Summary of Contents for AFERIY AF-P010
- Page 1 Portable Power Station A F- P 01 0 U se r M an u a l 800W...
- Page 2 According to the transportation requirements of the international customs for battery products, the battery level of this product is only less than 35% when it leaves the factory. Please fully charge the product after unpacking it to start the experience tour of AF-P010. Precautions For Use 1.
-
Page 3: Table Of Contents
Contents AC Output Parameter Packing List Product introduction Introduction of Display Interface UPS Mode Connection of Solar Panels Car charging Product Parameter Battery specification Troubleshooting table Warranty Card Disclaimer... -
Page 4: Ac Output Parameter
AC Output Parameter Type of AC port AC output 100V~120V 50Hz/60Hz US/JP 220V 50Hz 220V~240V 50Hz/60Hz 220V~240V 50Hz/60Hz 220V 60Hz... -
Page 5: Packing List
Packing List Portable Power Station A F-P 01 0 U ser Manual 800W Power Station AC Charger User Manual MC4 to XT60 Plug Charging Cable Product Introduction This product is a 512Wh large capacity 800W high power, 1.5 hours of high-speed charging portable energy storage power supply, using high safety performance of LiFePo4 battery. - Page 6 Main power control Light control USB control DC control LCD display Air intake/outlet AC on/off control(50Hz/60Hz switching control) XT60 input port(for solar panel) AC input port Main Power Control Main Control for the whole system turn on/off. Operate method:long press the button for 3s to turn on/off the system. LED light control Operate method:short press to turn on and change the light mode (SOS/Flash).
- Page 7 LCD display Present the remaining power and using data. Cooling system When the fans are working, please don’t block the channel. AC button(AC output, total share 800W) Operate method:short press to turn on/off. Notice: 1.Please confirm the output voltage or frequency before using. 2.Long press the button for 3s to entry the frequency changing mode, 50Hz and 60Hz will blink in the display, press again the button to chose the right frequency,wait till the frequency is not blinking, then you will get the frequency you want.
-
Page 8: Introduction Of Display Interface
Introduction of Display Interface Charging/using time Total output power Type-c output XT60 charging Total input power LED light USB output AC charging Battery Progress Bar AC output Fan state High/low temperature protection Power percentage DC output Cigar lighter output Display Attention When this icon light up. -
Page 9: Ups Mode
UPS Mode UPS function This product has the bypass mode, does not need to pass through the battery, can directly output from the AC. In UPS mode, when the AC input power of the mains is cut off due to a power outage, the ac input power of the mains can be used in about automatic switch to product battery power within 10 ms to ensure AC output. -
Page 10: Connection Of Solar Panels
Connection of Solar Panels Under the condition of light, this product can be connected to the solar panel and getting charged. The charging power is determined according to the conditions of light and weather. In this charging mode, we support solar panel input within 200W, and the input voltage cannot exceed 50V, otherwise the product abnormality caused by it will not be covered by the warranty. -
Page 11: Car Charging
Car Charging This product can be charged by the cigarette lighter in the car with an ACC cable (accessory: ACC hereinafter). Turn on the power of this product, connect the ACC charging cableto the cigarette lighter in the car and the XT60 interface on the side of the product, turn on the engine of the car, and the LCD of this product will show the input power. -
Page 12: Product Parameter
Product Parameter Product name 800W Portable Power station Product size L*W*H=272X184.5X240mm Product weight 6.5kg Capacity 512Wh AC Charging 50/60Hz 400W max MPPT input 11.5-50V 8A 200W max AC output 800W 50Hz/60Hz,pure sine wave USB-A output (QC 3.0 18W)x2 Type-C output (PD 100W)x1；(PD 20W)x2 DC 6530 output 12V/10A... -
Page 13: Troubleshooting Table
3. Press the overload protection button, connectthe AC cable to restore the AC input lf you have any questions, please feel free to contact us. Email address: support@aferiy.com. Sincerely. -
Page 14: Warranty Card
Warranty Card Warranty Card Model Name Address Mail Name of the store Buying date Please fill in all the above items. This product provides a 24-month warranty service from the date of purchase If there is a quality problem within the range of normal use, we provide warranty service. After purchasing our company’s products, please keep this product together with invoices and other items. -
Page 15: Disclaimer
Users undertake to be responsible for their own actions and all conse- quences arising therefrom. AFERIY is not responsible for all losses caused by the user’s failure to use the product in accordance with the User Manual.
