OPERATING INSTRUCTION
Electric Fence Energizer
Read full instructions before use!
Direct connection of the 110v Battery Recharger/
Power Supply in the DC2.1 socket of the front of
the top case
made in Germany
by horizont group gmbh
Animal Care
Solar IntelliShock SIS 100 ( 15W / 12Ah )
Voltage at no load:
max. 14000v
Voltage at 500 Ω
(animal contact):
max. 5000v
Requirements:
The energizer complies with the International
Safety Standard IEC 60335-2-76 +
EN 60335-2-76.
85545A 09/2023
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Premier Solar IntelliShock SIS 100
Summary of Contents for Premier Solar IntelliShock SIS 100
- Page 1 Electric Fence Energizer Read full instructions before use! made in Germany by horizont group gmbh Animal Care Solar IntelliShock SIS 100 ( 15W / 12Ah ) Voltage at no load: max. 14000v Voltage at 500 Ω (animal contact): max. 5000v...
-
Page 2: Spare Parts
Right Solar Bracket 87099 Left Solar Bracket 87098 Soft Grip SIS100: 84678MV 84793 Top Case 87101BLDC DC2.1 socket 606853 PCB: Solar IntelliShock SIS 100 60876 Solar Module with Bra- ckets and Solar Leads: SIS100: 60859 Black Ground On/Off Terminal Knob:... - Page 3 battery Solar Panel Solar IntelliShock SIS100 Solar Leads: 60812 Solar Panel knob: 91820 Rubber Buffer: 81051 Battery Leads: 60809 Battery Connection Leads: 60818 12V/12Ah 121600...
- Page 4 Solar Panel knob 91820 Right Solar Bracket 87099 Bracket Screws 94581 Left Solar Bracket 87098 Connecting sheets 87393 87394 Solar Module with Brackets and Solar Leads SIS 100 / 15W 60859 Wiring Harness 110v Battery Recharger / Power Supply Adapter : 1132007 130800 Ground Link...
- Page 5 Fig. 1 For recharging 12v battery only Attach the 110v Battery Recharger/Power Supply Adapter to the energizer (indoors without fence and earth connection) in the DC2.1 socket in the front of the top case. To use energizer connected to 110v 1.
-
Page 6: Installation And Connection
INSTALLATION AND CONNECTION Fig. 2 Attach negative battery lead to battery. Make sure all other connections are tight. 12V/12Ah IntelliShock SIS100 only: 121600 Remove ground U-Spike. 1. Rotate solar panel angle according to diagrams page 8. 2. Secure panel knobs to tighten on both sides. - Page 7 INSTALLATION AND CONNECTION Solar Intellishock SIS100 for soft soils (5a + 6a for hard soils) 5 + 5a: Included (step-in) U-Spike Ground Stake (combination Ground Rod and support stand). 6 + 6a: Slide energizer onto the U-Spike and position the energizer so that the solar panel faces due south.
-
Page 8: Warranty
Allow solar panel to fully charge battery before use. Battery may have discharged Fig. 3 during storage and transport. Battery Power & Control Button should test 12.6 volts or higher. ON / OFF Make sure panel always faces due south. See diagram below for proper angle. - Page 9 A. OPERATING INSTRUCTION FOR ELECTRIC FENCE ENERGIZER Solar IntelliShock 100 WORKING PRINCIPLE: The solar panel produces electric current when exposed to usable sunlight.The fence energizer requires a constant current, day and night. Thus the panel current is stored in the battery which delivers the energizer current. The solar panel might not always be capable of recharging the battery—especially in dark, grey and foggy months (i.e.
- Page 10 BATTERY INDICATION (FIG. 3 + 4): Test battery only at daybreak. If the battery test light is flashing red/green, recharge the battery. The battery should never fall below a 20% charge (continuous red light). If this happens, permanent damage may occur to the battery. Please note, that these values can vary due to the dependence of the battery itself, the age of the battery, the temperature (capacity) and mesuring deviation (tension).
- Page 11 B. SAFETY GUIDELINES ELECTRIC ANIMAL FENCES PART 1: PRINCIPLES AND LIMITATIONS OF ELECTRIC FENCING FOR ANIMALS An electric fence consists of an energizer and a connected fence where the energizer feeds electric impulses into the fence. The electric animal fence represents a “psychological barrier” for the animals; it keeps animals inside or outside a certain area, it can also be used to train a certain behaviour (e.g.
- Page 12 Read Annex BB.1 of the International Safety Standard IEC 60335-2-76 + EN 60335-2-76 (s. page 10) ANNEX BB.1: Electric animal fences and their ancillary equipment shall be installed, operated and maintained in a manner that minimises danger to persons, animals or their surroundings. WARNING: Do not touch the fence with the head, mouth, neck or torso.
- Page 13 Electric animal fences intended for deterring birds household pet containment or training animals such as cows need only be supplied from low output energizers to obtain satisfactory and safe per- formance. In electrical animal fences intended for deterring birds from roosting on buildings no fence wire shall be grounded if the fence wires are not connected to metal parts.
- Page 14 SAFETY GUIDELINES ELECTRIC ANIMAL FENCES - To Reduce Risk and Liability ... REMEMBER: Never touch an electric fence wire with your head or upper torso (see photo at right). Never allow anyone else to do so. Instruct all visitors and children to never do so.
-
Page 15: Technical Data
IntelliShock ~ 12100 v ~ 5000 v ~6400 v ~ 3400 v joules 14000 v mA/hr SIS100 MAX. FENCE LINE LENGTH Solar IntelliShock SIS 100 = 5-8 Rolls Solar IntelliShock SIS100 = 1,5 mile SUBJECT TO TECHNICAL ALTERATIONS ! - Page 16 assembled in US and Europe horizont group gmbh Animal Care...
