Onview Main Menu - ViewSonic ViewPanel VP151 User Manual

To save changes and exit Main Menu, press the [1] button
®
OnView Main Menu
The following steps show how to access the Main Menu, Submenus, and controls
within each Submenu. Details on the controls follow the steps listed below.
NOTE: Main menu shown below and menus on following pages are available only when
connected to an analog source. Digital source uses only the brightness control on
ViewPanel head (see page 10 for location of brightness control).
Base control buttons
Button
mutes the
audio
Button
reduces
volume
1
Press the [1] button to display the Main Menu shown below.
2
Press the [M] or [L] button to scroll to the desired menu option.
3
Press the [2] button to select the menu option.
4
Press the [M] or [L] button to select submenu option.
5
After making adjustments, press the [2] button to save changes and exit the
screen.
Contrast adjusts foreground white level of screen image.
[L] increases contrast, [M] decreases contrast.
Shortcut: Before displaying the OnView menu, press the [M] or [L] button to adjust.
Press button [2] to toggle between brightness and contrast.
Brightness adjusts background black level of screen image.
[L] increases brightness, [M] decreases brightness.
ViewSonic VP151 ViewPanel
Button [1]
displays main
Button
menu
increases
volume
[L] or [M] scroll up
and down main menu
to highlight control for
adjustment
®
Button [2] activates
control screen for
highlighted control,
and toggles between
two digital inputs
Operation
E
N
G
L
I
S
H
11
