RuggON MT7000 Quick Start Manual

PACKAGE LIST
Before you begin the installa�on or configura�on process, make sure all the components and
accessories are intact. Contact your representa�ve if any is missing or damaged. Please verify the
delivery of the contents upon receipt.
MT7000 in-vehicle terminal
■
Quick Start Guide
■
Circular power connector to Fork Terminals (Length: 300mm)
■
2-feet DB15 male connector cable with mul�ple end
■
2-feet DB15 male connector cable (no termina�on)
■
NOTE:
The packaging material provides op�mal protec�on to your device. A�er unpacking, DO store the
original packaging material in the event that you need to return for shipment.
PRODUCT INTRODUCTION
Front View
Speaker
Func�on bu�ons
The LEDs on MT7000 are status indicators that show the opera�ng status of your system.
LED Status
Power Blink Green
MT7000
MT7000
Mobile Data T erminal
Quick Start Guide
Ambient light sensor
Display turn on/off
Volume
Power & Communica�on
LED indicators
Speaker
Description
Power up
PRODUCT INTRODUCTION
LED Status
Power Blink Yellow
Power Solid Green
Power Blink Red
Communica�on Solid Green
Rear View
Bo�om View
GNSS(SMA Jack)
Op�onal WWAN Antenna
Connector (SMA Jack)
RS-232(COM1) with 5/12V power output
Side View
SIM Card Slot
Reset bu�on
Micro SD Card Slot
Description
Load boot loader
System ready to use
Vehicle ba�ery abnormal
WWAN enabled
The MT7000 supports a standard VESA version
MIS-D, 75, C (75mm distance quadrate order, M5
thread, deepness 6mm) with four moun�ng holes
on the back side of the device.
DC - in
Op�onal Wi-Fi/BT Antenna
Connector (SMA Jack)
DIO/ CAN bus
LAN
USB, RS - 232/422/485 (COM2)
The power management,
USB Type A
I/O configura�on, and
Headset jack bu�on se�ngs can be
configured in DashON.
P/N: 25U100014-001
