6
TORCH SPECIFICATIONS
Material: anodised aircraft 6063 aluminium
Colour: black
LED: 4x Luminus SST40 (10w/6500K)
LED lifespan: 100000 h
Brightness: 3500 lm
Light colour: white
Mode: high/dimming
Battery: 2x 26650 3.7V, 10000mAh
Recharge time: 5 hours (approx)
Charging: magnetic port
Switch design: magnetic slide switch
Lens: coated glass lens
Size: Ф81*216mm(Ф3.19*8.5")
(head diameter x length)
Weight (torch): 650g (1.43lbs)
Weight (torch and batteries): 850g (1.87lbs)
Please note weights are approximate
BATTERY INSTALLATION
DO NOT
insert battery the wrong way.
DO NOT
use different batteries to the ones provided.
DO NOT
use a battery if it is damaged.
Insert the battery positive end first, and close the tail
cap, taking care not to disturb the O rings.
If the battery doesn't fit, please check the battery's
orientation and not force into the battery mount.
If the battery is forced to set with a different polarity,
the battery may catch on fire, smoke, explode, or
cause heat generation.
When the battery is fully charged, switch off and
unplug the charger from the mains power.
USER MANUAL
1
3
2
STANDARD
NOTICE
This data may vary depending on environmental conditions.
OPERATION
The torch is operated by the top-mounted slide switch. Use
this to vary the torch output.
WHATS INCLUDED?
1
2
3
4
4
5
5
6
7
7
HIGH
3500 lumens
2 hrs
500m (beam distance)
62500cd (peak beam intensity)
1m (impact resistance)
100 metres (depth rating)
WARNINGS
When storing the torch, unscrew the tail cap to
ensure the power is cut off.
After every dive, clean the torch with fresh, clean
water and dry with a cloth. Salt water residue can
corrode the torch surface.
Ensure that the tail cap is lubricated regularly. A
small bottle of lubricant is supplied with your torch.
Avoid any impact on the torch.
Do not shine the light directly into eyes.
IF THERE IS A PLASTIC TAB LOCATED IN THE
BATTERY COMPARTMENT, IT MUST BE
REMOVED FROM THE TORCH BEFORE USE
3500 torch unit (1)
26650 battery (2)
Magnetic charger (1)
Spare O rings (2)
Tail cap lubricant (1)
Hard storage case (1)
User manual (1)
LOW
35 lumens
100 hrs
V.01.28062023
