Direct Supply Panacea Tilt-and-Recline Chair Owner's Manual

Weight capacity 350 lbs.
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TilT-and-Recline
Thank you for purchasing a Panacea
Direct Supply, Inc. Please read this entire guide carefully and keep it for future reference. This guide will provide you with
instructions, warnings, warranty information and other important information about your Panacea
Share this information with your housekeeping, nursing and maintenance staff to help ensure the chair is used and cared
for properly.
Panacea
chaiR
Owner's Manual
Please keep and refer to this Owner's Manual.
Tilt-and-Recline Chair from Direct Supply Equipment & Furnishing
®
1-800-634-7328 DirectSupply.com
®
Tilt-and-Recline Chair.
®
, a division of
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Panacea Tilt-and-Recline Chair and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Direct Supply Panacea Tilt-and-Recline Chair

Summary of Contents for Direct Supply Panacea Tilt-and-Recline Chair

  • Page 1 , a division of ® ® Direct Supply, Inc. Please read this entire guide carefully and keep it for future reference. This guide will provide you with instructions, warnings, warranty information and other important information about your Panacea Tilt-and-Recline Chair.

  • Page 2: Table Of Contents

    This owner’s manual is compiled from the latest specifications and product information available at the time of publication. Changes may be made to this manual at any time. Contact Direct Supply for a current copy of this Owner’s Manual.

  • Page 3: Warnings & Cautions

    Warnings & Cautions Read and follow all directions before using this device. Do not operate this device without first reading and understanding the contents of this manual. Damage, injury or even death may result from improper use of this device or not following directions and warnings. This device is intended for use by trained and licensed healthcare or senior care providers for normal, indoor use only.
  • Page 4 Warnings & Cautions (cont.) • WARNING: The device should be used away from stairwells, elevators and exterior doorways. • WARNING: Ensure the user is properly positioned in the chair. Improper positioning could result in a tipping of the chair and/or the user sliding or falling off the chair. •...

  • Page 5: Device Description

    Device Description Figure 1 Figure 2 The Panacea Tilt-and-Recline Chair consists of the following components: ® 1. Seat cushion 10. Manual tilt handle/lever 2. Back cushion 11. Manual recline handle/lever 3. Padded, elevating legrest 12. Manual legrest lever 4. Padded foot plate (optional) 13.

  • Page 6: Operating Instructions

    Operating Instructions Tilt Operation The seat tilt angle can be adjusted from 0 to -35 degrees. In order to tilt the chair: • Locate the tilt mechanism handle. The handle is located at the rear of the chair, on the right push bar, marked with a “TILT”...
  • Page 7 Recline Operation The backrest angle can be reclined from 95 to 125 degrees. In order to recline the chair: • Before reclining, the caregiver should ensure the chair is in a slight tilt position to prevent the user from sliding out while reclining. •...
  • Page 8 Operating Instructions (cont.) Lateral Supports The lateral supports are detachable and interchangeable. They can be used in various combinations, individually or collectively, to provide upper-body or lateral support. To adjust the lateral supports: • Unscrew the grip knobs counterclockwise slightly until the gap is large enough to detach the support (Figure 5).
  • Page 9 Armrest Adjustment The armrests are hinged and height adjustable. To flip back the armrests for lateral transfers: • Remove the lateral supports on the side of the lateral transfer. • Unscrew the grip knob on the side of the lateral transfer (located directly underneath the armrest on the seat frame) counterclockwise until the armrest can be lifted up freely.
  • Page 10 Operating Instructions (cont.) 20" Optional Wheels The chair has a detachable 20" wheel set. To attach the wheels: • Engage all four caster locks prior to attaching the wheels. • Push down on the adjustment lever located on the wheel-mounting bracket to elevate the sleeve where the wheel will attach (Figure 9).
  • Page 11 Legrest & Foot Plate To adjust the legrest angle: • Pull the release lever located under the seat on the front left side (Figure 11). • Raise or lower the legrest to the desired position. During this process, the caregiver should also use his or her other hand to help guide the legrest into place.
  • Page 12 Operating Instructions (cont.) Lap Tray The chair has a detachable lap tray that is depth adjustable. To attach the tray: • Pull down and rotate the release pins located under the armrests. Rotating the pins will lock them into an “open” position (Figure 13). •...
  • Page 13 Transfers Always follow your facility’s policies for transfers, in addition to these precautions: • All four caster locks must be engaged prior to a transfer. • Place the chair in the full upright position. Additionally, fold the foot plate in the upward position and the legrest in the stored position.

  • Page 14: Care & Maintenance

    If you believe a component or part is not functioning properly, you should cease use of the chair and contact Direct Supply immediately. • WARNING: Do not use the chair if it shows any signs of deterioration or excessive wear and tear.
  • Page 15 Perchloroethylene (PERC), should not be used. DO NOT USE THIS DEVICE IF IT APPEARS TO BE DAMAGED IN ANY WAY. Contact your Direct Supply account manager for replacement parts. Regular Inspections • Check the casters and wheels for wear. Replace as necessary. Do not replace or adjust wheel or caster components without the proper tools and training.

  • Page 16: Technical Specifications

    Technical Specifications Technical Specifications Table Seat Dimensions Width: 19", Depth: 17.5" Seat-to-Floor Height 21.5" Back Rest Height 28.6" Tilt Range 0 to -35 degrees Recline Range 95 to 125 degrees Caster Wheels Swivel locking, 4" diameter (front), 5" diameter (rear) Armrests Height adjustable, flip back Lap Tray Dimensions...
  • Page 17 Seat depth 17.5" Cushion height 1.6" Figure 16 1-800-634-7328 DirectSupply.com...

  • Page 18: Limited Warranty

    Limited Warranty We, Direct Supply Manufacturing, Inc. offer to you, as the original purchaser, a warranty for the Panacea Tilt-and-Recline Chair. Our warranty applies for the limited warranty period stated below. If ® any product or product part listed below is defective in material or workmanship during the applicable limited warranty period, we will repair or replace it at our cost.

  • Page 19: Customer Service

    Tilt-and-Recline Chair and enjoy outrageous customer service. If you have any questions ® about the Tilt-and-Recline Chair you have purchased or would like to request warranty service, please contact: Direct Supply Equipment & Furnishings at 1-800-634-7328, 6767 N. Industrial Road, Milwaukee, WI 53223, SalesSupport@DirectSupply.com. 1-800-634-7328...
  • Page 20 © 2016 Direct Supply Manufacturing, Inc. All Rights Reserved. Direct Supply , Panacea , and all associated logos are the ® ® registered trademarks of Direct Supply, Inc., used under license. All other trademarks are the property of their respective owners. Date of Printing: April 2016 11001...
