step by
step instructions for installation, operation and troubleshooting.
2.Warnings and Cautions
Warning: Any metal object may attract a lightning strike,
including your weather station mounting pole. Never install the
weather station in a storm.
Warning: Installing your weather station in a high location
may result in injury or death. Perform as much of the initial
check out and operation on the ground and inside a building or
home. Only install the weather station on a clear, dry day.
3.Getting Started
The professional weather station consists of a display console,
a sensor array with Integrated Outdoor Sensor, and mounting
hardware.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WS037C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Unit Connection Technology WS037C

Summary of Contents for Unit Connection Technology WS037C

  • Page 1 WS037C Professional Wireless Weather Station User Manual 1.Introduction Thank you for your purchase of the Professional Wireless Weather Station. The following user guide provides step by step instructions for installation, operation and troubleshooting. 2.Warnings and Cautions Warning: Any metal object may attract a lightning strike, including your weather station mounting pole.

  • Page 2: Parts List

    3.1 Parts List The weather station consists of the following parts (as referenced in Figure 1 ). Item Image Display Console Frame Dimensions (LxHxW): 7.6x5.5x1.1inch (193X140X28mm) LCD Dimensions (LxW): 6.3x 3.7inch (160X93mm) 3.4 Display Console 3.4.1 Layout of Display Console The following illustration shows the segment of LCD display for feature description purposes only in Figure 7.
  • Page 3 Figure 7 1) Outdoor temperature 12) Outdoor temperature display change indication 2) Outdoor humidity HI/LO 13) Outdoor dew point and alarm feels like temperature display 3) Channel 1-8 indicator 14) Temperature units (°F 4) Outdoor humidity display or °C) 5) WIFI network 15) Weather forecast 6) Indoor temperature display 16) Rainfall units of measure...
  • Page 4 BL ON will display in the time area for three seconds when powered up. Conversely, The AC OFF icon will display . Note: It is recommended to plug in the power adapter to reduce the battery consumption and extend the service life. 2.

  • Page 5: Sensor Operation Verification

    Replace the battery door, and unfold out the desk stand to place the console in the upright position. Note: The battery is a back-up of weather station console, saving console settings when powered off from adaptor 3.4.3 Connect Sensor with Display Console Once the display console is powered up, it will automatically scan all the nearby Integrated Outdoor sensors.

  • Page 6: Display Console Operation

    The following steps verify proper operation of the sensors prior to install the sensor array. 1. Verify proper operation of the rain gauge. Tip the Integrated outdoor sensor back and forth several times. You will heard a “ticking” sound within the rain gauge. Verify the rain reading on the display console is not reading 0.00.

  • Page 7: Set (Program) Mode

    Note: To exit the Quick Display Mode at any time, press the SNOOZE/LIGHT key of the display console. While in Normal Mode, press (do not hold) the SET key to enter the Quick Display Mode as follows: once for time, time/week and second Twice for rainfall three for pressure four for sensor temperature...
  • Page 8 Note: In the Set mode, press the CHANNEL/+ key or MAX/MIN/- key to change or scroll the setting value. Hold the CHANNEL/+ key or MAX/MIN/- key for three seconds to increase/decrease rapidly. Note: To exit the Set mode at any time, press the SNOOZE/LIGHT button of the display console.
  • Page 9 8. Max/Min Clearing (default: ON). Press the SET key again to set the Max/Min clearing mode (CLR). The Max/Min can be programmed to clear daily (at midnight) or manually. Press the CHANNEL/+ key or MAX/MIN/- key to switch between ON (Clears 24h) and OFF (Manually).

  • Page 10: Sensor Search Mode

    icon of Sunny, Cloudy, Partly Cloudy or Rainy. (For detailed information of this part please refer to 10.2) 15. Time SYNC(default:ON). Press the SET key again to set the network time sync. Press the [+] key or [-] key to switch between SYNC time ON and SYNC time OFF of measure.

  • Page 11: Snooze Mode

    Press the MAX/MIN/- key for three seconds to clear all Max values.(Rainfall, wind gust and average, pressure, temperature and humidity maximum values). Press the SNOOZE/LIGHT key to exit the min/max checking and clearing mode, return to normal display mode. Note: The Maximum values will display the current values after reset.

  • Page 12: Backlight Mode

    Press any key (MAX/MIN/-, SET, ALARM, CHANNEL/+) to permanently exit the Snooze mode. 7.6 Backlight Mode 7.6.1 Adjustable Brightness of Backlight 1. There are 3 levels of brightness of display backlight. When the backlight is on, press SNOOZE/LIGHT key to switch between the 3 levels.
  • Page 13 The weather station includes the following alarms: Time (Alarm 1 and Alarm 2) Outdoor Dew Point Wind Gust Hourly Rainfall Wind Average 24 Hour Rainfall Outdoor Temperature Absolute Pressure Outdoor Humidity Relative Pressure Outdoor Feels Like Indoor Temperature 8.1 Alarm Triggered Temperature Indoor Humidity 8.1 Alarm Triggered...

