Summary of Contents for SolaX Power X1-Hybrid/Fit G4
- Page 1 Meter/CT Self-Check V1.0 ENGLISH...
- Page 2 Background Meter and CT is the Measuring device installed at the GCP (Grid Connection Point) of the inverter system for detecting GCP data. For energy storage system, the functions such as Battery Charge and Discharge, Working Mode, Export Control and Three-phase Unbalanced, can only be achieved when the Measurement device is installed correctly.
- Page 3 the error code prompt: (Error codes refer to Table 1) ① 'CT' has not been successfully clipped on the phase wire ② 'CT' is wrongly connected to the loads side ③ 'CT' is wrongly connected between the loads and the inverter ④...
- Page 4 ⑥ The CT is connected to 2 wires ⑦ The direction of ‘Meter-CT’ is reversed Note: Meter’s direction reverse problem also need to be Manually Corrected according to the error code prompt. ⑧ ‘Meter-CT’ three phases correspondence is not correct Note: If there has communication problem with Meter and Meter-CT, the ‘Meter fault’...
- Page 5 error code if there has problem. The Table 1 describes the meaning of error codes. Tab.1 The Error Codes and Corresponding Meaning Error Codes Meaning Fail 00 Phase A has no CT clipped on it. Fail 01 Phase A has 2 CTs clipped on it, or there is CT clipped on the N wire. Fail 02 CT1 is clipped to Phase A and Phase B.
- Page 6 Checking passed; Failed xx: Meter and CT has installation problem required manual adjustment) The Meter/CT Self-Check function of X1-Hybrid/Fit G4 The Meter/CT Self-Check function of X1-Hybrid/Fit G4 has 2 differences from three-phase system in the following ways: Ⅰ. X1-Hybrid/Fit G4 only check CT and does not check meter;...
- Page 7 If ‘CT direction reversed’ is detected, the inverter will Automatically correct the CT direction. (2) These problems will report ‘miss CT fault’ and need to be Manually Corrected by the installer. ① CT has not been successfully clipped on the phase wire ②...
- Page 8 ⑤ CT is wrongly connected between the loads and the inverter Configuration Compatible Inverter Model： X1-Hybrid/Fit G4 X3-Hybrid/Fit G4 Firmware Version： X1-Hybrid/Fit G4： ARM≥1.34 DSP≥1.35 X3-Hybrid/Fit G4： ARM≥1.28 DSP≥1.30 Note: Both Inverter Parallel System and AC Coupling (with third-party string inverters) System all support Meter/CT Self-Check function.
