Summary of Contents for PowerGistics STANDARD POWER STRIP RETRO-MOUNT
- Page 1 INSTRUCTIONS FOR STANDARD POWER STRIP RETRO-MOUNT FOR TOWER OR CORE SERIES 12/16 OR 18/20 16 or 20 outlet standard power strip retrofit to a 12/16 shelf Tower or 18/20 shelf Tower...
- Page 2 Failure to read these warnings or to follow the instructions below could result in personal injury or damage to your product that could void its warranty. • DO NOT PLUG POWERGISTICS TOWERS INTO OTHER TOWERS. MUST BE PLUGGED DIRECTLY INTO THE WALL OUTLET.
- Page 3 INCLUDED IN RETRO-MOUNT KIT: • 16 Outlet or 20 Outlet • 1 Grounding Cord Screw • 4 Bolts Power Strip (120V, 15A • 1 Grounding Cord Nut • 4 Nuts Circuit Breaker for • 2 Brackets • Zip Ties Standard 110V Outlets) Remove power cord from grommet 2.
- Page 4 Remove USB power strip 1. Remove nut and remove the ground wire. 2. Remove old power strip in the back spine of the Tower and set aside. INSTRUCTIONS FOR STANDARD POWER STRIP RETRO-MOUNT...
- Page 5 Attach standard power strip 1. Position standard power strip on back of spine with power cord outlet at bottom. Power Cord Outlet...
- Page 6 4. Finger-tighten nuts to hold the power strip in place. 5. Repeat Steps 1-4 at another location on the power strip. 6. Use a socket wrench with extension to tighten all nuts. INSTRUCTIONS FOR STANDARD POWER STRIP RETRO-MOUNT...
- Page 7 Attach grounding wire 1. Place small screw into bottom hole on side of spine and slide on ground wire. 2. Place nut on screw and tighten the ground wire onto the side of the spine.
-
Page 8: Attach Power Cord
3. Reinsert the grommet into Tower base hole. Plug power cord into wall outlet. 100 Continental Drive, Columbus, Wisconsin 53925 USA 201-389-9940 | www.PowerGistics.com PWRG 1171 Standard Power Strip Retro-Mount Kit INSTALL GUIDE REVA 2023...
