Dot Pad 320
(DPA320A)
Simple Guide
Dot Incorporation
08591
Gasan Digital 1-Ro2, Geumcheon-gu, Seoul, Korea
10F No. 1005 (Gasan-dong, Woorim Lions Valley 2nd)
Phone Number: +82) 2-864-1113
Fax: +82) 2-864-1989
Email: inquiry@dotincorp.com
Homepage: www.dotincorp.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 320 and is the answer not in the manual?

Questions and answers

Related Manuals for DOT 320

Summary of Contents for DOT 320

  • Page 1 Dot Pad 320 (DPA320A) Simple Guide Dot Incorporation 08591 Gasan Digital 1-Ro2, Geumcheon-gu, Seoul, Korea 10F No. 1005 (Gasan-dong, Woorim Lions Valley 2nd) Phone Number: +82) 2-864-1113 Fax: +82) 2-864-1989 Email: inquiry@dotincorp.com Homepage: www.dotincorp.com...

  • Page 2: Table Of Contents

    5.1.1. Connecting iPhone/iPad with the Dot Pad 320 5.1.2. Disconnecting the Dot Pad 320 5.2. Default Key Settings 5.3. Connecting iPhone/iPad with the Dot Pad 320 to read braille and tactile images 5.3.1. Reading Braille Text 5.3.2. Displaying the Image 5.4.
  • Page 3 5.4.5. Adjusting the Image Line Thickness 5.5. Viewing Images Using Voiceover Recognition 5.5.1. Creating Image Recognition Gestures 5.5.2. Using the Image Recognition Function to View an Image 5.6. Customizing the Dot Pad 320 Keys 6. Handling and Safety Precautions 7. Customer Support...

  • Page 4: About Dot Pad 320 (Dpa320A)

    Dot Pad 320. 1.2. Dot Pad 320 Appearance When the Dot Pad 320 is removed from the box and placed on the desk, it is in the correct position when the square body is slightly inclined away from the user.

  • Page 5: Dot Pad 320 Top View

    1.2.1 Dot Pad 320 Top view When the Dot Pad 320 is normally placed, the upper surface of the Dot Pad 320 is divided into the following parts from nearest to farthest from the body: The graphic area: The graphic area takes up the most space from the top view with a total of 300, 8-pin cells (horizontal 30 cells x vertical 10 cells).

  • Page 6: Dot Pad 320 Right Side

    1.2.2. Dot Pad 320 Right Side On the right side of the Dot Pad 320, starting from the rear to the front, there is a USB C type power charging port, followed by a power switch. A USB C type power port is a power only port. Keep in mind that there is no data transfer.

  • Page 7: Dot Pad 320 Left Side

    1.2.3. Dot Pad 320 Left Side On the left side of the Dot Pad 320 is a USB C type port for data transfer. You can connect it to your PC via USB C cable. This port can be controlled by the manager.

  • Page 8: Hardware Specifications

    1.3. Hardware Specifications Tactile Display 300 cells Braille Display 20 cells Graphics area (300 cells) / Text area Protective Skin (20 cells) Processor ARM Cortex-M4 32-Bit 120MHz 64 Kbyte Hardware Specifications Flash Memory 128 Kbyte External Memory Support None Wireless Connection Bluetooth LE V5.0 Sensor None...

  • Page 9: Basic Functions

    2.2. Checking the battery level To check the battery level of the Dot Pad 320, you can press and hold the previous and next panning keys at the same time for at least 1.5 seconds while powered on, and then release them. The levels for displaying the remaining battery are divided into 5 levels and are notified by vibration feedback.

  • Page 10: Connecting Dot Pad 320 To Dot Canvas

    Select Draw Freely or Draw Shapes. Users will be asked to select geometrical shapes of his or her choice. The users will access a drawing area where the users can draw and print the image on the Dot Pad 320.

  • Page 11: Drawing

    3.3.5. Online Gallery Users can view a variety of tactile graphics and images in the Online Gallery which is Dot’s cloud server. Tactile images stored in the Online Gallery can be viewed, but can not be edited. After selecting the file, you can print the image to the Dot Pad 320 via the double tap.

  • Page 12: Using Dtm (Dynamic Tactile Map) Editor

    English and Korean and this can be changed by clicking it. Below the login and language keys, there is a DTM Editor Editing Tool screen. On the screen there are: 1) Dot Pad 320 Print and connect 2) DTM Page 3) DTM Editor Toolbar.

  • Page 13: Connecting Dot Pad 320 Dtm Editor

    4.3.1 Connecting Dot Pad 320 To connect the Dot Pad 320 to the DTM Editor, click [Dot Pad Conn] on the top right corner of the DTM Editor Screen. There are two ways to connect the Dot Pad 320. One is via Bluetooth while the other is via COM (C-type connector).

  • Page 14: Dtm Editor Tool Shortcuts

    Paste selected 5. Application of Dot Pad 320 with VoiceOver The Dot Pad 320 can be used with an iPhone or iPad. Also you can use Dot Canvas application and DTM Editor web software with iphone/ipad and PC that supports Bluetooth.

  • Page 15: Disconnecting The Dot Pad 320

    The Dot Pad 320 can display braille text and graphics. Braille text is displayed on the braille cells close to the front, and the graphic appears in the graphics area that occupies the largest area. This section walks you through Voiceover to view basic braille and graphic information.

  • Page 16: Reading Images In Detail With Rotors

    5.4.4. Scrolling Images Horizontally and Vertically If the image is enlarged at a size that it is difficult to display it all at once in the Dot Pad 320 graphics area, you can scroll the image left, right, up, and down to see the full picture of the image using [Rotate braille horizontally] and [Rotate braille vertically].

  • Page 17: Adjusting The Image Line Thickness

    ※To activate this function, the device must be iOS/iPad OS 14 and above. 5.5.1. Creating Image Recognition Gestures To use Voiceover recognition to send an image to the Dot Pad 320, you must manually add a gesture that allows you to run Voiceover recognition; here's how: Go to [Settings] >...

  • Page 18: Handling And Safety Precautions

    Use with caution as the product may be damaged if impacted. - Keep the dot pads dry. If it is used in a humid place or is wet with water, the product may not work regularly.
  • Page 19 2.Do not use Dot pad in prohibited areas. Do not use in areas where use of the product is prohibited, such as airplanes or hospitals. Electronics and communication products can be affected by electromagnetic waves. 3. Never disassemble and modify.

  • Page 20: Customer Support

    12. Keep the Dot pad in a safe place for storage. When not in use for a long-time, disconnect the charger from the dot pad and store them in a safe place. When storing the power adapter on the dot pad, be careful not to severely fold or twist the USB cable. If the USB cable is stored or used with an excessive fold or twist, the USB cable can be stripped off or disconnected and cause a failure or accident.
