ViewSonic G70mb Specifications page 2

ViewSonic
G70mb black case version
• OnView controls including ViewMatch
All screen adjustments are made via an on
screen menu using simple controls. ViewMatch
allows the user to adjust color temperature
and individual color intensity for screen-to-print
matching.
• ARAG screen treatment
®
This specially formulated anti-reflection, anti-glare
screen treatment uses a multi-layer process to
refract unwanted light away from the users
while maintaining the highest quality of the
displayed image.
• Headphone jack and external
microphone port
Easily accessible headphone and microphone
jacks give users the flexibility of adding external
multimedia devices.
• TCO '99 † and Energy 2000 certified
This monitor complies with the world's strictest
standards of low radiation, safety, ergonomics,
recycling and power management while saving
costs through automatic power saving modes.
•
ViewSonic Corporation's QMS\EMS has been registered
to ISO 9001 & ISO 14001 by the British Standards Institution.
*The optional ViewSonic USB hub (model VS-USB) can be purchased separately. **Free universal Mac
Copyright © 2000, ViewSonic Corporation. All rights reserved. Corporate names and trademarks stated herein are the property of their respective companies. Specifications subject to change without notice. As an E
ViewSonic has determined that this product meets the E
and other countries.
VSG70m_9/00_20k_rev1
VS-2101
®
G70m
17" (16.0" VIEWABLE) MULTIMEDIA COLOR MONITOR WITH
CRT
INPUT SIGNAL
COMPATIBILITY PC
CONNECTOR
POWER
USER CONTROLS Basic
VIDEO INPUT
AUDIO
MISCONVERGENCE
DISPLAY AREA
OPERATING
CONDITION
DIMENSIONS
WEIGHT
OTHER
REGULATIONS
POWER MANAGEMENT
WARRANTY
®
cable adapter available.
S ® guidelines for energy efficiency. Microsoft, Windows, Windows NT and the Windows logo are the registered trademarks of Microsoft Corporation in the United States
NERGY TAR
G S e r i e s Mul t i Med i a
Monitor
Type 17" (16.0" diagonal viewable area) 90˚ deflection
Dot Pitch 0.23mm Horizontal, 0.13mm Vertical, 0.27mm Diagonal
Phosphor RGB medium short persistance
Glass Surface Tint (TM=46%), ARAG
Video RGB analog (0.714Vp-p, 75 ohms)
Sync H/V separate (TTL)
Frequency F h :30-70kHz, F v :50-120Hz
Audio 1.0Vrms
IBM ® PC and PC compatibles (from VGA up to
1,280 x 1,024 non-interlaced)
**
®
Mac Power Mac ™ (up to 1024 x 768)
Video In 15-pin mini D-sub, (attached)
Audio In 3.5mm pin mini jack (stereo)
Mic In/Out 3.5mm pin mini jack (mono/auxillary)
Headphone Out 3.5mm pin mini jack (stereo)
Power 3-pin plug (IEC320)
Voltage AC 100-240VAC/50-60Hz (auto switch)
Consumption 95W (typ)
Power on/off, volume, +/-, mute, 1, up, down, 2
OnView ® Contrast, brightness, H/V-size, H/V-position,
pincushion, pin-balance, trapezoid, parallelogram,
tilt, moiré, ViewMatch
OSD position, language, audio, recall, zoom
Bandwidth 110MHz (typ)
Output 3W (x2) @ 1KHz, THD<=1%
Response 100Hz-20kHz +/-3dB
0.25mm (max) at center, 0.3mm (max) at corner
Factory Setting 310mm (H) x 230mm (V) (Dependent upon
Maximum Scan 320mm (H) x 240mm (V) signal timing used)
Temperature 32°F to 104°F (0°C to 40°C)
Humidity 5% to 95% (non condensing)
Physical 405mm (W) x 421mm (H) x 420mm (D)
(15.9" x 16.6" x 16.5")
Net 16.0Kg (35.2 lbs.)
DDC1 & DDC2B, GTF compliant
UL, CUL, DHHS, DOC-B, CB E
TCO '99 , Energy 2000, ISO 9241-3, TUV/GS,
†
EN60950, CE, BSMI, C-TICK, NEMKO, DEMKO,
SEMKO, FIMKO
Meets E S
NERGY TAR
and Energy 2000 standards
Three year limited warranty on CRT, parts and labor.
48 hour Express Exchange
381 Brea Canyon Road, Walnut, CA 91789
Phone (800) 888-8583 • (909) 869-7976
Fax (909) 468-1202 • Internet: www.ViewSonic.com
† Black case model TCO '95.
® screen treatment
® color, degauss, ViewMeter ® ,
S ® , MPR II,
NERGY TAR
® , VESA ® DPMS and TCO'99 †
® service option available.
S ® partner,
NERGY TAR
