Security Brands SECUREPASS CR1 40-100 Install Manual

I n s t a l l
1
Reader
Attach included Adhesive Template to
A2
mounting surface where required.
Feed Reader cable through pass-
A5
through hole, and connect Reader to
Wiegand controller (not included).
G U I D E
Unpack box and make sure you have all items shown here.
(Hex nuts and screws for faceplate mounting included with faceplate)
Adhesive Mounting Screw
Template
( 2x )
A3
A6
Wall Anchor L Key
( 2x )
Drill mounting and pass-through holes
per Template. Mounting holes are not
required if not using Wall Anchors.
Use 7/16" (6 mm) bit
for mounting holes
and drill to a depth of
1-1/8" (30 mm).
Use 3/8" (10 mm) bit
for pass-through hole.
Hang Reader on Reader Base, ease into
place, and install Set Screw using
included L Key.
Model
I M P O R TA N T
r
If mounting the proximity card reader to a
surface like a wall or door frame, proceed to
Step A2 on this page.
If mounting the proximity card reader to a
controller faceplate, remove the cover plate or
existing card reader, keep the hex nuts and
screws handy, and proceed to Step B2 on the
next page.
Gently tap in Wall Anchors (if using)
A4
with a hammer, and then attach
Reader Base with Mounting Screws.
separate Reader from
Power up Wiegand controller, and
A7
make sure Reader is working correctly
by scanning a valid card (not included).
1 of 2
40-100
r
Remove Set Screw
from Reader using
included L Key to
Reader Base.
Set Reader aside.
