ViewSonic Optiquest Q190mb User Manual

High-resolution multi-scan color monitor
Hide thumbs Also See for Optiquest Q190mb:
Table of Contents

Advertisement

Quick Links

Q190mb
LCD Display
Q190mb
L91C
Q190mb-1

Advertisement

Table of Contents
loading

Related Manuals for ViewSonic Optiquest Q190mb

Summary of Contents for ViewSonic Optiquest Q190mb

  • Page 1 Q190mb LCD Display Q190mb L91C Q190mb-1...

  • Page 2: Operation Instructions

    FCC RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: (FOR FCC CERTIFIED MODELS) This monitor has been tested and found compliant with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide proper protection against harmful interference to a residential installation.

  • Page 3: Table Of Contents

    Content Safety Precautions ...1 First Setup...2 Front Panel Control ...3 Installation ...3 Using OSD Functions ...4 Supporting Timing modes ...12 Technical Information ...13 Care and Maintenance ...14 Troubleshooting ...14...

  • Page 4: Safety Precautions

    This monitor is manufactured and tested on a ground principle that a user’s safety comes first. However, improper use or installation may result danger to the monitor as well as to the user. Carefully go over the following WARNINGS before installation and keep this guide handy.

  • Page 5: First Setup

    First Setup Congratulation for purchasing this monitor of high performance! This monitor comes with the following accessories : Video cable with 15 pin D-SUB connector. Power cable. ViewSonic Wizard CD-ROM Quick Installation 1. Connect video cable Make sure both the monitor and computer are powered OFF.

  • Page 6: Front Panel Control

    Front Panel Control ACTIVATE/EXIT OSD SCROLL DOWN/DECREASE SCROLL UP/INCREASE Installation ❼ POWER INPUT ❽ AUDIO INPUT ➒ ➓ VGA INPUT ❶ ❷ ❸ ❹❺➏ SELECT DESIRED FUNCTION LED INDICATOR POWER ON/OFF ❼ ❽ ➒ ➓...

  • Page 7: Using Osd Functions

    Using OSD Functions 1. Press the ① ① ① ① button to display the main menu shown below. 2. Press the ▲ or ▼ button to scroll to the desired menu option. 3. Press the ② ② ② ② button to select the menu option. 4.
  • Page 8 To adjust the foreground white level of screen image. Contrast : ▲ : increase contrast, ▼ : decrease contrast To adjust the background black level of screen image. Brightness : ▲ : increase brightness, ▼ : decrease brightness Provides four preset color adjustments: Color Adjust : 9300K, 6500K, 5400K, and User Color for improved brightness and color saturation.
  • Page 9 9300K--Adds blue to screen image for cooler white. 6500K--Adds to screen image for warmer white and richer red. 5400K--Adds green to screen image for a darker color. Individual adjustments for red (R), green (G), blue (B). User Color : 1. Press button ② ② ② ② to set adjustment and select next color to adjust. 2.
  • Page 10 Adjust Horizontal /Vertical Position ,H. Size, Fine Tune Image Adjust : and Sharpness. To adjust the horizontal and vertical position of the video. H./V. Position: H. Position: ▲ : moves screen to right, ▼ : moves screen to left. V. Position: ▲ : moves screen to up, ▼ : moves screen to down. Adjusts the width of screen image.
  • Page 11 To adjust the delay time. Fine Tune: Press ▼ or ▲ to adjust to user preference. Adjusts the clarity of a non-SXGA (1280x1024) signal. Sharpness : Press ▼ or ▲ button to adjust. To setting Language Select, Resolution Notice, OSD Setup Menu : Position , OSD Time Out and Input Select (Analog).
  • Page 12 Allows the user to choose from available languages. Language Select : There is a OSD message of "For best picture quality Resolution Notice : change resolution to 1280 x 1024" displayed on the screen after 30 seconds Powering ON or changing mode to lower resolutions (640 x 480/ 720 x 400 / 800 x 600/ 1024 x 768), if the function was "enable".
  • Page 13 Press the ❷ button to select the horizontal or vertical OSD Position : OSD position. Horizontal OSD Position horizontally repositions all OSD screens. ▲ moves OSD right, ▼ moves OSD left. Vertical OSD Position vertically repositions all OSD screen. ▲ moves OSD up, ▼ moves OSD down. Sets the length of time the Onscreen Display screen is OSD Time Out : displayed before exiting.
  • Page 14 When press Input Select change Input singnal to Analog Input Select : or Digital. Return the adjustments back to factory settings. Memory Recall : Press the button ② ② ② ② to select the Memory Recall menu option. Audio Menu: Volume: For adjust speaker output.

  • Page 15: Supporting Timing Modes

    VESA Warning : Do not set the graphic card in your computer to exceed these maximum refresh rates. Doing so may result in permanent damage to your monitor. 640 x 480 @ 60Hz 640 x 480 @ 72Hz 640 x 480 @75Hz...

  • Page 16: Technical Information

    Technical Information Technical Specification LCD Panel Power Management Displayable Resolution Pixel Dimension LCD Display Color Viewing Angle Tilt Contrast Ratio Brightness Response Time Active Display Area Temperature Compliance Power Speaker 19.0” TFT Energy Star compliant VESA DPMS compatible < 2 W SXGA 1280 x 1024 max.

  • Page 17: Care And Maintenance

    Avoid exposing your monitor directly to sunlight or other heat source. Place your monitor away from the sun to reduce glare. Put your monitor in a well ventilated area. Do not place anything heavy on top of your monitor. Make certain your monitor is installed in a clean and moisture-free area.
  • Page 18 Wrong or abnormal colors If any colors (red, green, blue) are missing, check the video cable to make sure it is securely connected. Loose or broken pins in the cable connector could cause an improper connection. Connect the monitor to another computer.
