ViewSonic ViewPanel VP140 Specifications page 2

ViewSonic
• Anti-static, anti-glare screen
This screen treatment refracts unwanted
light away from the user while
maintaining the highest image quality.
•
®
Fully supports the Microsoft
auto-installation standard for easy,
trouble-free configuration and setup.
®
• TCO '99 and E S certified
NERGY TAR
This monitor complies with the world's
strictest standards of low radiation,
safety, ergonomics, recycling and power
management while saving costs through
automatic power saving modes.
®
• Kensington security port
Kensington security port protects your
assets.
• Three year limited warranty
ViewSonic Corporation's QMS&EMS has been registered
to ISO 9001 & ISO 14001 by the British Standards Institution.
*Wall mount accessories are optional. Designed for easy wall mount configuration with any optional third-party wall mount kit to meet VESA wall mount specifications. **Leading non-captive monitor brand: Stanford Resources, Inc. (Monitrak 2000). †Free universal
Mac® adapter avaiable. Specifications subject to change without notice. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2001 ViewSonic Corporation. All rights reserved. [10332-01B 09/01_0M] VS-224
®
VP140
14.1" VIEWABLE COLOR TFT LCD DISPLAY WITH TCO '99
LCD
INPUT SIGNAL
COMPATIBILITY
CONNECTOR
POWER
USER CONTROLS Basic
VIDEO INPUT
OPERATING
®
Windows
CONDITION
DIMENSIONS
WEIGHT
OTHER
REGULATIONS
POWER MANAGEMENT
WARRANTY
Vi e w P a n e l
LCD Display
Type 14.1" viewable TFT active matrix ViewPanel
Viewing Angle 100˚ Horizontal, 60˚ Vertical (typ)
Pixel Pitch 0.279mm (H) x 0.279mm (V)
Contrast Ratio 250:1 (typ)
Color Depth 6-bits/color (16.7 million colors)
Backlight N= 2CCFT (Cold Cathode Fluorescent Tube)
Backlight Life 50,000 hrs (typ)
Glass Surface Anti-glare hard coat
Video RGB Analog (0.7/1Vp-p, 75 ohms)
Sync H/V separate (TTL) composite, sync on green
Frequency fh: 30-62kHz, fv: 50-75Hz
PC VGA up to 1024 x 768 non-interlaced
Mac ® † 640 x 480 up to 1,024 x 768
Signal 15-pin mini D-sub (detachable cable)
Power External AC/DC adapter with 3-pin AC Plug (CEE22)
Voltage AC 100-240 VAC 50-60Hz (auto switch) adapted
to 12VDC
Consumption 38W (max)
1, down, up, 2, power
OnView ® Contrast, brightness, auto sync, H/V OSD position,
ViewMatch ® color, LCD adjust, H-size, H-position,
FineTune, background, smoothing, ViewMeter
language, recall
Bandwidth 100MHz (typ)
Temperature 32˚F to 104˚F (0˚C to 40˚C)
Humidity 10-90% (no-condensation)
Physical 390mm (W) x 372mm (H) x 138mm (D)
15.3" (W) x 14.6" (H) x 5.4" (D)
Net 5.5KG (12.1lbs)
DDC1, DDC2B, detachable base,
Kensington lock recepticle
UL, CSA, CB, CE, FCC-B, DOC-B, TUV/GS, Energy Star
TCO '99, Energy 2000, VCCI, BSMI, ISO13406-2,
NEMKO, SEMKO, DEMKO, FIMKO, B-MARK, SASO,
CCIB, KMI
Meets Energy Star
Energy 2000 standards
Three year limited warranty on parts and labor.
Three year on backlight.
381 Brea Canyon Road, Walnut, CA 91789
Phone (800) 888-8583 • (909) 444-8888
Fax (909) 839-7922 • ViewSonic.com
®
S e r i e s
® ,
®
,
® ®
, VESA DPMS, and TCO and
