Reyee RG-E4 Quick Installation Manual

RG-E4 Router
Quick Installation Guide
For any inquiries, suggestions, or product-related assistance,
please email us at techsupport@ireyee.com.
For comprehensive technical support, user manuals, and other
helpful information, please visit https://www.ireyee.com.
2

Set Up Your Router

Method 1: Via a Web Browser
1. Connect your smartphone or computer to the
router using a wired or wireless connection.
For the wired connection, use an Ethernet cable to
connect your computer's Ethernet port to any LAN
port on the router.
For the wireless connection, open Wi-Fi settings on
your smartphone, and connect to the Wi-Fi network
that starts with @Reyee. You can find the specific
Wi-Fi name on the label at the bottom of the router
indicated by SSID.
2. Follow the instructions on the displayed
setup page to complete the setup. If the setup
page is not displayed, open a web browser, enter
192.168.110.1 in the address bar.
If you are still unable to access the setup page, see
Q1 in FAQ for further assistance.
Method 2: Via an App
Download up-to-date Reyee Router App. Follow
app instructions to complete setup.
SSID ： @Reyee-sXXXX
SSID： @Reyee-sXXXX
192.168.110.1
or
Reyee Router app
1

Connect Your Router

· If you use a modem for Internet access, power off your
modem and remove the backup battery if it has one.
If you do not have a modem, you can connect the Ethernet
port in the wall directly to the WAN port of your router. Once
connected, proceed to follow steps 3 and 4.
1 Connect the modem to the WAN port on the
router using an Ethernet cable.
2
Power on the modem and wait for it to restart.
3

Add a Reyee Unit

first router
Internet Mesh Button
1. Set up the first reyee router using Method
1 or Method 2.
2. If possible, connect the WAN port of the
second router to a LAN port of the first router
using an Ethernet cable. (Follow Steps 3)
If not, place the second router within 2 meters
(78.74 in.) of the first router. (Follow Steps 3
and 4)
· After the mesh network setup is successful, the Wi-Fi name and password of the second router will
be the same as those of the first router.
· Before creating a mesh network, make sure that the second router has not been configured before.
If you are uncertain, restore the second router to factory defaults by pressing the Reset button for
more than 10 seconds.
For more details, please visit https://www.ireyee.com.
Modem Unplug the power
4 Verify the LED on the top of the router until
it turns solid red or green.
3 Connect the power adapter to the router.
Second router
Mesh LED
3. Connect the second router to a power
source. After the second router has initialized
successfully, press the Mesh button on the first
router. After the Mesh LED on the second
router turns from blinking to solid on, the mesh
connection between the two routers is
established successfully.
4. Power off the second router, relocate it to
the desired location and power it on. Make sure
that there are no more than two walls between
two routers.
