Dreo Macro Pro - Air Purifier Manual

Specifications

KNOWING YOUR AIR PURIFIER

Package Contents

About the Filter

The filter uses a-stage filtration system which is composed ot a pre-filter a H13 HEPA filter, and a high-efficiency activated carbon filter.

1. Pre-Filter
2. H13 HEPA Filter
3. High Efficiency Activated Carbon Filter

1. To maintain the optimal performance, please replace the filter every 6-8 minutes.
2. Keep away from water and humid areas. Moisture will allow mold to grow.

Getting the Most Out of Your Air Purifier

1. Keep the doors and windows closed when the air purifier is on.
2. Do not block the air openings and keep away from curtains or walls.
3. Maintain and replace the filters on a regular basis for maximum efficiency.
4. It the Indoor air quality is bad ar you would like to speed up the purification process, it's recommended to turn an Turbo Mode first, then switch to Auto or other modes after the air quality improves.

USING YOUR AIR PURIFIER

Getting Started

1. Put it upside down. Rotate the bottom cover to unlock and take the cover off.

2. Press and rotate the bottom cover clockwise tn lock hack in place.

3. Remove the filter from its packaging then put the filter back.

4. Return to upright position on a flat, stable, and clear surface.


Controls & Lights

1. Filter Change Reminder
   Lights up in red when the filter should be changed.

Filter Reset Button
Long press tar 5 seconds to reset the filter change reminder.

Child Lock Button
Long press for 3 seconds to lock/unlock the buttons.

Timer Button
Select 3 time to turn on/off after 2H, 4H or 8H.

Turbo Mode Button
Select to purify the air at the highest power setting.

Sleep Mode Button
Select to purity the air at the mast silent, power setting,

Auto Mode Button
Select to purify and adjust fan speed automatically based an air quality conditions.

Manual Mode Button
Select purify the air with adjustable fan speeds.

Power Button
Select to turn power on or off.

Air Quality Indicator Light

After the air purifier is turned on, the air quality indicator light will cycle through Red, Orange, Green and Blue colors tor 30 seconds, then the air quality sensor will begin to gauge the air quality in the environment.

General Operations

1. Insert the power cord into the air purifier and an electrical outlet.

2. Press the power button to turn on the air purifier.

3. Choose your desired working mode.

   Manual Mode
   Press repeatedly to select the fan speed to
   Low Medium High

   Auto Mode
   Fan speed will adjust automatically based on the air quality level.

   Turbo Mode
   Fan speed will be running at the highest speed.

   Sleep Mode
   • Fan speed will be set to the lowest speed.
   • All buttons will be on mute and all lights turn off after 10 seconds.

4. Press the power button to turn off the air purifier.


Additional Features

• Long press for at least 3 seconds to enable/disable child lock.
• When child lock is on, all the buttons on the air purifier will be locked except for the Child Lock button.

• When the air purifier is ON/OFF, press the timer button repeatedly to set a time (2/4/8H) tar the air purifier to turn OFF/ON.
• To cancel, press and hold the timer button for at least 2 seconds.

If the air purifier is turned OFF or disconnected from power, it will operate under the previous settings (except the timer setting) when it is turned ON again.

CLEANING AND MAINTENANCE

Replacing the Filter

The filter life is measured by the air purifier's algorithm which is based on the working mode, fan speed run time, and indoor air quality It's recommended to replace the filter every 6-8 months or when the filter change reminder

1. The Filter Change Reminder will flash when the filter needs to be replaced. Turn off and unplug the air purifier.

2. Rotate the bottom cover to unlock then take the cover off.

3. Remove the old filter then put the new filter in place.

4. Press and rotate the bottom cover clockwise to lock in place.

5. Return to upright position and long press the Filter Reset Button for 5 seconds until it beeps, to reset the filter change reminder.


Cleaning the Inside & Outside

1. Unplug the air purifier before any cleaning and maintenance.

2. Remove the filter and clean the inside with a dust vacuum.

3. Wipe clean the housing with a dry, soft, non-abrasive cloth.

4. Open the cover at the back and clean the AQ sensor with a dust vacuum.


Cleaning the Filter

For optimal user the outer pre-filter can be cleaned with a soft dry brush once every 2-4 weeks.

TROUBLESHOOTING

Related to the Filter

Where can I buy a new filter?	Please purchase from Dreo official website: www.dreo.com.
I changed the filter, but the Filter Change Reminder is still on.	The Filter Change Reminder will not automatically reset. Please press and hold the Filter Reset button to reset the reminder, the indicator will turn off after reset.
The Filter Change Reminder has not turned on for a long period of time.	There are several factors that can impact the filter life, including the indoor air quality level, length of operation and particle density in the air. If your room has a better air quality level and / or you don't use your air purifier often, the reminder will take longer to light up.

Related to Use

IMPORTANT SAFETY INSTRUCTIONS

READ ALL CAUTIONARY MARKINGS ON THE APPLIANCE AND SAFETY INSTRUCTIONS IN THE USER MANUAL BEFORE USE.

General Safety

1. Use the appliance as described in the user manual only. Any other use not recommended in the user manual may cause fire, electrical shock, or personal injury.
2. Children shall not play with the appliance. Cleaning and maintenance shall not be performed by children without supervision.
3. This appliance can be used by children aged above 8 years and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of this appliance in a safe way and understand the hazards involved.

Location Safety

1. Always place the appliance on a level, stable and dry surface.
2. Keep the appliance away from heat sources to avoid fire hazards.
3. Do not place the appliance in excessively humid environments.
4. Do not place the appliance directly on or against soft furnishings such as beddings or curtains. Doing so could cause blockage of the openings.
5. Do not use the appliance outdoors, or in toxic or explosive environments, or where flammable or combustible gases are present. .
6. Allow at least 15 in / 38 cm of clearance on all sides of the appliance.

Operation Safety

1. Do not immerse in water and any other liquids.
2. Do not plug in or operate the appliance with wet hands.
3. Do not sit, stand or place heavy objects on the appliance.
4. Do not insert your fingers, pencil and any other objects into any openings.
5. Do not attempt to repair or modify any electrical or mechanical functions on the appliance. Doing so will valid your warranty. All servicing should be performed by qualified personnel only.

Electricity Safety

1. To avoid fire or shock hazard, plug the appliance directly into a wall outlet.
2. Make sure that the voltage of your power source is the same as that specified on the appliance.
3. Keep the cord out of areas where people walk often. Place the cord where it will not be tripped over.
4. Always unplug before cleaning or leaving the appliance unused for a long period of time.
5. Do not operate the appliance with a damaged cord or plug or after the appliance malfunctions, has been dropped or damaged in any manner.
6. Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings. Do not route cord under furniture or appliances. Arrange cord away from traffic area and where it will not be tripped over.
7.
   To reduce the risk of fire or electric shock, do not use this appliance with any solid-state speed control device.

FOR HOUSEHOLD USE ONLY
READ AND SAVE THESE INSTRUCTIONS

Gentle Reminder:
Check the appliance regularly and refer to TROUBLESHOOTING or contact our customer support if it shows any of the following signs:

• Power cord or plug is damaged.
• Loud noise, unusual smell or excessive heat.
