Summary of Contents for Ortofon 2MR Red
- Page 2 Technical specifications Model Blue Bronze Black Black LVB 250 Mono Output voltage at 1 kHz, 5 cm/sec. 5.5 mV 5.5 mV 5 mV 5 mV 5 mV 4 mV 4 mV Tracking ability at 315 Hz 70 µm 80 µm 80 µm 80 µm 80 µm...
- Page 3 Thank you for choosing an Ortofon 2MR cartridge. The 2MR cartridges are high- performance moving magnet phono cartridges with premium sound reproduction. At Ortofon, we have been working with sound reproduction since 1918. We developed the first phono cartridge in 1948, and since then, more than 300 different phono cartridges have been developed and manufactured.
- Page 4 Mounting the 2MR cartridge 1. It is recommended to keep the stylus guard on the stylus when mounting or 3. Secure the cartridge to the tonearm using a pair of screws enclosed in the packaging. dismounting the unit. Avoid overtightening the screws, as they may become stuck in the threaded holes of the mounting plate.
- Page 5 Stylus guard 24.0 mm Remove the stylus guard before use by holding at the front and rear of the guard and gently pressing the rear while tilting it downwards (Fig. 2-3). M2.5 mm 18.5 mm Fig. 2 Fig. 3...
- Page 6 Stylus care and maintenance Warning To obtain optimal sound The product is a phono cartridge only intended for mounting on tonearms, it must not be reproduction, remove dust used for any other purposes. from the stylus regularly by using a stylus brush (Fig.
- Page 7 Scan and follow the QR code for setup information (www.ortofon.com/support). Ortofon A/S | Stavangervej 9 | DK-4900 Nakskov support@ortofon.dk | www.ortofon.com...
