Quick guide Q-Power backpack system
1. Setup
1.1 Connect the wired remote control (Fig. 1) to the battery pack
1.2 The battery with the power button
1.3 The battery indicator (Fig. 3) should light green
battery (see chapter Charging)
Connect cable remote control
1
1.4 Put on the backpack (Fig. 4) and tighten the straps
1.5 Connect the supplied ROTAQLEEN cable to the wired remote control (Fig. 5)
1.6 Attach the cable to the QLEEN telescopic rod and connect it to the ROTAQLEEN (Fig. 6)
1.7 Connect the water supply to the ROTAQLEEN with a hose
1.8 For best results, we recommend using one of our QLEEN water supply systems, which produce pure
water that dries without leaving streaks
Applied backpack
4
(Fig. 2) switch on this lights up green
green
ROTAQLEEN cable connection
5
or yellow
yellow, if the display is red
Power button
2
green
red, please charge the
Battery indicator
3
Complete system
6
