FRESER AT-600 Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AT-600
Model
Convection Oven
Operation Manual
Convection Oven
AT-600
Model
3.4KW
Power
230V/60Hz/1ph
Voltage
Fuse Protection
16A
Temperature
0-300℃
60 Kgs
Net Weight
Tray Size
440 x 345 mm
600Wx660Dx510H mm
Dimensions
FRESER INTERNATIONAL
email: info@freser.com.tw
web: www.freser.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AT-600 and is the answer not in the manual?

Questions and answers

Related Manuals for FRESER AT-600

Summary of Contents for FRESER AT-600

  • Page 1 AT-600 Model Convection Oven Operation Manual Convection Oven AT-600 Model 3.4KW Power 230V/60Hz/1ph Voltage Fuse Protection Temperature 0-300℃ 60 Kgs Net Weight Tray Size 440 x 345 mm 600Wx660Dx510H mm Dimensions FRESER INTERNATIONAL email: info@freser.com.tw web: www.freser.com...

  • Page 2: Table Of Contents

    Operating Instructions Convection Oven Atoll 600 GC-1000 ____________________________________________________________________ Table of Contents 1. Introduction ....................3 1.1 Basic Terms / Operating Elements ............3 1.2 12 Fixed Programs ................4 1.3 Technical Parameters................5 2. Working Parameters ................. 6 2.1 Write a Baking Program................. 6 2.2 Setting up Working Parameters .............

  • Page 3: Introduction

    Operating Instructions Convection Oven Atoll 600 GC-1000 ____________________________________________________________________ 1. Introduction 1.1 Basic Terms / Operating Elements 11 12 1. Key control ON/OFF 2. Ready for baking display 3. Door opening display 4. Time display 5. Temperature display 6. Display steam quantity / Program number 7.

  • Page 4: Fixed Programs

    Operating Instructions Convection Oven Atoll 600 GC-1000 ____________________________________________________________________ 1.2 12 Fixed Programs 11 12 1. Switch ON/OFF key Keep pressed for approx. 3 seconds. Once the oven is turned on, the LED light turns off. 2. Ready for baking. After temperature has reached the chosen temperature, OK sign is flashing.

  • Page 5: Technical Parameters

    Operating Instructions Convection Oven Atoll 600 GC-1000 ____________________________________________________________________ 10. Programming key for parameter / value input Set up baking programs when the LED light is flashing. 11. Circulating fan speed key 12. Warning light water shortage key If the water level in the water box is too low, the LED light in the key is flashing.

  • Page 6: Working Parameters

    Operating Instructions Convection Oven Atoll 600 GC-1000 ____________________________________________________________________ 2. Working Parameters 2.1 Write a Baking Program 1. Press “P” key. LED light flashes. Set up parameters. 2. Select a baking program 1 to 12 or select afterwards baking programs 13 to 30 with the lower arrow key [9].

  • Page 7: Setting Up Working Parameters

    Operating Instructions Convection Oven Atoll 600 GC-1000 ____________________________________________________________________ 2.2 Setting up Working Parameters 1. Press program key “P”. LED light flashes. Set up parameters. 2. Press function key “F”. 3. In the time display window appears this sign. Input password “0110”. 4.

  • Page 8: Oven Working Environment Temperature Check

    Operating Instructions Convection Oven Atoll 600 GC-1000 ____________________________________________________________________ number of temperature parameters. The higher the value, the slower the operation of PID. Temperature range setting up: 0: Double-digit control temperature mode Other values: Proportion temperature control or PID °C 0~99 proportion temperature control area.

  • Page 9: Touch Panel Display Check

    Operating Instructions Convection Oven Atoll 600 GC-1000 ____________________________________________________________________ 2.4 Touch Panel Display Check 1. Press program key “P”. LED light flashes. 2. Press function key “F”. 3. In the time display window appears this sign. Input password “0800”. 4. In the time display window appears the following sign.

  • Page 10: Input/Output Check

    Operating Instructions Convection Oven Atoll 600 GC-1000 ____________________________________________________________________ 2.6 Input/Output Check 1. Press program key “P”. LED light flashes. 2. Press function key “F”. 3. In the time display window appears this sign. Input password “0807”. 4. In the time display window appears this sign.

  • Page 11: Frequently Malfunction Warning Displays

    Operating Instructions Convection Oven Atoll 600 GC-1000 ____________________________________________________________________ 3. Press “START/STOP” key again. The output display’s light will correspond according to ON or OFF mode. The corresponding output will also turn into ON or OFF mode. The meaning of the corresponding display is as listed below.

  • Page 12: Short Circuit Warning

    Operating Instructions Convection Oven Atoll 600 GC-1000 ____________________________________________________________________ 3.2 Short Circuit Warning Malfunction reason: If power is cut off during baking time modus, switch on the control power supply. Malfunction elimination: Press “START/STOP” key to delete the warning code. 3.3 Baking Temperature Sensor Disconnection Warning Malfunction reason: The cable of the temperature sensor is not properly connected or is disconnected.

  • Page 13: Input And Output Program

    Operating Instructions Convection Oven Atoll 600 GC-1000 ____________________________________________________________________ 4. Input and Output Program 4.1 Input Program Door switch input: The LED light in the right upper corner lights up if the door is opened. When the door is closed, the LED light turns off. After opening the door all programs stop.

  • Page 14: Inside Parameters Setup

    Operating Instructions Convection Oven Atoll 600 GC-1000 ____________________________________________________________________ Lighting: Once the power supply switch is ON, the lights are flashing. Open the door: The door can be opened when the setup time has stopped or by pressing the door opening display key [3]. Unlock the oven door manually by pulling down the unlocking wire cable (located on the left at the front and at floor level of the oven).

  • Page 15: Renew The Inside Parameters According To Factory Settings

    Operating Instructions Convection Oven Atoll 600 GC-1000 ____________________________________________________________________ Opening door time interval: 0-9.9 sec. Factory setting: 2.0 Steaming time: 0-9.9 sec. Factory setting: 1.0 Steaming stop time interval: 0-9.9 sec. Factory setting: 1.0 Time interval between the end of steaming and restarting of the circulating fan: 0-99 sec.

  • Page 16: Proper Installation Circumstances

    Operating Instructions Convection Oven Atoll 600 GC-1000 ____________________________________________________________________ 6. Proper Installation Circumstances 1. No dust 2. No acidic gas 3. The oven has to be set up on an even and flat surface and should not be exposed to vibration. 4.
