INSTALLATION MANUAL
AIR CONDITIONER
* Please read this installation manual completely before installing
the product
* Installation work must be performed in accordance with the natinal wiring
standards by authorized personnel only.
* Please retain this installation manual for future reference after reading it
thoroughly
TYPE : FLOOR STANDING TYPE
Model : HP-C3063EC0,HP-C306KA0
HP-C366TA0,HP-C508TA1,HP-C608TA0
P/NO : 3828A20896E
www.lge.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HP-C3063EC0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LG HP-C3063EC0

  • Page 1 * Installation work must be performed in accordance with the natinal wiring standards by authorized personnel only. * Please retain this installation manual for future reference after reading it thoroughly TYPE : FLOOR STANDING TYPE Model : HP-C3063EC0,HP-C306KA0 HP-C366TA0,HP-C508TA1,HP-C608TA0 www.lge.com P/NO : 3828A20896E...
  • Page 2: Table Of Contents

    Floor Standing Type Air Conditioner Installation Manual TABLE OF CONTENTS OUT-LINE OF INSTALLATION Safety Precautions..................3 Installation Tools ....................6 Installation of Indoor, Outdoor Unit ............. 7 1) Selection of the best location..........................7 2) Indoor Unit Installation ............................10 3) Outdoor unit installation ............................10 4) Refrigerant amount ..............................10 5) Installation method procedure..........................11 6) Preparation of installation parts and tools ......................12...
  • Page 3: Safety Precautions

    Safety Precautions Safety Precautions To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring instruction will cause harm or damage. The seriousness is classified by the following indications. WARNING This symbol indicates the possibility of death or serious injury.
  • Page 4 Safety Precautions Do not modify or extend the power cable. Be cautious when unpacking and installing the product. • There is risk of fire or electric shock. • Sharp edges could cause injury. Be especially careful of the case edges and the fins on the condenser and evaporator.
  • Page 5 Safety Precautions CAUTION Installation Always check for gas (refrigerant) leakage after Install the drain hose to ensure that water is installation or repair of product. drained away properly. • Low refrigerant levels may cause failure of • A bad connection may cause water leakage. product.
  • Page 6: Installation Tools

    Installation Installation Installation Tools Figure Name Figure Name Screw driver Ohmmeter Electric drill Hexagonal wrench Measuring tape, Knife Ammeter Hole core drill Gas-leak detector Thermometer, Spanner Horizontal meter Torque wrench Flaring tool set Manifold gage Vacuum pump R-22 Floor Standing type Air Conditioner...
  • Page 7: Installation Of Indoor, Outdoor Unit

    Installation of Unit Installation of Unit Selection of the best location 1. Indoor unit • There should not be any heat source or steam near the unit. • There should not be any obstacles to prevent the air circulation. • A place where air circulation in the room will be good.
  • Page 8 3) Select a well-drained place. 1. If you can’t meet above guide line in the seaside installation, please contact LG Electronics for the additional anticorrosion treatment. 2. Periodic ( more than once/year ) cleaning of the dust or salt particles stuck on the heat exchanger by using water...
  • Page 9 PIPE SIZE MODEL Length Elevation GAS SIDE LIQUID SIDE A (m) B (m) HP-C306KA0 5/8" 1/4" 5/8 " 1/4" HP-C3063EC0 5/8 " HP-C366TA0 3/8" 3/4" 3/8" HP-C508TA1 1/2" HP-C608TA0 3/4" Indoor unit Outdoor unit CAUTION: • Capacity is based on standard length and maximum allowance length is on the basis of reliability.
  • Page 10: Indoor Unit Installation

    HP-C306KA0 30g/m subject to 7.5m piping length. (The rated amount of refrigerant is indicated on the name 50g/m HP-C3063EC0 plate.) But when the piping length exceeds 7.5 40g/m HP-C366TA0 meters, additional charge is required according to the following table.
  • Page 11: Installation Method Procedure

    Installation of Unit Installation method Installation works Descriptions Preparation of tools and installation parts Preparation of installation Flaring the pipes To insert the flare nuts, mounted on the connection parts of both indoor and outdoor unit, onto the copper pipes. Pipe bending To reduce the flow resistance of refrigerant.
  • Page 12: Preparation Of Installation Parts And Tools

    Installation of Unit Preparation of installation parts and tools Installation Parts, Tools Flaring tool ( Ø 6.35 - Ø 19.05) Flaring the pipes Remear Remove burrs from cut edges of pipes. Pipe cutter (MAX 35mm Copper pipe) Cutting the pipings Wrench (H5, H4 hexagonal wrench) To open the service valve Pipe bender...
  • Page 13: Preparation Of Piping

    Installation of Unit Preparation of Piping Main cause of gas leakage is defect in flaring work. Carry out correct flaring work in the Copper following procedure. Slanted Uneven Rough tube 90 ° 1. Cut the pipes and the cable. • Use the accessory piping kit or the pipes purchased locally.
  • Page 14: Connection Of Piping

    Installation of Unit Connection of piping 1. Move the indoor tubing and drain hose to the hole • Remove tubing holder and pull the tubing out of the chassis. 2. Replace the tubing holder into original position 3. Route the tubing and the drain hose staight backwards. 4.
  • Page 15: Connecting The Cable To The Indoor Unit

    1. Open the inlet grille manually.(Fig.1) 2. Open the terminal block cover with driver . 3. Connect the cables(LG doesn't sypply) to the Terminal Block in the front Bracket. (Fig.2) 4. Secure the terminal block cover to the original position with the screw.
  • Page 16: Connecting The Piping To The Outdoor Unit

    Installation of Unit Connecting pipings to the outdoor unit 1. Align the center of the pipings and sufficiently tighten the flare nut with fingers. 2. Finally tighten the flare nut with torque wrench until the wrench clicks. • When tightening the flare nut with torque wrench, ensure the direction for tightening Gas side piping follows the arrow on the wrench.
  • Page 17: Power Supply And Wiring

    Installation of Unit Power supply and Wiring The unit is completely wired internally at the Voltage factory according to general rule of electrical technology, but local rules, if they are required, Power source voltage should be complied with. working voltage 1.
  • Page 18: Vacuum Drying Of The Connecting Pipes And The Indoor Unit

    Installation of Unit Vacuum Drying of the Connecting Pipes and the Indoor Unit The air which contains moisture remaining in the refrigeration cycle may cause a malfunction on the compressor. 1. Confirm that both the liquid side valve and the gas side valve are set to the closed position. 2.
  • Page 19: Form The Pipe

    Installation of Unit Form the Piping 1. Wrap the connecting portion of indoor unit with the insulation material and secure it with two Plastic Bands. (for the right piping) • If you connect an additional drain hose, Gas side the end of the drain-outlet should be kept piping distance from the ground.
  • Page 20: Final Check And Test Run

    Final Check and Test Run Final Check and Test Run After installing the unit, perform the final check Running test should be accomplished as follows: and running test as follows: Final check points 1. Set operation switch at "FAN" and the fan 1.
