LEHMANN QLEEN PURASTART E Quick Manual

1. Setup

1.1 The water inlet (Fig. 1) can be connected as follows:
• With the Gardena adapter over a Gardena hose to the house water connection and then open the
water inlet of the house water connection
• Remove the Gardena adapter and connect the intake hose to the machine and sink the side with
the filter into the water tank
1.2 Attach the hose to the pole and to the brush bow or to the ROTAQLEEN
1.3 Connect the cable for the ROTAQLEEN to the ROTAQLEEN socket (Fig. 2) and to the ROTAQLEEN
1.4 Switch on the battery with the power button
1.5 The battery indicator (Fig. 2) should be green
battery (see chapter 4. Charging)
1.6 The machine is set up
Connections
Shut-off tap
Water input
1

2. Cleaning

2.1 Open the shut-off tap (Fig. 1)
2.2 Place the ROTAQLEEN on the surface to be cleaned and hold the rod with one hand
2.3 Press the button on the remote control (Fig. 3)
2.4 The ROTAQLEEN starts
2.5 After a short time the clean water arrives at the nozzles
Quick Guide QLEEN PURASTART E
Power Button
Battery indicator
ROTAQLEEN socket
2
(Fig. 2), it lights green
green or yellow yellow, if the indicator is red
Battery
green
red please charge the
Remote control
Switch on
Switch off
3
