RIFFE HORIZONTAL REEL
INSTALLATION GUIDE
(RL-1500 / RL1500R)
(RL-1600 / RL-1600R)
RIFFE International Inc.
1214 Puerta Del Sol, San Clemente, CA 92673
info@speargun.com www.riffeinternational.com
SPOOLED LINE DIRECTION
REEL EXPLODED VIEW
12. REEL AXIS BOLT
11. THRUST WASHER
10. TEFLON WASHER
9. BEARING TUBE
8. SPOOL & KNOB ASSEMBLY
RADIAL BASE ASSEMBLY
7. DRAG ROLLERS
6. DRAG CONTROL PLATE
5. SPRING BALLS
4. DRAG LEVER
3. SCREWS
2. MOUNTING BASE ASSEMBLY
1. GASKET
FLAT BASE ASSEMBLY
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Riffe RL-1500
Summary of Contents for Riffe RL-1500
- Page 1 RIFFE HORIZONTAL REEL INSTALLATION GUIDE (RL-1500 / RL1500R) (RL-1600 / RL-1600R) RIFFE International Inc. 1214 Puerta Del Sol, San Clemente, CA 92673 info@speargun.com www.riffeinternational.com SPOOLED LINE DIRECTION REEL EXPLODED VIEW 12. REEL AXIS BOLT 11. THRUST WASHER 10. TEFLON WASHER 9.
- Page 2 INSTALLING REEL BASE RIFFE INTERNATIONAL, INC. Spool exploded view of Horizontal Reel (RL-1500) Washer **If you have an 8mm wrench that will fit under the Drag Control Plate Reel Axis Bolt to access the screws, you do not need to disassemble the Reel.
