Summary of Contents for Saunum AutoLEIL
- Page 1 Saunum Automatic Water Dispensing Unit AutoLEIL...
- Page 2 THE BEST SAUNA EXPERIENCE TO HAVE! am very glad that you have invested in the Saunum device, and I believe that our innovative technology will offer you a wonderful and extraordinary sauna experience. I have a degree in thermal engineering and come from Southern Estonia, where my love for saunas began.
- Page 3 A moist steamy sauna, a therapeutic salt sauna, or a healthy aroma sauna – all of these functions are available on Saunum’s devices to create a truly relaxing sauna experience. When...
- Page 4 Saunum congratulates you on choosing an innovative sauna automatic water dispensing unit!
-
Page 5: Table Of Contents
DIRECTION FOR USE Using the automated water dispensing unit ________________ Automated water dispensing unit _______________________ Using an AutoLeil unit with a Leil Control unit ______________ Automatic water dispensing unit _________________________ Automatic water dispensing modes _______________________ Water dispensing in public saunas ________________________... -
Page 6: Warnings And Notes
This device should not be used by child ren, people with reduced mobility, or sick people. Children should use the device only under constant and close adult supervision. Persons with reduced physical, sensory, or mental capabilities, or persons with a lack of experience and knowledge, should use this device only under constant and close adult supervision and only after consulting... - Page 7 Prolonged exposure to steam can be harm • It is vital to install the device accord ful or fatal. Users should discontinue using ing to the instructions for installation the sauna if they feel lightheaded, dizzy, or and use. Failure to carefully follow all experience heat exhaustion.
-
Page 8: Using The Automated Water Dispensing Unit
USING THE AUTOMATED WATER DISPENSING UNIT The air in the sauna becomes dry as it heats • Avoid throwing excessive amounts up. Therefore, it is necessary to create steam of water on the stones. to achieve a suitable level of humidity. The •... -
Page 9: Automated Water Dispensing Unit
AUTOMATED WATER DISPENSING UNIT The Saunum water dispensing unit AutoLEIL consists of a control unit with water valve (1), an operating button (2), a spray nozzle (3), a humidity sensor (4) and a set of cables for (5). The control unit controls the supply of wa... -
Page 10: Using An Autoleil Unit With A Leil Control Unit
Leil controller via the data cable. Leil is water on the heater stones. the main controller of the heater system, whereas AutoLEIL is an accessory device in • Alternatively, the unit can be set up the system. to throw userspecified amounts of AutoLEIL is recognised by Leil when they water at specified time intervals. -
Page 11: Automatic Water Dispensing Modes
(RH) (5–60% RH) in the sauna and duration of the automatic dispensing cycle Temperature oC (1–30 min). AutoLEIL automatically opti mises the water quantity and dispensing Water is dispensed on the stones in 1 minu interval in order to reach the desired humi... -
Page 12: Water Dispensing In Public Saunas
By default, the AutoLEIL duration can be This can be adjusted from 0.3–4 sec), the configured for up to 30 minutes. In public... -
Page 13: Operating Button
AutoLEIL water dis preset duration according to the Sauna pensing and the desired sauna parameters. -
Page 14: Button Functions
BUTTON FUNCTIONS The “sauna ready” time is when the sauna’s steam zone temperature has reached the selected temperature level. ON/OFF Long press the operating button (~1 sec) to turn automatic water dispensing “Humidity settings” allow to set up auto ON/OFF. LED light indicates whether the matic water dispensing in either Automa... -
Page 15: Creating Asauna Type
While the sauna is in heating mode, it is pos Set the heater. sible to change the “sauna ready” time and the temperature by tapping on the time Finnish sauna 1/2 and temperature controls and selecting the desired numbers. 09:55 CREATING A SAUNA TYPE MANU AL... -
Page 16: Technical Data
TECHNICAL DATA CONTROL PANEL (LEIL TOUCH SCREEN): • Humidity adjustment range 5–60% • Water output period adjustment range: 0.3–4 sec. • Automatic water dispensing inter val adjustment range 1–10 min. • Automatic water dispensing func tion duration adjustment range: 1–30 min or 1–12 hrs settings. MAIN UNIT: •... - Page 17 (location 230 V 1N~ button according manual) KLMA SiHF 4 x 0.25mm2 x 0,8 + 0.8 HF Button Water output 2x1.5 mm2 SiHF 4 x 0.25 mm2 AutoLEIL Water tap 15/10 mm2 hose SiHF 4 x 0.25 mm2...
-
Page 18: Installing The Operating Button
INSTRUCTIONS 1. Use the printed template to mark loca tions for screw holes and a drill hole (Ø 18– FOR INSTALLATION 23 mm drill bit) for the cable connector (see page 24). If the cable is not concealed in side the wall, the hole can be only 5 mm WARNING! Failure to install the pro... - Page 19 2. Install the screws, leaving the heads out 34mm from the wall. Drill the hole through the wall and bring the cable to the opening. B Pull enough cable through the hole to con L nect the cable to the button connectors. 3.
-
Page 20: Installing The Humidity Sensor
INSTALLING THE HUMIDITY SENSOR Connect the wires to the button connector. Install the humidity sensor inside the sauna Make sure the wires are connected to the room. The sensor should be installed on the main unit in the same colour code order. opposite wall to the heater. -
Page 21: Installing The Main Unit
INSTALLING THE MAIN UNIT The installation location for the main unit As the AutoLEIL Main Unit needs to com must be a dry space outside the sauna municate with Leil controller, it is advised room with a floor drain (ambient tempera... -
Page 22: Installing The Piping
PRE-BENT PIPE Prebent stainless steel pipes for Saunum Professional and Primary heaters are sold separately from the AutoLEIL package. These pipes should be clamped onto the wall right next to the heater to save time during installation. -
Page 23: Installing The Nozzle
INSTALLING THE NOZZLE When the pipe is installed, fit the spray Tighten the cap nut (1) with a wrench. The nozzle in the end of water outlet pipe. Cut adequate number of turns for 10mm cop the pipe square, deburr properly. Slide cap per pipe is 1 full turn (360°) and for 10mm stainless steel pipe ¾... -
Page 24: Button Template
18–23 mm... -
Page 25: Electrical Connection
ELECTRICAL CONNECTIONS The connection of the main unit is shown on the diagram of electrical connections. For more information on connecting the heater or Leil control unit, see the respec tive heater and/or Leil control unit instal lation and operating manuals. If the connection and installation cables are located higher than 100cm from the floor of the sauna room or inside the walls of... - Page 26 Leil Main Unit to AutoLEIL continues to the page on the right...
- Page 27 AutoLeil Main Unit HUMIDITY SENSOR to Leil continues to the page on the left BUTTON OUTLET ONTO HEATER STONES WATER TAP...
-
Page 28: Warranty
Device if it is used in a public sauna. • Adaptation or modification of the The Saunum warranty starts from the date device for any purpose other than of purchase and includes all manufacturer that indicated in the instructions for provided parts of the control unit. -
Page 29: Installation Protocol
INSTALLATION PROTOCOL Saunum model: _________________________________________________________ Date of purchase: _________________________________________________________ Original purchaser: ________________________________________________________ Place of installation: _______________________________________________________ Purchased from: __________________________________________________________ Date of electrical installation: ________________________________________________ Signature of the installer: ___________________________________________________ Notes: _________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________ Customer’s contact (name, email address): ______________________________________ ______________________________________________________________________...
