KUKKO BA-20-30-120 Operating Instructions Manual

Pullers with sliding, parallel jaws
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BA-20-30-120
Abzieher mit gleitenden, immer parallelen Abzughaken
Pullers with sliding, parallel jaws
gültig für / vAlid for
20er, 20-1+, 20-10+, 20-2+, 20-20+, 20-3+, 20-30+, 20-1+S, 20-10+S, 20-
2+S, 20-20+S, 20-3+S, 20-30+S, 20-1+S-T, 20-10+S-T, 20-10-V, 20-2+B,
20-20+B, 20-3+B, 20-30+B, 20-3-H, 20-30-H, 20-4-AV, 20-40-AV, 20-5,
20-4-H, 20-40-H, 20-5-H, 20-ST+, 20-ST-S, 219-1, 30er, 30-1+, 30-10+,
30-2+, 30-20+, 30-3+, 30-30+, 30-1+S, 30-10+S, 30-2+S, 30-20+S,
30-3+S, 30-2+B, 30-20+B, 30-3+B, 30-30+B, K-2030-10, K-2030-10+S,
K-2030-10-S, K-2030-10-S-T, K-2030-20, K-2030-20-B, K-2030-20-S, 30-
20+T, 120er, 120-1, 120-10, 120-2, 120-20, 120-3, 120-30, 120-ST,
VerLetZungen VerMeiDen.
sie müssen diese Bedienungsanleitung lesen und verstehen, bevor sie die abzieher benutzen.
aVOiD inJurY.
You Must read and understand these Operating instructions before using the pullers.
Bedienungsanleitung
Operating instructiOns
A world in motion
since 1919!
Version
BA-20-30-120-2017-02-28
dE
EN
fr
ES
KUKKo Werkzeugfabrik
Kleinbongartz & Kaiser oHG
Heinrich-Hertz-Str. 5
40721 Hilden (Germany)
www.KUKKO.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BA-20-30-120 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KUKKO BA-20-30-120

Summary of Contents for KUKKO BA-20-30-120

  • Page 1 A world in motion since 1919! Bedienungsanleitung Operating instructiOns Version BA-20-30-120-2017-02-28 BA-20-30-120 Abzieher mit gleitenden, immer parallelen Abzughaken Pullers with sliding, parallel jaws gültig für / vAlid for 20er, 20-1+, 20-10+, 20-2+, 20-20+, 20-3+, 20-30+, 20-1+S, 20-10+S, 20- 2+S, 20-20+S, 20-3+S, 20-30+S, 20-1+S-T, 20-10+S-T, 20-10-V, 20-2+B,...