  • Page 14: Setting The Alarms

    Press ALARM key again to return to normal mode. Note: Press the SNOOZE/LIGHT key at any time to return to the normal mode in HI/Low alarm mode. 8.3 Setting the Alarms Press ALARM key to enter the alarm mode. Press and hold the SET key for three seconds. The first alarm parameter will begin flashing (alarm hour).
  • Page 15 22.Indoor temperature low alarm Relative pressure HI alarm 23.Indoor humidity HI alarm 20.Relative pressure low alarm 24.Indoor humidity low alarm 21.Indoor temperature HI alarm Note: To prevent repetitive temperature alarming, there is a 0.9 °F(0.5°C) tolerance band. For example, if you set the high alarm to 80.0°F(26.7°C) and silence the alarm, the alarm icon will continue to flash until the temperature falls below 80.0°F (26.7°C), at which point, the alarm will reset and must increase...
  • Page 16 In normal mode, press and hold the ALARM key for three seconds to toggle the BZ ON (beeper on) or BZ OFF (beeper off) depending on the current setting. Display console return to normal mode without any operation in three seconds. 9.
  • Page 17 internet, radio, television or newspapers. They are in a different location and typically update once per hour. The purpose of your weather station is to measure conditions of your surroundings, which vary significantly from location to location. The profession weather station supports up to eight remote thermo-hygrometer sensors.
  • Page 18 In normal mode, press and hold the SET and MAX/MIN/- keys at the same time for five seconds to enter into the humidity calibration mode. The indoor humidity will begin flashing. Press the CHANNEL/+ key or MAX/MIN/- key to increase or decrease the humidity reading (in increments of 1%).
  • Page 19 Press the SET key to skip over a parameter to the next. Absolute Pressure Calibration In the calibration mode, the “ABS” symbol will display at the pressure section, the absolute pressure value will flash. (The default value is 0.00 inHg) Press the CHANNEL/+ key or MAX/MIN/- key to increase or decrease the absolute pressure value (in increments of 0.01 inHg).
  • Page 20 Press the ALARM key to reset current value. Example: The calibrated pressure sources measure 25.00 inHg. The display console pressure reads 24.85 inHg. Offset = 25.00 - 24.85 = 0.15 inHg Note: The display console displays two different pressures: absolute (measured) and relative (corrected to sea-level). To compare pressure conditions from one location to another, meteorologists correct the pressure to sea-level conditions.
  • Page 21 of Weather.com or Wunderground.com), and set your weather station to match the official reporting station. Wind Speed Calibration In the calibration mode, press the SET button twice and the wind speed value will flash (the default is 1.00). Press the CHANNEL/+ key or MAX/MIN/- key to adjust the wind speed calibration factor from 0.75 to 1.25, where: Calibrated Wind Speed = Calibration factor x Measured Wind Speed...
  • Page 22 In addition to installation challenges, wind speed bearings (any moving part) wears over time. To correct for wear, the correction value can be increased until the wind cups must be replaced. Without a calibrated source, wind speed is a difficult parameter to measure.

  • Page 23: Weather Forecasting

    to calibration. 10.Other Features of Display Console 10.1 Weather Forecasting Note: The weather forecast or pressure tendency is based on the rate of change of barometric pressure. In general, when the pressure increases, the weather improves (sunny to partly cloudy) and when the pressure decreases, the weather degrades (cloudy to rain).

  • Page 24: Moon Phase

    Pressure is falling and the previous condition is sunny Partly or Pressure is Cloudy rising and the previous condition is cloudy Pressure is falling and the previous condition is partly Cloudy cloudy or Pressure is rising and the previous condition is rainy.

  • Page 25: Feels Like Temperature

    10.4 Feels Like Temperature 10.4.1 Feels Like Temperature Feels like temperature is a combination of Heat Index and Wind Chill. 1. Temperatures less than 4.4°C(40°F), the wind chill is displayed, as shown in the National Weather Service Wind Chill Table below:...
  • Page 26 2. Temperatures greater than 26.7°C(80°F), the heat index is displayed, as shown in the National Weather Service Heat Index Table below:...

  • Page 27: Pressure Threshold Setting

    10.5 Pressure Threshold Setting The pressure threshold (the negative or positive rate of change of pressure signifying a change in the weather) can be adjusted from 2 hPa to 4 hPa (default level 2 hPa). The lower the level pressure threshold setting, the higher sensitivity for weather forecast changes.
  • Page 28 Modifications not expressly approved by this company could void the user's authority to operate the equipment. Statement according to FCC part 15.105: NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
