Northern Diver Varilux 3500 User Manual

7

TORCH SPECIFICATIONS

Material: anodised aircraft 6061 aluminium
Colour: black
LED: 4x CREE XM-L2
LED lifespan: 100000 h
Brightness: 3500 lm
Light colour: white
Mode: high/dimming
Battery: 26650 3.7 V, 5200 mAh
Recharge time: 5 hours (approx)
Switch design: magnetic slide switch
Lens: coated glass lens
Size: 217*69*130mm (8.5*2.7*5.1")
(length x head diameter x handle length)
Weight (torch): 586g (1.29lbs)
Weight (torch and batteries): 772g (1.7lbs)
Please note weights are approximate

OPERATION

The torch is operated by the top-mounted
slide switch. Use this to vary the torch output.

TORCH STRUCTURE

3
1
2
USER MANUAL
1
3
2
4
STANDARD
NOTICE
This data may vary depending on environmental
conditions.
4
WHATS INCLUDED?
1. 3500 torch unit (1)
2. 26650 batteries (2)
3. Battery charger (1)
4. USB cable (1)
5
5. Spare O ring (1 minimum)
6
6. Tail cap lubricant (1)
7. Hard storage case (1)
8. User manual (1)
8
HIGH
3500
LUMENS
2 hrs
1000m (beam distance)
90000cd (peak beam intensity)
0.5m (impact resistance)
100 metres (depth rating)
1. Head with LED modules
2. Body
3. Slide switch
4. Handle
5. Unscrew to access batteries
5
You MUST remove the plastic tab!
6. Tail cap
6
MID LOW
3500 - 200 200
LUMENS LUMENS
2 - 40 hrs 50 hrs
V.01.09032022
