- Page 1 INSTRUCTIONS FOR USB POWER STRIP RETRO-MOUNT FOR TOWER OR CORE 8/10, 12/16, OR 18/20 POWER SUPPLY: 100 - 250 VAC 50/60 Hz Output of up to 2.1A per port for sleep and charge. For devices with maximum power supply of 45W or less.
- Page 2 Failure to read these warnings or to follow the instructions below could result in personal injury or damage to your product that could void its warranty. • DO NOT PLUG POWERGISTICS TOWERS INTO OTHER TOWERS. MUST BE PLUGGED DIRECTLY INTO THE WALL OUTLET.
- Page 3 2. Widen the opening in the 1. Push out the grommet grommet and remove the from power cord hole in power cord. base of Tower. 3. Save grommet for 4. Ready power cord for later use. power strip removal. 201-389-9940 | www.PowerGistics.com...
- Page 4 Standard Power Strip #1 (with wide vertical plugins) 1. Remove nut and remove the ground wire. 2. Pop off the standard 3. Use a screwdriver to remove power strip from the the brackets from the top and brackets. bottom of the Tower spine. INSTRUCTIONS FOR USB POWER STRIP RETRO-MOUNT...
- Page 5 Standard Power Strip #2 (with narrow horizontal plugins) 1. Remove nut and remove the ground wire. 2. To remove the power strip, use a Phillips screwdriver to remove the screws at the top and bottom. 201-389-9940 | www.PowerGistics.com...
- Page 6 Attach USB power strip 1. Screw the new power strip to the spine at the top and bottom. INSTRUCTIONS FOR USB POWER STRIP RETRO-MOUNT...
- Page 7 Attach grounding wire 2. Screw the ground wire into the screw on the side of the spine. 201-389-9940 | www.PowerGistics.com...
- Page 8 3. Reinsert the grommet into Tower base hole. Plug power cord into wall outlet. 100 Continental Drive, Columbus, Wisconsin 53925 USA 201-389-9940 | www.PowerGistics.com PWRG 1144 Mounting Kit USB power strip INSTALL GUIDE REVA 2023...
