Faro Barcelona TRAS 25 Quick Start Manual

NO
TEST
DRAINAGE to
DRENAJE hasta
6lt / 10min
Anticipate the condensation by running the device for an
hour without the glass. After this time, place the glass back
immediately. Only for outdoor private use: it is strictly
forbidden to use the luminary in public places.
i
Sizes Cotas
Ø200
80
Installation with recessed box
1
NO OK
Prever la condensación haciendo funcionar el aparato
durante una hora sin cristal. Volver a colocar el cristal
inmediatamente transcurrido este periodo. Uso exclusivo
exterior privado: está prohibida la utilización de la luminaria
en lugares de concurrencia publica.
i
Parts Partes
a
2
i Gravel height >25cm
TRAS 25
TECHNICAL FEATURES
OSLON SSL 25W 700mA 3000K CRI90 incl
Ref. 71716 1463lm13°
DRIVER MBTS
24Vdc 100V-240V
Available environment
Recessed
temperature -20º~40ºC
box
i
DRIVER MBTS IP67
b
24Vdc 100V-240V
a
b
3
Ref. 71717 1320lm 40º
LED
IP67 NO INCL
0,5m
H05RN-F
2
2x1mm
100-240V
24Vdc
DRIVER MBTS IP67
24Vdc 100V-240V
see www.faro.es
4
IK09
783Kg -7679N
IP67
