Hanwha Vision SHB-V-3200HPR Quick Manual

Outdoor enclosure kit for box cameras
Hide thumbs Also See for SHB-V-3200HPR:

Advertisement

Quick Links

SHB-V-3200HPR
Quick Guide
Outdoor Enclosure Kit
for Box Cameras

Advertisement

loading
Need help?

Need help?

Do you have a question about the SHB-V-3200HPR and is the answer not in the manual?

Questions and answers

Summary of Contents for Hanwha Vision SHB-V-3200HPR

  • Page 1 SHB-V-3200HPR Quick Guide Outdoor Enclosure Kit for Box Cameras...
  • Page 2 Box Cameras Quick Guide Copyright ©2023 Co., Ltd. All rights reserved. Hanwha Vision Trademark Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered trademark of their respective company. Restriction Copyright of this document is reserved.
  • Page 3: Installation And Connection

    overview CONTENTS OVERVIEW What’s Included INSTALLATION & CONNECTION Installation 3_ Contents...
  • Page 4: What's Included

    overview WHAT’S INCLUDED Please check if your camera and accessories are all included in the product package. Each item may be package in its' own box. Appearance Item Name Quantity HOV32K2A700 OUTDOOR HOUSING WITH POE/HPOE WBJA WALL BRACKET WITH BALL JOINT IRH30L IR ILLUMINATOR OSUPPIR...
  • Page 5 Quick Installation of housing, wall mount, and illuminator: Fasten the plate (1) between the bottom of the housing (2) and the bracket (3) using the supplied screws (4). Fasten the top bracket (1) to the illuminator using the screws and washers (2) supplied. Fasten the illuminator and bracket using the nut and the washer.
  • Page 6 Opening the housing Loosen the 2 screws on the side of the housing, allowing the cover and the upper half of the body to pivot open on the hinge. Slide removal To remove the slide it is necessary to partially unscrew the fixing screws as shown in the figure.
  • Page 7 Position the camera lens (not included) close to the glass to avoid visual interference or optical reflections. Connect the camera to the J2 connector (3) (PoE+ OUT) Refit the slide in its housing and fix the previously loosened screws. Connection of the illuminator Connect the illuminator to the J6 terminal as described in the diagram below.
  • Page 8 PoE+ cable connection Connect the PoE+ cable from the Power Injector to the J1 connector. Before powering the device, you must set the maximum power consumption of the housing operating on dip switch SW1, below. Configuration POWER CONSUMPTION CONFIGURATION Before powering the device, you must set the Maximum power maximum power consumption of the housing to ON for PoE+ class 4 (25.5W maximum output) operating on dip...
  • Page 9 OPERATING STATUS The LEDs shown in the figure allow you to check the LED Status Apparatus Status product's operating status. LD1 (Power The device is not powered supply) The device is correctly powered The camera is not connected or Cold Start is active (Camera) The camera is correctly powered...
  • Page 10 Hanwha Vision America 500 Frank W. Burr Blvd. Suite 43 Teaneck, NJ 07666 Toll Free +1.877.213.1222 Direct +1.201.325.6920 Fax +1.201.373.0124 www.hanwhavisionamerica.com Vision...
