nanobox | tangerine Quick Start Guide
GET SET UP
1.
Insert the microSD card. The card must be in the slot for tangerine to load. The card is spring-
loaded. Push to eject when needed, but leave it in for now.
2.
Connect the Line Out to your mixer, speakers or headphones.
3.
Connect an optional MIDI controller to the MIDI IN jack. TRS Type A and B are supported.
4.
Connect the USB power cable.
5.
Finger drum on the Pads Home screen or the MIDI controller and you are ready to make some
beats!
INTRODUCING NANOBOX | TANGERINE
PRESET NAME
Touch to load and save presets.
Menu
Copy and paste within
and across presets.
Pads
Tap to play. The orange
pad is selected. The
white bar shows
progress.
HOME BUTTON
Go to the Pads
Home, Keys
screen, or the
Sequencer Home.
Trigger pads
with a MIDI
Controller on
notes C2 (36) -
G2 (43).
1 of 4
Sep 22, 2023
nanobox
LAYER BUTTON
Access the Mixer, Mutes
and FX Controls. Cycle
through pads, fx params
or sequence pages.
CLOCK
The current Measure and beat.
Touch to open Transports pop-up.
LEFT ARROW BUTTON
Go back to the previous screen.
RIGHT ARROW BUTTON
Access more detail about the
current selection.
Master Volume
Turn the top knob
to adjust.
KNOBS
Top knob adjusts
master volume,
bottom knob
selects a pad.
Advertisement
Related Manuals for 1010 Music nanobox tangerine
Summary of Contents for 1010 Music nanobox tangerine
- Page 1 nanobox | tangerine Quick Start Guide GET SET UP Insert the microSD card. The card must be in the slot for tangerine to load. The card is spring- loaded. Push to eject when needed, but leave it in for now. Connect the Line Out to your mixer, speakers or headphones.
- Page 2 FEATURE MAP Hold Home to Touch options on access the the Teleporter to Teleporter Menu. jump to a screen. Pads Home Macro Controls Waveform WAV Selector Play pads and Tune the pad Adjust end points Choose a select a preset. settings.
- Page 3 TUNE PAD SETTINGS ON THE MACRO SCREEN Pad Mode Picker Push the layer button to cycle Touch to select a pad through the pads in this preset. mode. Pad Grid Pad Trigger See which pad Touch to trigger the pad to is selected.
- Page 4 EDIT PARAMETERS Graph See how parameter Pad Trigger settings impact the Touch to LFO or Envelope. hear the pad. Push the layer button to Parameters Modulation Slots cycle through Turn the top knob or Push Right Arrow to the pads in touch to select a row.
