Optiquest
Q110
Q110
21" (20.0" viewable) HIGH RESOLUTION COLOR MONITOR
CRT Type
Dot Pitch
Phosphor
Glass Surface
INPUT SIGNAL Video
Sync
Frequency
COMPATIBILITY PC
® *
Mac
CONNECTOR Signal
Power
POWER Voltage
Consumption
USER CONTROLS Buttons
OnView ®
VIDEO INPUT Bandwidth
MISCONVERGENCE
DISPLAY AREA Factory Setting 390mm (H) x 292mm (V) (typ)
Maximum Scan 400mm (H) x 300mm (V)
OPERATING Temperature
CONDITION Humidity
DIMENSIONS Physical
WEIGHT
Net
OTHER
REGULATIONS
POWER MANAGEMENT
WARRANTY
381 Brea Canyon Road, Walnut, CA 91789
( 800 ) 888-8583
(909) 869-7976
•
Fax (909) 468-1202 Internet: www.ViewSonic.com
•
*Free universal Mac cable adapter available. Copyright © 2000, ViewSonic Corporation. All rights reserved. Corporate names and trademarks
stated herein are the property of their respective companies. Specifications subject to change without notice. The EPA only promotes energy
efficiency and does not endorse any particular company or product.
®
Monitor
Monitor
21" (20.0" diagonal viewable area)
90 ˚ deflection
0.21mm Horiz., 0.14mm Vert., 0.25mm Diagonal
RGB medium persistance
Tint (TM=52.5%), Anti-static, anti-glare coating
RGB Analog (0.7V/1.0p-p, 75 ohms)
H/V separate (TTL)
F h :30-97kHz, F v :50-160Hz
IBM ® PC and compatibles
(from VGA up to 1,600 x 1,280 non-interlaced)
Power Mac ™ (up to 1,600 x 1,200)
15-pin mini D-sub (detached cable)
3-pin plug (CEE22)
AC 100–240VAC (auto switch)50/60 (+/-3)Hz
125W (typ)
Power, OSD, Up Arrow, Down Arrow, Adjust +/-
Contrast, brightness, H/V-position, H/V-size, side
pincushion, pin-balance, trapezoid, degauss,
color control, language, parallelogram, tilt,
H/V moiré, OSD position, degauss, memory recall
210MHz
0.25mm (max) at center
0.35mm (max) at corner
32 ˚ F to 104 ˚ F (0 ˚ C to 40 ˚ C)
5% to 95% (no condensation)
513mm (W) x 577mm (H) x 510mm (D)
(20.2" x 22.7" x 20.1")
31.0Kg (68.2 lbs.)
DDC1, DDC2B, made in the Philippines
UL, CSA, FCC-B, DHHS, DOC, TUV, PTB, MPR-II,
CE, E S ® , ISO9241-3
NERGY TAR
Meets E S , VESA ® DPMS ™
NERGY TAR ®
standards
Three year limited warranty on CRT, parts and labor.
48 hour Express Exchange ® service option available.
ViewSonic
ViewSonic
Powered by
ViewSonic Coporation's QMS/EMS has been registered to ISO
9001 & ISO 14001 by the British Standards Institution.
Features & Benefits
1,600 x 1,200 resolution
Displays a maximum resolution of 1,600 x
1,200; 1,280 x 1,024 at 90Hz flicker-free
refresh rate for easy viewing.
1,600 x 1,200 @ 77Hz
1,280 x 1,024 @ 90Hz
1,024 x 768 @ 118Hz
800 x 600 @ 149Hz
®
OnView controls
All screen adjustments are made via an
on-screen menu using simple controls. The
user can adjust color temperature and individual
color intensity for screen-to-print matching.
Anti-static, anti-glare screen
This anti-static, anti-reflection screen coating
refracts unwanted light away from the user
while maintaining the highest quality of the
displayed image.
High contrast screen
Ergonomically designed to provide full image
with minimal glare/distortion on edges and
corners. Displayed images remain true in size
and proportion throughout the screen.
Fully supports the Microsoft
Windows 98 auto-installation standard for
easy, trouble-free configuration and set-up.
and MPR-II
®
®
® Windows 95 and
