WHEELCHAIR SEAT
Thank you for purchasing this Direct Supply EZ-Lift Wheelchair Seat. In this owner's manual, you'll find important information
that you should read before assembling and using this device. If at any time you do not understand how to use this product,
or you suspect it may be damaged, DO NOT USE and immediately contact the distributor that sold this product to you. This
owner's manual is compiled from the latest specifications and product information available at the time of publication.
Changes may be made to this manual at any time. Contact your distributor for a current copy of this owner's manual.
Direct Supply
EZ-LIFT
Patents pending
Owner's Manual
Please keep and refer to this Owner's Manual.
1-800-634-7328 DirectSupply.com
®
TM
Advertisement
Table of Contents
Related Manuals for Direct Supply EZ-LIFT WHEELCHAIR SEAT
Summary of Contents for Direct Supply EZ-LIFT WHEELCHAIR SEAT
- Page 1 Please keep and refer to this Owner’s Manual. Thank you for purchasing this Direct Supply EZ-Lift Wheelchair Seat. In this owner’s manual, you’ll find important information that you should read before assembling and using this device. If at any time you do not understand how to use this product, or you suspect it may be damaged, DO NOT USE and immediately contact the distributor that sold this product to you.
-
Page 2: Table Of Contents
• Attention! Read the instructions. PRODUCT OR DEVICE: Your Direct Supply EZ-Lift Wheelchair Seat, distributed by Direct Supply Manufacturing, Inc. (“We” , “Us” or “Our”). “You”: Means the user, caregiver and any other individuals who will be using or servicing the product. -
Page 3: Warnings
WARNING: Do not make any modifications to • WARNING: Check system daily to verify this device or use non-Direct Supply parts. Doing so functionality; periodic tweaks or adjustments may may void the warranty and pose a risk to the user. -
Page 4: Installation Instructions
Installation Instructions Tools Required: Phillips Screwdriver 10mm Wrench and (or other tool(s) as Long-nose Pliers needed to remove used for Anti-rollback wheelchair sling seat) Installation 2x 7/16" Wrenches 3/16" Allen Wrench or Socket Wrenches used to adjust upper used to adjust lift force mounting bars STEP 1 –... -
Page 5: Step 3 - Install Lift Mechanism
STEP 3 – Install Lift Mechanism a. Using (2) 7/16 inch wrenches, loosen the mounting bar width-adjustment bolts to allow the bars to slide in and out. Do not completely remove the bolts. (figure 3) b. Adjust the mounting bars to the approximate width of your wheelchair’s mounting tubes. -
Page 6: Step 3A - Install Lift Mechanism (Optional Seat Height Adjustment For Some Installations)
Installation Instructions (cont.) STEP 3a – Install Lift Mechanism (Optional seat height adjustment for some installations) Follow these directions if your lift seat mechanism is interfering with the cross bars on your wheelchair and additional clearance height is needed. Always verify that a higher seating height is appropriate for the user before placing the wheelchair into use. -
Page 7: Step 4 - Install And Test Anti-Rollback System
Thank you for purchasing this Direct Supply Anti-rollback Device. In this owner’s manual, you’ll find important information that you should read before assembling and using this device. If at any time you do not understand how to use this product, height of your anti-rollback bumpers. -
Page 8: Step 5 - Attach Wheelchair User's Seat Cushion
Do not allow a user to sit directly on the lift seat’s plastic seat pan. Contact your Direct Supply Account Manager if you need to purchase a pressure-redistributing seat cushion. -
Page 9: Step 6 - Install Rear Cover
STEP 6 – Install Rear Cover a. Press the hook-and-loop strip on the rear cover onto the compatible strip on the rear of the plastic seat. (figure 15) b. Fit upper attachment loops over the wheelchair’s push handles, as shown. This is easiest if the lift seat is in the “up”... -
Page 10: Step 7 - Prepare The Wheelchair For Use
Installation Instructions (cont.) STEP 7 – Prepare the Wheelchair for Use a. Reinstall removable armrests and ensure that seat system functions without interference. b. Reinstall removable footrests, if applicable. STEP 8 – Test all Functions Before Use a. Test the lift seat functionality. a.1 Manually compress the lift seat to ensure stability, range of travel, and to check for interference with the wheelchair or any installed accessories. -
Page 11: Directions For Use
Directions for Use Directions for Use Your Direct Supply EZ-Lift Wheelchair Lift Seat Device is designed to provide between 20-60 lbs of lift assistance while standing. The system should help enable a resident who is otherwise able to stand and ambulate safely, however the lift seat is not expected to fully lift the resident by itself. - Page 12 Directions for Use (cont.) c. Lift gently on the back of the plastic lift seat and then guide the adjustment block into one of the desired force settings, as shown. (figure 20) LOWEST lift force d. Once the desired force setting has been selected, swing the adjustment lock into its home position and secure with round pin and hairpin.
-
Page 13: Adjusting Rear Lock Lever
When the EZ-Lift Wheelchair Lift Seat is removed, the Direct Supply seat lift device is designed to allow a wheelchair to fold even when the device is installed. Your wheelchair’s collapsed width may be slightly wider when using this device. -
Page 14: Adjusting Seat Collapse Force Setting
Directions for Use (cont.) Adjusting Seat Collapse Force Setting Follow these steps for fine-adjustment of seat collapse force. Use this setting if the wheelchair user requires a lower force to lower the seat while sitting, while maintaining a higher lifting force while standing. -
Page 15: Cleaning Instructions
Cleaning Cleaning Instructions • WARNING: Ensure the chair is unoccupied before performing any cleaning or service. • Sanitize and wash all components. DO NOT submerge the device. • Use standard water pressure. DO NOT power wash or steam clean any parts. •... -
Page 16: Periodic Inspection
Periodic Inspection Periodic Inspection 1. Check for proper system function by following the steps outlined in Step 8 of the Installation section of this manual. 2. Review all adjustment points to ensure adjustment pins are correctly seated and hairpin retainers are in place on all adjustment pins. -
Page 17: Parts List
91263A562 (screw) (x4) Direct Supply EZ-LiftTM 90107A029 (washer) (x4) 847102001272 Wheelchair Seat 95615A120 (nut) (x4) HOOK & LOOP Rear Cover Replacement for Direct Supply EZ- REAR COVER (x1) 847102001333 LiftTM Wheelchair Seat Front Cover Replacement for Direct FRONT COVER (x1) 847102001444... -
Page 18: Limited Warranty
Limited Warranty We, Direct Supply Manufacturing, Inc. offer to you, as the original purchaser, a warranty for the Direct Supply EZ-Lift Wheelchair Lift Seat Device and Direct Supply Anti-rollback Device. Our warranty ® ™ ® applies for the limited warranty period stated below. If any product or product part listed below is defective in material or workmanship during the applicable limited warranty period, we will repair or replace it at our cost. -
Page 19: Customer Service
Wheelchair Seat and enjoy outrageous customer service. If you have any ® questions about the seat lift device you have purchased or would like to request warranty service, please contact: Direct Supply Equipment & Furnishings at 1-800-634-7328, 7301 W Champions Way, Milwaukee, WI 53223, SalesSupport@DirectSupply.com. 1-800-634-7328... - Page 20 © 2022 Direct Supply Manufacturing, Inc. All Rights Reserved. Direct Supply , and all associated logos are the registered ® trademarks of Direct Supply, Inc., used under license. All other trademarks are the property of their respective owners. Date of Printing: November 2022 18149...
