Continuous analgesia monitoring system
Tel: +33 (0)3 62 09 20 80 - Fax: +33 (0)9 72 38 75 27
MD/PRD/IN16.ANIV1 V.10 – 29 SEP 2021
Analgesia Nociception Index
ANI Monitor V1
User manual
Software version 1.1.4.0
(CE mark first approved on April 2012)
MDOLORIS MEDICAL SYSTEMS SAS
Biocentre Fleming
Bâtiment C Epi de Soil
270 rue Salvador Allende
59120 LOOS (France)
www.mdoloris.com
