- Page 1 R320M User Manual Wi-Fi6 SOM Module User Manual R320M V2.0 Be Honest & Do Best Your Trustworthy Smart Industrial IoT Partner pusr.com...
-
Page 2: Table Of Contents
R320M User Manual Content 1. Introduction ............................... - 4 - 1.1. Overview............................- 4 - 1.2. Features............................- 4 - 1.3. Specification ............................. - 4 - 1.4. Button & Indicator ..........................- 6 - 1.5. Dimension ............................- 6 - 2. - Page 3 R320M User Manual 3.8.5. Reset to factory setting ......................- 23 - System log ............................- 24 - 4. Warranty ..............................- 25 - 5. Contact Us ..............................- 25 - 6. Disclaimer ..............................- 25 - 7. Revision History ............................- 25 - pusr.com...
-
Page 4: Introduction
1. Introduction 1.1. Overview R320M is a highly integrated embedded WIFI6 wireless AP/client module that can be used in conjunction with a customized motherboard to form a complete WIFI6 wireless AP/client product. The product supports dual independent serial ports and 5 gigabit Ethernet ports, which can meet application scenarios such as AGV, robots, and industrial monitoring. - Page 5 R320M User Manual BT 5.1 Power supply 6V-16V Power consumption ≤10W PCBA size 70* 55 * 1.6 mm Operating -20~70°C, 10% ~ 90% without condensation temperature & humidity Storage humidity -40~75°C, 5%～95% without condensation WLAN Interface Technical standard IEEE 802.11a/b/g/n/ac/ax 2.4GHz-2.483GHz...
-
Page 6: Button & Indicator
Holding for 5s to reset to factory settings 1.5. Dimension Unit： mm Figure 1. Dimension of R320M 2. Get Started 2.1. Login setting webpage Connect PC to the LAN port of the AP controller, and set the IP to static IP, such as 192.168.1.101. The IP should be on the same network segment as the AP device. -
Page 7: Briefs Introduce Of The Webpage
The left column is divided into 9 menu pages: System status, mobile network, Internet accessing settings, WLAN settings, LAN settings, Login settings, client list, upgrade and system log. There are three auxiliary options in the upper right corner: PUSR cloud, Luci, language, as shown in the following figure. -
Page 8: Configuration And Parameter Details
R320M User Manual Figure 4. Function page 3. Configuration and parameter details 3.1. System status This interface displays the basic information of the router, including 5 major blocks: system information, WAN port information, LAN port information, WLAN information. The specific information is shown in the figure below. - Page 9 R320M User Manual Figure 5. System information(AP mode) Figure 6. System information(Router mode) pusr.com - 9 -...
-
Page 10: Mobile Network
R320M User Manual 3.2. Mobile network This function block displays the basic information of mobile network, including: SIM information, 5G model information, 5G band, 4G LTE band, 3G WCDMA band. Figure 7. Mobile network 3.3. Internet accessing settings There are 4 parts included in this function block: Mode Selecting, Network Port Settings, WAN Settings, IP Mapping. -
Page 11: Ethernet Port Setting
R320M User Manual Figure 8. Mode selecting 3.3.2. Ethernet port setting In this function block, users can implement WAN/LAN switching, and can monitor whether the Ethernet port is connected to a device. Figure 9. pusr.com - 11 -... -
Page 12: Wan Settings
R320M User Manual 3.3.3. WAN settings On this page, users can set parameters of WAN port to get access to Internet, including DHCP client, static IP, and PPPoE. MAC clone: Replace the AC's MAC address with this MAC. Figure 10. WAN Port 3.3.4. - Page 13 R320M User Manual Figure 11. Wireless repeater settings Figure 12. System information(wireless repeater) 3.3.5. 5G AT To get information or settings of 5G module via sending AT command. pusr.com - 13 -...
-
Page 14: Wlan Settings
R320M User Manual Figure 13. 5G AT command settings 3.3.6. 5G NR Settings of 5G module. Figure 14. 5G NR settings Table 3. Parameters details of 5G NR settings Items Description 5G enable Turn on/Turn off 5G NR. Station selecting Select the right base station. -
Page 15: G Settings
R320M User Manual 3.4.1. 2.4G settings Figure 15. 2.4G Wi-Fi settings Table 4. Parameters details of 2.4G Wi-Fi settings Items 内容 SSID Set the SSID of AP device, the maximum length is up to 22 characters. Length: 8~32, it can be characters and numbers. -
Page 16: Settings
R320M User Manual 3.4.2. 5G settings Figure 16. 5G Wi-Fi settings Table 5. Parameters details of 5G Wi-Fi settings Items Description SSID Set the SSID of AP device, the maximum length is up to 22 characters. Length: 8~32, it can be characters and numbers. -
Page 17: Lan Network Settings
Figure 17. Signal selecting 3.5. LAN network settings This function block is used to set the LAN IP address of the R320M, with the setting options as shown in the following diagram, and the configuration instructions as in Table 3. -
Page 18: Login Settings
R320M User Manual After enabling DHCP, the R320M can assign IP addresses to terminal devices. DHCP service The IP addresses start from the “initial value” and can be allocated up to the “maximum number“ set. 3.6. Login settings This function is used to change the login password of a webpage. - Page 19 R320M User Manual Figure 20. DHCP list Wireless clients: It displays the clients connected to the AP device via wireless. Click “Refresh” to update the latest client list. Figure 21. Wireless clients IP Binding: Enter the IP address and MAC address of the device that needs to be bound, then click on <Add>.
-
Page 20: Software Upgrading
R320M User Manual Figure 22. IP binding 3.8. Software upgrading This functional block includes 5 submenus: [Firmware Upgrade], [Backup/Restore Configuration], [Date/Time], [Restart], and [Restore Factory Settings]. 3.8.1. Firmware upgrading Select firmware file-> Click upgrade pusr.com - 20 -... - Page 21 R320M User Manual Figure 23. Firmware upgrading Figure 24. Firmware upgrading pusr.com - 21 -...
-
Page 22: Backup
Backup parameters Click the <Backup Configuration> button to save the current settings to a file. Click <Browse> to select the configuration file. Click <Import Configuration>, and in the Import backup file prompt box, click <OK> to upload the settings to R320M and restart. pusr.com - 22 -... -
Page 23: Time & Date
R320M User Manual 3.8.3. Time & Date Set the time and date of the R320M. Figure 27. Time&Date 3.8.4. Reboot Reboot the AP device. Figure 28. Reboot 3.8.5. Reset to factory setting Reset to factory settings. pusr.com - 23 -... -
Page 24: System Log
R320M User Manual Figure 29. Reset to factory settings System log To check the system log. Figure 30. System log pusr.com - 24 -... -
Page 25: Warranty
R320M User Manual 4. Warranty 5. Contact Us Jinan USR IOT Technology Limited Address : Floor 12 and 13, CEIBS Alumni Industrial Building, No. 3 Road of Maolingshan, Lixia District, Jinan, Shandong, China Official website:https://www.pusr.com Official shop:https://shop.usriot.com Technical support: http://h.usriot.com/ Email : sales@usriot.com... - Page 26 R320M User Manual V1.0.1 2024-01-29 May Liu Translation pusr.com - 26 -...
- Page 27 R320M User Manual Official Website: www.pusr.com Official Shop: shop.usriot.com Technical Support: h.usriot.com Inquiry Email: inquiry@usriot.com Skype & WhatsApp: +86 13405313834 关注有人微信公众号 登录商城快速下单 Click to view more: Product Catalog & Facebook & Youtube pusr.com...
